🔧 Edge - Thermostat Replacement

The thermostat controls coolant flow between the engine and radiator. On your Edge, replacing it requires draining some coolant, removing the thermostat housing, installing the new thermostat/seal, then refilling and bleeding the cooling system.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant reservoir cap when the engine is hot. Hot coolant can spray out and cause burns.
• 🧊 Let the engine cool completely before starting. The upper radiator hose should feel cool to the touch.
• 🧤 Wear gloves and safety glasses. Coolant is slippery, toxic, and harmful to pets.
• 🔋 Battery disconnect is not normally required for this thermostat replacement, but keep tools away from the battery terminals.
• 🌡️ Dispose of old coolant properly. Do not pour it on the ground or into a drain.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 10mm socket
• 1/4-inch drive ratchet
• 3/8-inch drive ratchet
• 6-inch socket extension
• Hose clamp pliers
• Flat-blade screwdriver
• Plastic trim clip remover
• Drain pan, 2-gallon minimum
• Coolant funnel kit
• Torque wrench, inch-pound capable
• Shop towels
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine coolant thermostat - Qty: 1
• Thermostat housing seal/O-ring - Qty: 1
• Motorcraft Orange-compatible prediluted coolant or correct Ford-approved replacement coolant - Qty: 1-2 gallons
• Upper radiator hose clamp - Qty: 1, if original clamp is weak or damaged

---

📋 Before You Begin

• 🚗 Park your Edge on level ground and set the parking brake.
• 🧊 Let the engine cool fully, ideally for several hours.
• 🧴 A coolant funnel kit is a spill-control funnel that attaches to the coolant reservoir and helps remove trapped air while refilling.
• 🔧 A torque wrench tightens bolts to the correct force so the plastic thermostat housing is not cracked or left loose.
• 📌 Keep the new thermostat clean. Dirt on the seal can cause leaks.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Appearance Cover

• Use both hands to lift the plastic engine cover straight upward from its rubber mounting points.
• Set the cover aside where it will not be stepped on.
• Pull evenly, not sideways.

Step 2: Remove the Air Inlet Duct for Access

• Use an 8mm socket or flat-blade screwdriver to loosen the air duct clamp at the throttle body.
• Use an 8mm socket or flat-blade screwdriver to loosen the clamp at the air filter box.
• Disconnect any small breather hose from the duct by hand if it blocks removal.
• Lift the duct out and place it aside.

Step 3: Relieve Cooling System Pressure

• Make sure the engine is cold.
• Slowly turn the coolant reservoir cap counterclockwise by hand.
• If you hear pressure escaping, stop and wait until it finishes, then remove the cap fully.

Step 4: Drain Some Coolant

• Place a 2-gallon drain pan under the radiator drain area.
• Use a plastic trim clip remover to remove any lower splash shield clips needed for access.
• Use your hand or a flat-blade screwdriver carefully on the radiator drain petcock if accessible, and drain about 1 gallon of coolant.
• If the drain petcock is not easy to reach, use hose clamp pliers to loosen the lower radiator hose clamp slightly and drain coolant carefully from the hose connection.
• Close the drain petcock or reinstall the hose and clamp securely after draining.

Step 5: Locate the Thermostat Housing

• Follow the upper radiator hose from the radiator toward the engine.
• The hose attaches to the thermostat housing on the engine side.
• Use shop towels under the housing area to catch small coolant spills.

Step 6: Disconnect the Upper Radiator Hose

• Use hose clamp pliers to squeeze the spring clamp tabs on the upper radiator hose.
• Slide the clamp back onto the hose.
• Twist the hose gently by hand to break it loose, then pull it off the thermostat housing.
• If stuck, use a flat-blade screwdriver carefully between the hose and housing edge. Do not gouge the plastic housing.
• Twist first, then pull.

