🔧 Frontier - Timing Chain Service

Your Frontier does not use a timing belt. The 4.0L V6 uses a timing chain system, which is inside the front of the engine and is designed to last much longer than a belt.

This repair is much more involved than a belt replacement because the front engine cover, valve covers, oil pan sealing area, coolant, and multiple timing components must be removed and resealed correctly.

Difficulty Level: Advanced | Estimated Time: 8-12 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable before starting to prevent accidental cranking.
• ⚠️ Let the engine cool completely before draining coolant or removing front engine parts.
• ⚠️ Support the vehicle securely with jack stands. Never rely on a jack alone.
• ⚠️ Do not rotate the crankshaft or camshafts independently once the timing chains are removed.
• ⚠️ Incorrect cam timing can cause severe engine damage.
• ⚠️ Use paint marks and factory timing marks together. Paint marks alone are not enough.
• ⚠️ This job requires careful sealing. Oil or coolant leaks are common if surfaces are not cleaned correctly.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 17mm socket
• 19mm socket
• 27mm socket
• 3/8-inch ratchet
• 1/2-inch breaker bar
• 3/8-inch torque wrench
• 1/2-inch torque wrench
• Socket extension set
• Universal joint socket adapter
• Serpentine belt tool
• Harmonic balancer puller (specialty)
• Crankshaft pulley holding tool (specialty)
• Camshaft holding tool (specialty)
• Plastic trim clip remover
• Gasket scraper
• Plastic razor scraper
• Drain pan
• Funnel
• Coolant fill funnel kit
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Shop towels
• Brake cleaner
• Paint marker
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Primary timing chain - Qty: 1
• Secondary timing chains - Qty: 2
• Timing chain guide set - Qty: 1
• Timing chain tensioner set - Qty: 1
• Crankshaft front seal - Qty: 1
• Front timing cover sealant - Qty: 1
• Valve cover gaskets - Qty: 2
• Spark plug tube seals - Qty: 6
• Upper intake manifold gasket set - Qty: 1
• Throttle body gasket - Qty: 1
• Engine coolant - Qty: As needed
• Engine oil - Qty: 5.4 quarts
• Oil filter - Qty: 1
• Serpentine belt - Qty: 1

---

📋 Before You Begin

• 📋 Park your Frontier on level ground and set the parking brake.
• 📋 Place wheel chocks behind the rear wheels.
• 📋 Disconnect the negative battery cable using a 10mm socket.
• 📋 Raise the front with a floor jack rated 3-ton minimum and support it with jack stands rated 3-ton minimum.
• 📋 A harmonic balancer is the crankshaft pulley at the front of the engine. It must be pulled off with a special puller.
• 📋 A timing chain tensioner keeps the chain tight using spring and oil pressure.
• 📋 Expect this repair to take a full weekend if you are new to engine work.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect Battery and Remove Skid Protection

• Use a 10mm socket to disconnect the negative battery cable.
• Use a 12mm socket or 14mm socket to remove the front skid plate if equipped.
• Set all bolts aside in labeled containers.
• Label bolts as you go.

Step 2: Drain Coolant and Engine Oil

• Place a drain pan under the radiator drain area.
• Open the radiator drain carefully and drain the coolant.
• Use a 14mm socket to remove the engine oil drain plug.
• Drain the oil completely into the drain pan.
• Reinstall the oil drain plug and torque to 34 Nm (25 ft-lbs).

Step 3: Remove Engine Covers and Intake Ducting

• Use a 10mm socket to remove the plastic engine cover fasteners.
• Use a 10mm socket or screwdriver to loosen the air intake tube clamps.
• Disconnect the mass airflow sensor electrical connector by pressing the release tab.
• Remove the intake tube and air ducting from the engine bay.

Step 4: Remove Upper Intake Manifold

• Use a 10mm socket and 12mm socket to remove brackets and intake manifold bolts.
• Disconnect vacuum hoses and electrical connectors by hand.
• Lift the upper intake manifold straight up.
• Cover the intake ports with clean shop towels so nothing falls inside.
• Do not drop bolts inside.

Step 5: Remove Serpentine Belt

• Use a serpentine belt tool on the belt tensioner.
• Rotate the tensioner to release belt tension.
• Slide the belt off the pulleys and remove it.
• Take a photo of the belt routing before removal.

Step 6: Remove Cooling Fan, Shroud, and Front Accessories

• Use a 10mm socket to remove the fan shroud fasteners.
• Use a 10mm socket and 12mm socket to remove front accessory brackets as needed.
• Move wiring and hoses aside gently. Do not pull on connectors.

Step 7: Remove Crankshaft Pulley

• Install the crankshaft pulley holding tool to hold the pulley still.
• Use a 27mm socket and 1/2-inch breaker bar to loosen the crankshaft pulley bolt.
• Use the harmonic balancer puller to pull the pulley off the crankshaft.
• Do not pry against the timing cover.

Step 8: Remove Valve Covers

• Use a 10mm socket to remove ignition coil bolts.
• Pull the ignition coils upward and set them aside in order.
• Use a 10mm socket to remove both valve cover bolts.
• Lift off the valve covers carefully.
• Remove old valve cover gaskets and spark plug tube seals.

