🔧 Accord - Starter Motor Replacement

Replacing the starter motor on your Accord involves disconnecting the battery, removing access components, unplugging the starter wiring, and unbolting the starter from the transmission housing. The starter turns the engine over when you press the Start/Stop button, so a failing one can cause no-crank, clicking, or intermittent starting.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable before touching the starter wiring. The starter has a direct battery power cable.
• ⚠️ Let the engine cool fully. The starter area is near hot engine and exhaust components.
• ⚠️ Support your Accord securely with jack stands if raising the front. Never work under a car held only by a jack.
• ⚠️ Keep the key fob away from the vehicle while working so the ignition system cannot wake up unexpectedly.
• ⚠️ Avoid shorting the starter battery cable to metal. A short can cause sparks, burns, or wiring damage.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 17mm socket
• 3/8-inch ratchet
• 3/8-inch extension set
• Torque wrench 10-100 ft-lbs
• Flat-blade screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Battery terminal brush
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Starter motor - Qty: 1
• Battery terminal protectant - Qty: 1
• Replacement splash shield clips - Qty: As needed

---

📋 Before You Begin

• 🅿️ Park your Accord on level ground, shift to Park, and apply the parking brake.
• 🧱 Place wheel chocks behind the rear wheels.
• 🔑 Keep the key fob at least 15 feet away from the vehicle.
• 🔋 Open the hood and disconnect the negative battery cable using a 10mm socket.
• ⏱️ Wait at least 3 minutes after disconnecting the battery before working around main electrical cables.
• 📘 A “starter motor” is the small electric motor that cranks the engine so it can start running.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect the Battery

• Use a 10mm socket to loosen the negative battery terminal clamp.
• Lift the negative cable off the battery post and move it aside so it cannot spring back.
• Use a battery terminal brush to clean corrosion from the battery post if needed.
• Black cable comes off first.

Step 2: Raise and Support the Front

• Place wheel chocks behind the rear wheels.
• Use a floor jack rated 2-ton minimum at the front center jacking point.
• Set the vehicle onto jack stands rated 2-ton minimum at the front side support points.
• Gently shake the vehicle by hand to confirm it is stable before going underneath.

Step 3: Remove the Lower Splash Shield

• Use a trim clip removal tool to remove the plastic clips from the lower engine splash shield.
• Use a 10mm socket to remove any 10mm splash shield bolts.
• Lower the shield and set it aside.
• A trim clip tool is a small fork-shaped tool that lifts plastic clips without breaking them.

Step 4: Locate the Starter Motor

• From underneath, look near the lower front side of the engine where the engine meets the transmission.
• The starter is a small cylindrical motor with a thick battery cable and a smaller control wire attached.
• Use a flashlight if available, but do not use metal tools to probe the wires.

Step 5: Remove Starter Wiring

• Use a flat-blade screwdriver to gently lift the rubber cover from the large starter battery cable terminal.
• Use a 12mm socket to remove the nut holding the large battery cable to the starter.
• Pull the large cable straight off and position it away from the starter.
• Use needle-nose pliers or your fingers to release the lock tab on the small starter control connector.
• Unplug the small connector from the starter.
• Take a photo before unplugging wires.

Step 6: Remove the Starter Mounting Bolts

• Support the starter with one hand.
• Use a 14mm socket, 3/8-inch ratchet, and 3/8-inch extension to remove the starter mounting bolts.
• If one bolt is tighter or harder to reach, use a longer 3/8-inch extension for better angle.
• Slide the starter out of the transmission housing.
• Keep track of bolt locations if they are different lengths.

Step 7: Compare the Old and New Starter

• Place both starters side by side on a clean surface.
• Confirm the mounting ears, electrical terminals, and nose shape match.
• Do not install the new starter if the terminal layout or mounting shape is different.

Step 8: Install the New Starter

• Guide the new starter into position by hand.
• Start both mounting bolts by hand first to avoid cross-threading.
• Use a 14mm socket and torque wrench 10-100 ft-lbs to tighten the starter mounting bolts to Torque to 44 Nm (33 ft-lbs).
• Hand-start bolts before using tools.

Step 9: Reconnect Starter Wiring

• Push the small starter control connector onto the starter until it clicks.
• Install the large battery cable onto the starter terminal.
• Use a 12mm socket and torque wrench 10-100 ft-lbs to tighten the starter cable nut to Torque to 9 Nm (80 in-lbs).
• Reinstall the rubber protective cover over the large terminal.
• Make sure the cable does not touch sharp edges or moving parts.

Step 10: Reinstall the Lower Splash Shield

• Lift the splash shield back into place.
• Use a 10mm socket to reinstall the splash shield bolts.
• Tighten the splash shield bolts snugly to Torque to 9 Nm (80 in-lbs) if using a torque wrench.
• Use a trim clip removal tool or your fingers to reinstall the plastic clips.
• Replace any broken clips with replacement splash shield clips.

Step 11: Lower the Vehicle

• Use the floor jack rated 2-ton minimum to lift the front slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower the vehicle slowly to the ground.

Step 12: Reconnect the Battery

• Apply battery terminal protectant to the battery post if available.
• Install the negative battery cable onto the negative battery post.
• Use a 10mm socket to tighten the terminal clamp to Torque to 5 Nm (44 in-lbs).
• Do not overtighten the clamp. Battery terminals can crack.

---

✅ After Repair

• ✅ Sit in the driver seat, press the brake pedal, and start your Accord normally.
• ✅ Listen for smooth cranking. Grinding, spinning, or clicking means you should stop and recheck installation.
• ✅ Confirm the battery warning light turns off after the engine starts.
• ✅ Check that radio presets, clock, and driver window auto-up/down still work.
• ✅ If the driver window auto function does not work, fully lower the window, then fully raise it and hold the switch up for 2 seconds.
• ✅ Inspect underneath for loose splash shield clips or hanging wiring.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 (parts + labor)

DIY Cost: $180-$380 (parts only)

You Save: $270-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