Step 7: Remove the Thermostat Housing Bolts

• Use a 10mm socket, 6-inch socket extension, and 3/8-inch drive ratchet to remove the thermostat housing bolts.
• Hold the housing with one hand as the last bolt comes out.
• Pull the housing away from the engine.
• Expect a small amount of coolant to drain out. Catch it with the drain pan and shop towels.

Step 8: Remove the Old Thermostat and Seal

• Pull the old thermostat out by hand.
• Remove the old seal/O-ring by hand or with a flat-blade screwdriver used very gently.
• Do not scratch the sealing surface. A scratch can cause a coolant leak.

Step 9: Clean the Sealing Surfaces

• Use shop towels to wipe the thermostat housing and engine sealing area clean.
• Do not use metal scrapers on the aluminum or plastic sealing surfaces.
• Make sure no old seal pieces remain.

Step 10: Install the New Thermostat

• Install the new thermostat in the same orientation as the old one.
• Install the new thermostat seal/O-ring fully into its groove by hand.
• If the thermostat has a small jiggle valve or air bleed, position it upward when possible.
• Match the old thermostat position.

Step 11: Reinstall the Thermostat Housing

• Place the housing squarely against the engine by hand.
• Start all bolts by hand first to avoid cross-threading.
• Use a 10mm socket, 6-inch socket extension, and 3/8-inch drive ratchet to snug the bolts evenly.
• Use an inch-pound torque wrench with a 10mm socket to tighten the thermostat housing bolts to Torque to 10 Nm (89 in-lbs).
• Do not overtighten. The housing can crack.

Step 12: Reconnect the Upper Radiator Hose

• Push the upper radiator hose fully onto the thermostat housing by hand.
• Use hose clamp pliers to move the spring clamp back to its original position.
• Make sure the clamp sits behind the raised bead on the housing neck.

Step 13: Reinstall the Air Inlet Duct

• Place the air duct back between the air filter box and throttle body.
• Reconnect any breather hose by hand.
• Use an 8mm socket or flat-blade screwdriver to tighten both air duct clamps snugly.

Step 14: Refill the Cooling System

• Install the coolant funnel kit onto the coolant reservoir.
• Pour the correct Ford-approved prediluted coolant into the reservoir until it reaches the proper level.
• Leave some coolant in the funnel so air bubbles can escape while the engine warms up.

Step 15: Bleed Air from the Cooling System

• Start the engine and let it idle with the coolant funnel installed.
• Set the cabin heat to maximum temperature and low fan speed using the climate controls.
• Watch for bubbles in the funnel as trapped air leaves the system.
• Let the engine warm until the upper radiator hose gets hot and the cooling fan cycles if conditions allow.
• Add coolant as the level drops.
• Use nitrile gloves and keep hands clear of belts and fans.

Step 16: Cap the System and Check for Leaks

• Shut the engine off.
• Use the stopper from the coolant funnel kit to remove the funnel without spilling coolant.
• Install the coolant reservoir cap by hand.
• Use a flashlight if available, or visually inspect around the thermostat housing and upper radiator hose for leaks.
• If you removed a splash shield, reinstall it using the plastic trim clip remover.

Step 17: Reinstall the Engine Cover

• Line up the engine cover with the rubber mounting points.
• Press straight down by hand until it seats firmly.

---

✅ After Repair

• ✅ Test drive your Edge for 10-15 minutes while watching the temperature gauge.
• 🌡️ The temperature should rise normally and stay steady near the middle of the gauge.
• 🔥 Confirm the heater blows warm air after the engine reaches operating temperature.
• 🔍 After the engine cools completely, recheck the coolant level in the reservoir and top off if needed.
• 💧 Recheck for leaks around the thermostat housing, upper radiator hose, and radiator drain area.
• ⚠️ If the temperature rises above normal, stop driving and shut the engine off. Air may still be trapped or another cooling system fault may be present.

---

💰 DIY vs Shop Cost

Shop Cost: $280-$520 (parts + labor)

DIY Cost: $45-$130 (parts only)

You Save: $235-$390 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.2-2.0 hours.

---