Step 9: Remove Front Timing Cover

• Use a 10mm socket, 12mm socket, and 14mm socket to remove timing cover bolts.
• Use a plastic trim clip remover or plastic razor scraper to gently separate the cover.
• Do not gouge the aluminum sealing surfaces.
• Remove the front cover and set it on a clean workbench.

Step 10: Set Engine to Top Dead Center

• Use a 27mm socket on the crankshaft bolt area to rotate the engine clockwise only.
• Align the crankshaft and camshaft timing marks to the factory timing positions.
• Use a paint marker to mark the chain-to-sprocket positions before removal.
• Top dead center means piston number one is at the top of its compression stroke.

Step 11: Remove Timing Chain Tensioners and Guides

• Use a 10mm socket and 12mm socket to remove timing chain tensioner bolts.
• Use a camshaft holding tool to prevent camshaft movement.
• Remove the chain guides and tensioners in order.
• Keep your fingers clear of chain pinch points.

Step 12: Remove Timing Chains

• Remove the primary timing chain first.
• Remove both secondary timing chains after the tension is released.
• Do not rotate the crankshaft or camshafts after chain removal.
• Compare old chains, guides, and tensioners with the new parts before installing.

Step 13: Install New Timing Chains, Guides, and Tensioners

• Install the new secondary timing chains using the colored chain links and factory sprocket marks.
• Install the new primary timing chain using the colored chain links and factory crank/cam timing marks.
• Use a 10mm socket and 12mm socket to install the guides and tensioners.
• Typical small timing guide fasteners are tightened carefully with a 3/8-inch torque wrench; do not overtighten aluminum-thread bolts.
• Release the tensioners only after all timing marks are aligned.
• Check timing marks twice.

Step 14: Rotate Engine by Hand

• Use a 27mm socket and rotate the crankshaft clockwise two full turns.
• Stop immediately if the engine binds or feels locked.
• Recheck that the timing marks return to their proper alignment positions.
• If marks are off, remove the chains and correct the timing before continuing.

Step 15: Clean Sealing Surfaces

• Use a plastic razor scraper and gasket scraper to remove old sealant.
• Use brake cleaner on a towel to clean oil from sealing surfaces.
• Do not let debris fall into the oil pan or timing area.
• Sealing surfaces must be clean and dry before applying new sealant.

Step 16: Install Front Timing Cover

• Apply front timing cover sealant to the cover in the same pattern as the factory sealant path.
• Install the timing cover carefully without smearing the sealant.
• Use a 10mm socket, 12mm socket, and 14mm socket to install the bolts by hand first.
• Tighten bolts gradually with a 3/8-inch torque wrench in a crisscross pattern.
• Small cover bolts are typically tightened lightly; avoid stripping aluminum threads.

Step 17: Install Crankshaft Front Seal and Pulley

• Install the new crankshaft front seal squarely into the timing cover.
• Slide the crankshaft pulley back onto the crankshaft.
• Use the crankshaft pulley holding tool and 27mm socket to tighten the crankshaft pulley bolt.
• Use the factory torque-plus-angle method if your service information specifies it for the pulley bolt.

Step 18: Reinstall Valve Covers

• Install new valve cover gaskets and spark plug tube seals.
• Use a 10mm socket to reinstall the valve covers.
• Tighten valve cover bolts evenly with a 3/8-inch torque wrench.
• Reinstall ignition coils using a 10mm socket.

Step 19: Reinstall Intake Manifold and Accessories

• Install new upper intake manifold gaskets.
• Use a 10mm socket and 12mm socket to reinstall the intake manifold and brackets.
• Reconnect all vacuum hoses and electrical connectors.
• Install the intake ducting and tighten clamps with a 10mm socket.

Step 20: Install New Serpentine Belt

• Route the new serpentine belt around the pulleys using your photo.
• Use the serpentine belt tool to rotate the tensioner.
• Slide the belt into place and release the tensioner slowly.
• Make sure the belt ribs sit fully in every pulley groove.

Step 21: Refill Oil and Coolant

• Install a new oil filter by hand.
• Use a funnel to refill the engine with fresh engine oil.
• Use a coolant fill funnel kit to refill the cooling system.
• Reconnect the negative battery cable using a 10mm socket.

Step 22: First Start Check

• Before starting, check that all tools are removed from the engine bay.
• Start the engine and listen carefully.
• A brief rattle for one or two seconds may occur while oil pressure fills the tensioners.
• Shut the engine off immediately if you hear loud knocking, grinding, or continuous chain noise.

---

✅ After Repair

• ✅ Check for oil leaks around the front timing cover, valve covers, and crankshaft seal.
• ✅ Check for coolant leaks around hoses and the radiator drain.
• ✅ Let the engine reach operating temperature with the heater on hot.
• ✅ Top off coolant after air bubbles stop coming through the fill funnel.
• ✅ Recheck engine oil level after the first warm-up.
• ✅ Road test gently for 10-15 minutes, then inspect again for leaks.
• ✅ Change the oil again soon if debris or old sealant may have entered the pan.

---

💰 DIY vs Shop Cost

Shop Cost: $1,800-$3,200 USD equivalent (parts + labor)

DIY Cost: $450-$950 USD equivalent (parts only)

You Save: $1,000-$2,200 USD equivalent by doing it yourself!

Shop labor rates vary by region. This repair takes a shop approximately 8-12 hours.

---
