🔧 Traverse - Timing Drive Inspection

Your Traverse does not use a timing belt. The 3.6L V6 uses an internal timing chain system, which is lubricated by engine oil and is not a normal maintenance replacement item like a belt.

Replacing the timing chains is an advanced engine repair that requires major front-engine disassembly, special holding tools, and exact camshaft timing setup. This is usually done only for chain stretch, guide failure, tensioner failure, or related diagnostic trouble codes.

Difficulty Level: Advanced | Estimated Time: 10-14 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable before working near the starter, alternator, or engine harness.
• ⚠️ Support the engine correctly before removing any engine mount brackets.
• ⚠️ Do not rotate the crankshaft or camshafts independently after the timing chains are removed. Engine damage can occur.
• ⚠️ Keep the work area extremely clean. Dirt inside the engine can damage bearings, chains, and oil passages.
• ⚠️ This repair requires accurate timing alignment. If the timing is set incorrectly, valves and pistons can be damaged.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 13mm socket
• 15mm socket
• 18mm socket
• 24mm socket
• E10 external Torx socket
• E12 external Torx socket
• 3/8-inch ratchet
• 1/2-inch breaker bar
• 3/8-inch torque wrench
• 1/2-inch torque wrench
• Torque angle gauge (specialty)
• Harmonic balancer puller (specialty)
• Camshaft holding tool set (specialty)
• Crankshaft holding tool (specialty)
• Engine support bar (specialty)
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Drain pan
• Plastic scraper
• Gasket cleaning brush
• Trim clip removal tool
• Serpentine belt tool
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Timing chain kit - Qty: 1
• Timing chain guides - Qty: 1 set
• Timing chain tensioners - Qty: 1 set
• Timing cover gasket set - Qty: 1
• Valve cover gasket set - Qty: 1
• Front crankshaft seal - Qty: 1
• Engine oil (5W-30 full synthetic) - Qty: 6 quarts
• Oil filter - Qty: 1
• Engine coolant - Qty: As needed
• RTV engine sealant - Qty: 1 tube
• Harmonic balancer bolt - Qty: 1
• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park your Traverse on level ground and let the engine cool completely.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Disconnect the negative battery cable using a 10mm socket.
• Raise the front of the vehicle with a floor jack and support it with jack stands.
• Drain the engine oil into a drain pan.
• Drain the coolant into a drain pan if the timing cover removal requires coolant pipe or pump access.
• A harmonic balancer is the crankshaft pulley at the front of the engine.
• A torque angle gauge measures extra bolt rotation after a torque value is reached.
• A camshaft holding tool locks the camshafts so valve timing stays correct.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove Engine Covers And Intake Ducting

• Use your hands to lift off the plastic engine appearance cover.
• Use a flat-blade screwdriver or 8mm socket if needed to loosen the air intake duct clamps.
• Remove the intake duct and set it aside.
• Take photos before unplugging connectors.

Step 2: Disconnect Battery And Raise Vehicle

• Use a 10mm socket to disconnect the negative battery cable.
• Use a floor jack to lift the front of your Traverse.
• Place jack stands under approved front support points.
• Gently lower the vehicle onto the stands before working underneath.

Step 3: Remove Splash Shields And Access Panels

• Use a trim clip removal tool to remove plastic push clips.
• Use a 10mm socket to remove lower splash shield fasteners.
• Set the shields and fasteners aside in order.

Step 4: Drain Engine Oil And Coolant

• Place a drain pan under the oil pan.
• Use the correct socket for the drain plug and drain the engine oil.
• Remove the oil filter with an oil filter wrench if needed.
• Place a drain pan under the radiator drain area and drain coolant as needed.
• Reinstall the oil drain plug after draining. Torque to 25 Nm (18 ft-lbs).

Step 5: Remove Serpentine Belt

• Use a serpentine belt tool on the belt tensioner.
• Rotate the tensioner to release belt tension.
• Slide the belt off the pulleys and remove it.
• Draw the belt route first.

Step 6: Support Engine

• Install an engine support bar across the upper engine bay.
• Attach the support hooks to proper engine lift points.
• Apply light upward tension only. Do not lift the vehicle by the engine.

Step 7: Remove Engine Mount Brackets As Needed

• Use 15mm socket and 18mm socket to remove the mount fasteners blocking front cover access.
• Keep bolts organized by location.
• When reinstalling engine mount fasteners, tighten to the service specification for your exact fastener location. Typical mount fasteners are torque-to-yield and should not be reused if specified by GM.

Step 8: Remove Valve Covers

• Unplug ignition coil connectors by hand.
• Use a 10mm socket to remove ignition coil bolts.
• Remove the ignition coils and label their positions.
• Use a 10mm socket to remove valve cover bolts.
• Lift off the valve covers carefully.
• During reassembly, tighten valve cover bolts evenly. Torque to 10 Nm (89 in-lbs).

