🔧 CR-V - Water Pump Replacement

The water pump circulates coolant through your CR-V’s engine and radiator. Replacing it involves draining the coolant, removing the drive belt and water pump pulley, unbolting the pump, then refilling and bleeding the cooling system.

Difficulty Level: Intermediate | Estimated Time: 2.5-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Work only on a completely cold engine. Hot coolant can spray out and cause serious burns.
• ⚠️ Keep fingers, clothing, and tools away from the drive belt and cooling fan area.
• ⚠️ Coolant is toxic. Catch all drained coolant and keep it away from pets and children.
• ⚠️ Support your CR-V with jack stands if raising the vehicle. Never work under a vehicle held only by a jack.
• ⚠️ Battery disconnect is not normally required, but keep the ignition OFF during belt and pump removal.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 3/8-inch drive ratchet
• 3/8-inch drive breaker bar
• 3/8-inch drive extension 6-inch
• Torque wrench inch-pound
• Torque wrench foot-pound
• Serpentine belt tool (specialty)
• Pulley holding tool (specialty)
• Flat-blade screwdriver
• Plastic trim removal tool
• Pick tool set
• Gasket scraper plastic
• Drain pan 2-gallon minimum
• Coolant funnel kit with radiator adapter (specialty)
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Shop towels
• Safety glasses
• Nitrile gloves

A serpentine belt tool is a long, thin tool that gives extra reach and leverage to move the belt tensioner safely.

A pulley holding tool keeps the pulley from spinning while you loosen or tighten its bolts.

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Water pump - Qty: 1
• Water pump gasket or O-ring - Qty: 1
• Honda Type 2 coolant or equivalent blue premixed coolant - Qty: 1-2 gallons
• Serpentine drive belt - Qty: 1 if worn, cracked, noisy, or coolant-contaminated
• Water pump pulley bolts - Qty: As needed if damaged or corroded
• Plastic splash shield clips - Qty: As needed

---

📋 Before You Begin

• 🚗 Park your CR-V on level ground and set the parking brake.
• 🛞 Place wheel chocks behind the rear wheels.
• ❄️ Let the engine cool completely before opening the cooling system.
• 📸 Take a clear photo of the serpentine belt routing before removal.
• 🧴 Use Honda Type 2 coolant or an equivalent blue premixed coolant. Do not mix coolant types.
• 📌 Assumption: this procedure covers the external belt-driven engine water pump on the 1.5L turbo engine.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Release Cooling System Pressure

• Make sure the engine is fully cold before touching the coolant cap.
• Use a shop towel and your hand to slowly loosen the coolant reservoir cap.
• If you hear pressure escaping, stop and wait longer before continuing.
• Never rush a hot cooling system.

Step 2: Raise and Support the Vehicle

• Use a floor jack to lift the front of your CR-V at the front jacking point.
• Place jack stands under the front support points.
• Lower your CR-V gently onto the jack stands.
• Leave the floor jack nearby, but do not use it as the only support.

Step 3: Remove the Lower Splash Shield

• Use a plastic trim removal tool to remove the plastic splash shield clips.
• Use a 10mm socket with a 3/8-inch drive ratchet to remove any 10mm splash shield fasteners.
• Remove the splash shield and set the hardware aside in order.
• For reinstallation later, tighten splash shield bolts to Torque to 9 Nm (80 in-lbs).

Step 4: Drain the Coolant

• Place a 2-gallon drain pan under the radiator drain area.
• Use your hand or a flat-blade screwdriver to open the radiator drain plug if accessible.
• Drain the coolant until the radiator and engine water pump area are below coolant level.
• Close the radiator drain plug by hand. Do not overtighten it.
• If the drain plug is not accessible, use the drain pan and remove the lower radiator hose carefully.

Step 5: Loosen the Water Pump Pulley Bolts

• Before removing the belt, use a pulley holding tool to keep the water pump pulley from turning.
• Use a 10mm socket with a 3/8-inch drive ratchet to loosen the water pump pulley bolts about one turn.
• Do not remove the pulley bolts yet.
• Loosen pulley bolts before belt removal.

Step 6: Remove the Serpentine Drive Belt

• Use a serpentine belt tool or 3/8-inch drive breaker bar on the belt tensioner.
• Rotate the tensioner to release belt tension.
• Slide the belt off the water pump pulley by hand.
• Slowly release the tensioner. Do not let it snap back.
• Remove the belt from the remaining pulleys if replacing it, or move it aside if reusing it.

Step 7: Remove the Water Pump Pulley

• Use the pulley holding tool again to hold the pulley steady.
• Use a 10mm socket with a 3/8-inch drive ratchet to remove the loosened water pump pulley bolts.
• Remove the water pump pulley by hand.
• Set the pulley on a clean surface.

