🔧 Civic - Front Brake Pad Replacement

This repair replaces the front disc brake pads on your Civic. The pads are the friction material that clamp against the brake rotors to slow the car, and they should be replaced before they wear down enough to damage the rotors.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack by itself.
• ⚠️ Use jack stands to support the Civic before putting any part of your body near the wheels.
• ⚠️ Brake dust can be harmful. Do not blow it with compressed air; use brake cleaner and a rag.
• ⚠️ Keep brake fluid off paint. It can damage painted surfaces quickly.
• ⚠️ Do not press the brake pedal while the caliper is removed.
• ⚠️ Battery disconnect is not required for this front brake pad replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 19mm lug nut socket
• 12mm socket
• 17mm open-end wrench
• 3/8-inch drive ratchet
• 3/8-inch drive torque wrench
• C-clamp or disc brake piston compression tool
• Flat-blade screwdriver
• Brake cleaner spray
• Shop towels
• Wheel chocks
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake hardware kit - Qty: 1
• Brake caliper grease - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• 🚗 Park your Civic on level ground and shift to Park.
• 🧱 Place wheel chocks behind the rear wheels so the car cannot roll.
• 🅿️ Set the parking brake. The front brakes do not require electronic parking brake service mode.
• 🧴 Open the hood and locate the brake fluid reservoir. If the fluid is at the MAX line, remove a small amount with a clean suction tool before compressing the caliper piston.
• 📌 A caliper is the brake part that squeezes the pads against the rotor. The rotor is the round metal disc behind the wheel.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Wheel Lug Nuts

• Use the 19mm lug nut socket and 3/8-inch drive ratchet to loosen the front lug nuts about 1/2 turn.
• Do this while the tires are still touching the ground so the wheels do not spin.
• Loosen only; do not remove yet.

Step 2: Raise and Support the Front of the Civic

• Use the floor jack rated 2-ton minimum to lift the front of the Civic at the front center jacking point.
• Place jack stands rated 2-ton minimum under the front side pinch weld support points.
• Slowly lower the Civic onto the jack stands and gently shake the car to confirm it is stable.

Step 3: Remove the Front Wheels

• Use the 19mm lug nut socket and 3/8-inch drive ratchet to remove the loosened lug nuts.
• Remove both front wheels and place them flat under the side of the car as an extra safety backup.

Step 4: Remove the Lower Caliper Slide Pin Bolt

• Turn the steering wheel to give yourself more room on the side you are working on.
• Use the 17mm open-end wrench to hold the caliper slide pin steady.
• Use the 12mm socket and 3/8-inch drive ratchet to remove the lower caliper bolt.
• The slide pin lets the caliper move smoothly as the pads wear.

Step 5: Swing the Caliper Up

• Use your hands to swing the caliper upward like a hinge.
• If it feels stuck, use the flat-blade screwdriver gently between the pad and caliper to create a small gap.
• Do not stretch, kink, or hang the caliper by the rubber brake hose.

Step 6: Remove the Old Brake Pads

• Use your hands or the flat-blade screwdriver to slide the old inner and outer brake pads out of the caliper bracket.
• Notice how the wear indicator tab is positioned so the new pads go in the same way.
• The wear indicator is a small metal tab that squeals when the pads are worn low.

Step 7: Remove and Replace the Pad Hardware

• Use the flat-blade screwdriver to remove the old stainless pad clips from the caliper bracket.
• Spray the bracket contact areas with brake cleaner spray and wipe them with shop towels.
• Install the new clips from the front brake hardware kit in the same positions as the old clips.
• Apply a thin film of brake caliper grease to the clip areas where the pad ears slide.
• Do not get grease on the rotor or pad friction surfaces.

Step 8: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use the C-clamp or disc brake piston compression tool to slowly push the piston fully back into the caliper.
• A piston is the round metal part inside the caliper that pushes the brake pad.
• Watch the brake fluid reservoir while compressing the piston so it does not overflow.
• Go slowly to protect the brake system.

Step 9: Install the New Brake Pads

• Use your hands to slide the new inner and outer pads into the caliper bracket.
• Make sure the pad friction material faces the rotor.
• The pads should slide smoothly in the new hardware without forcing them.

Step 10: Reinstall the Caliper

• Swing the caliper back down over the new pads by hand.
• Use the 17mm open-end wrench to hold the slide pin steady.
• Use the 12mm socket and 3/8-inch drive torque wrench to install and tighten the lower caliper bolt.
• Torque to 34 Nm (25 ft-lbs)

Step 11: Repeat on the Other Front Side

• Use the same 12mm socket, 17mm open-end wrench, flat-blade screwdriver, and C-clamp or disc brake piston compression tool to replace the pads on the other front wheel.
• Always replace front brake pads as a full axle set, left and right together.

Step 12: Reinstall the Front Wheels

• Use your hands to install the lug nuts until finger-tight.
• Use the 19mm lug nut socket and 3/8-inch drive ratchet to snug the lug nuts in a star pattern.
• Raise the Civic slightly with the floor jack rated 2-ton minimum, remove the jack stands rated 2-ton minimum, and lower the vehicle to the ground.
• Use the 19mm lug nut socket and 3/8-inch drive torque wrench to tighten the lug nuts in a star pattern.
• Torque to 108 Nm (80 ft-lbs)

Step 13: Pump the Brake Pedal

• Sit in the driver seat and press the brake pedal slowly 5-10 times until it feels firm.
• This moves the caliper pistons back out so the pads contact the rotors.
• Do not drive until the pedal feels firm.

---

✅ After Repair

• ✅ Check the brake fluid level and make sure it is between MIN and MAX.
• ✅ Start the Civic and press the brake pedal again. It should feel firm, not spongy.
• ✅ Test drive slowly in a safe area before normal driving.
• ✅ Perform gentle stops for the first 200 miles. Avoid hard braking unless needed for safety.
• ✅ If you hear grinding, feel vibration, or the pedal sinks, stop driving and recheck the work.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$420 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $175-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