Step 9: Remove Harmonic Balancer

• Use a crankshaft holding tool to keep the crankshaft from turning.
• Use a 24mm socket and 1/2-inch breaker bar to loosen the harmonic balancer bolt.
• Install a harmonic balancer puller.
• Remove the harmonic balancer straight off the crankshaft.
• Do not pry against the timing cover.

Step 10: Remove Front Timing Cover

• Use 10mm socket, 13mm socket, E10 external Torx socket, and E12 external Torx socket to remove timing cover fasteners.
• Note bolt length and location. Some bolts are different lengths.
• Carefully separate the cover using a plastic scraper.
• Do not gouge the aluminum sealing surfaces.

Step 11: Set Engine To Timing Position

• Use a 24mm socket on the crankshaft to rotate the engine clockwise only.
• Align factory timing marks on the crankshaft and camshaft sprockets.
• Install the camshaft holding tool set to lock the camshafts.
• Install the crankshaft holding tool if required.
• Do not rotate camshafts after chains are removed.

Step 12: Remove Timing Chain Tensioners And Guides

• Use a 10mm socket or E10 external Torx socket as equipped to remove tensioner fasteners.
• Remove the timing chain tensioners.
• Use the correct socket to remove guide bolts.
• Remove the timing chain guides.
• Keep each bank’s parts separated.

Step 13: Remove Timing Chains

• With the guides and tensioners removed, lift the chains off the sprockets.
• Do not move the camshaft sprockets or crankshaft sprocket.
• If anything moves, stop and reset timing with the holding tools before continuing.

Step 14: Install New Timing Chains, Guides, And Tensioners

• Match the colored chain links to the timing marks on the camshaft and crankshaft sprockets.
• Install the new chain guides using the correct socket.
• Install the new tensioners using the correct socket.
• Release the tensioner pins only after the chain, guides, and timing marks are fully aligned.
• Typical guide and tensioner fasteners are tightened to light torque values; use the specification supplied with the timing kit or GM service procedure for the exact bolt location.

Step 15: Verify Timing Before Closing Engine

• Remove the holding tools.
• Use a 24mm socket to rotate the crankshaft clockwise by hand two full turns.
• Feel for binding. Stop immediately if the engine locks or feels hard to turn.
• Recheck that timing marks return to the correct positions.
• Never use the starter motor for this check.

Step 16: Clean Sealing Surfaces

• Use a plastic scraper to remove old gasket material.
• Use a gasket cleaning brush lightly on stubborn areas.
• Do not scratch the aluminum surfaces.
• Apply RTV engine sealant only where the factory sealing joints require it.

Step 17: Reinstall Timing Cover

• Install the new front crankshaft seal into the timing cover.
• Position the timing cover carefully without disturbing the RTV.
• Start all bolts by hand first.
• Use 10mm socket, 13mm socket, E10 external Torx socket, and E12 external Torx socket to tighten bolts evenly.
• Timing cover bolts use different torque specs by size and location; follow the included gasket kit or GM fastener map exactly.

Step 18: Reinstall Harmonic Balancer

• Slide the harmonic balancer onto the crankshaft by hand.
• Install a new harmonic balancer bolt.
• Use a crankshaft holding tool to hold the crankshaft.
• Use a 24mm socket, 1/2-inch torque wrench, and torque angle gauge to tighten the bolt to the current GM torque-plus-angle specification.
• Do not reuse the old balancer bolt if it is torque-to-yield.

Step 19: Reinstall Valve Covers

• Install new valve cover gaskets.
• Set the valve covers in place.
• Use a 10mm socket to snug the bolts evenly.
• Torque to 10 Nm (89 in-lbs).
• Reinstall ignition coils with a 10mm socket.

Step 20: Reinstall Mounts, Belt, Shields, And Intake

• Use 15mm socket and 18mm socket to reinstall engine mount brackets.
• Use a serpentine belt tool to install the new serpentine belt.
• Use a 10mm socket and trim clip removal tool to reinstall splash shields.
• Reinstall the intake duct and tighten clamps with the correct socket or screwdriver.

Step 21: Refill Oil And Coolant

• Install a new oil filter by hand until snug, then tighten per the filter instructions.
• Add 5W-30 full synthetic engine oil.
• Refill the cooling system with the correct engine coolant if drained.
• Reconnect the negative battery cable using a 10mm socket.

---

✅ After Repair

• ✅ Before starting, crank the engine briefly only after confirming oil and coolant are filled.
• ✅ Start the engine and listen for rattling, knocking, or chain noise.
• ✅ Check around the timing cover, valve covers, oil filter, and drain plug for leaks.
• ✅ Let the engine reach operating temperature and watch the coolant level.
• ✅ Shut the engine off, let it cool, and recheck oil and coolant levels.
• ✅ If a check engine light appears, scan for cam/crank correlation codes before driving.
• ✅ Road test gently, then recheck for leaks again.

---

💰 DIY vs Shop Cost

Shop Cost: $2,200-$4,000 (parts + labor)

DIY Cost: $450-$1,100 (parts only)

You Save: $1,750-$2,900 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 10-14 hours.

---