Step 8: Remove the Water Pump

• Place shop towels below the pump to catch leftover coolant.
• Use a 10mm socket or 12mm socket with a 3/8-inch drive ratchet and 6-inch extension to remove the water pump mounting bolts.
• Remove the bolts evenly and keep track of their positions.
• Pull the water pump straight off by hand.
• If it is stuck, use a plastic gasket scraper gently at the edge. Do not pry hard on aluminum.

Step 9: Clean the Mounting Surface

• Use a plastic gasket scraper to remove old gasket material from the engine-side surface.
• Use shop towels to wipe the surface clean and dry.
• Use a pick tool set only for small stuck pieces near corners.
• Do not scratch or gouge the aluminum sealing surface.
• The surface must be smooth so the new gasket can seal.

Step 10: Install the New Water Pump

• Install the new water pump gasket or O-ring onto the new pump by hand.
• Position the new water pump against the engine carefully.
• Start all mounting bolts by hand first to avoid cross-threading.
• Use a 10mm socket or 12mm socket with a 3/8-inch drive ratchet to snug the bolts evenly in a crisscross pattern.
• Use a torque wrench inch-pound to tighten the water pump mounting bolts to Torque to 12 Nm (106 in-lbs).

Step 11: Reinstall the Water Pump Pulley

• Place the water pump pulley onto the new pump by hand.
• Start all pulley bolts by hand.
• Use a 10mm socket with a 3/8-inch drive ratchet to snug the pulley bolts lightly.
• Final torque will happen after the belt is installed.

Step 12: Reinstall the Serpentine Drive Belt

• Use your belt routing photo to route the belt around the pulleys.
• Use the serpentine belt tool or 3/8-inch drive breaker bar to rotate the tensioner.
• Slide the belt over the final pulley by hand.
• Slowly release the tensioner.
• Check that the belt ribs sit fully in every pulley groove.

Step 13: Torque the Water Pump Pulley Bolts

• Use the pulley holding tool to hold the water pump pulley steady.
• Use a 10mm socket with a torque wrench foot-pound to tighten the pulley bolts evenly.
• Tighten the water pump pulley bolts to Torque to 12 Nm (106 in-lbs).
• Double-check that the pulley spins straight and does not wobble.

Step 14: Refill the Cooling System

• Install a coolant funnel kit with radiator adapter at the fill point if the adapter fits.
• Slowly add Honda Type 2 coolant or equivalent blue premixed coolant.
• Fill the coolant reservoir to the correct level mark.
• Squeeze the upper radiator hose by hand several times to help move trapped air.

Step 15: Bleed Air from the Cooling System

• Leave the coolant funnel partly filled.
• Start the engine and let it idle.
• Set the heater temperature to full hot and the blower to low.
• Add coolant as the level drops.
• Watch for air bubbles in the funnel.
• Let the engine warm until the radiator fan cycles on if possible.
• Use a flashlight to inspect around the water pump, radiator drain, and hoses for leaks.

Step 16: Cap the Cooling System

• Turn the engine OFF.
• Let bubbles settle in the funnel.
• Use the coolant funnel stopper to remove the funnel cleanly.
• Install the coolant cap by hand until fully seated.
• Wipe away spilled coolant with shop towels.

Step 17: Reinstall the Lower Splash Shield

• Lift the lower splash shield into place by hand.
• Use a plastic trim removal tool to reinstall the plastic clips.
• Use a 10mm socket with a 3/8-inch drive ratchet to reinstall the 10mm splash shield fasteners.
• Tighten splash shield bolts to Torque to 9 Nm (80 in-lbs).

Step 18: Lower the Vehicle

• Use the floor jack to lift your CR-V slightly off the jack stands.
• Remove the jack stands.
• Lower the vehicle slowly with the floor jack.
• Remove the wheel chocks after the vehicle is safely on the ground.

---

✅ After Repair

• ✅ Test drive your CR-V for 10-15 minutes while watching the temperature gauge.
• ✅ Make sure the heater blows warm air after the engine reaches operating temperature.
• ✅ Listen for belt squeal or pulley noise near the water pump area.
• ✅ Park on level ground and let the engine cool completely.
• ✅ Recheck the coolant level and top off if needed.
• ✅ Inspect the new water pump, pulley area, and lower splash shield area for coolant leaks.
• ✅ Recheck coolant level again after 2-3 normal drive cycles.
• ✅ Dispose of used coolant through an approved recycling or hazardous waste facility.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $90-$250 (parts only)

You Save: $300-$600 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2.5-4 hours.

---
