🔧 Forester - Serpentine Belt Replacement

The serpentine belt drives important accessories like the alternator, A/C compressor, and water pump-related accessory drive components on your Forester. Replacing it involves relieving tension from the automatic belt tensioner, removing the old belt, and routing the new belt correctly.

Difficulty Level: Beginner | Estimated Time: 0.5-1 hour

---

⚠️ Safety & Precautions

• ⚠️ Work only with the engine completely off and cool.
• ⚠️ Keep fingers, hair, clothing, and tools away from the belt path and pulleys.
• ⚠️ Disconnect the negative battery cable to prevent accidental starting while your hands are near the belt.
• ⚠️ Do not pry against plastic pulleys or aluminum brackets.
• ⚠️ Make sure the new belt is fully seated in every pulley groove before starting the engine.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm wrench
• 14mm serpentine belt tool (specialty)
• 14mm socket
• 3/8-inch drive ratchet
• Flashlight
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• 🅿️ Park your Forester on level ground and set the parking brake.
• ❄️ Let the engine cool fully before working near the belt and pulleys.
• 🔋 Use a 10mm wrench to loosen the negative battery terminal, then move the cable aside so it cannot touch the battery post.
• 💡 Take a clear photo of the belt routing before removing the old belt. This helps if the under-hood routing decal is hard to see.
• 🔎 A serpentine belt tool is a long, slim wrench that gives extra reach and leverage to move the spring-loaded belt tensioner.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the Belt and Routing Path

• Open the hood and use a flashlight to look at the front of the engine.
• Find the serpentine belt wrapped around the crankshaft pulley, alternator pulley, A/C compressor pulley, and idler/tensioner pulleys.
• Use your phone to take a photo of the belt routing before removal.
• Photo first, removal second.

Step 2: Find the Automatic Belt Tensioner

• Use a flashlight to locate the belt tensioner pulley near the front accessory drive.
• The tensioner is spring-loaded. It keeps the belt tight automatically.
• Look for the 14mm hex area or bolt head on the tensioner arm used to rotate it.

Step 3: Release Belt Tension

• Place the 14mm serpentine belt tool or 14mm socket with 3/8-inch drive ratchet onto the tensioner hex.
• Slowly rotate the tensioner to relieve belt tension.
• Hold the tensioner steady. Do not let it snap back.
• With your other hand, slide the belt off the easiest smooth pulley first, usually an idler pulley.
• Move slowly and protect your fingers.

Step 4: Remove the Old Belt

• Once the belt is off one pulley, slowly release the tensioner using the 14mm serpentine belt tool or 14mm socket and 3/8-inch drive ratchet.
• Remove the belt from the remaining pulleys by hand.
• Pull the old belt out from the engine bay.

Step 5: Inspect the Pulleys

• Use a flashlight to inspect each pulley.
• Spin accessible smooth pulleys by hand. They should turn smoothly without grinding, wobbling, or noise.
• Check grooved pulleys for debris, missing ribs, or oil contamination.
• If a pulley is noisy or loose, do not install the new belt until the pulley problem is fixed.

Step 6: Compare the New Belt to the Old Belt

• Lay the old and new serpentine belt side by side.
• Confirm the new belt has the same rib count and nearly the same length.
• A slightly shorter new belt is normal because the old belt stretches with age.

Step 7: Route the New Belt

• Install the new serpentine belt around the lower and harder-to-reach pulleys first.
• Follow your photo or the under-hood belt routing decal exactly.
• Leave the easiest upper smooth pulley for last.
• Make sure the ribbed side of the belt sits on grooved pulleys.
• Make sure the smooth side of the belt rides on smooth pulleys.

Step 8: Slip the Belt Over the Last Pulley

• Use the 14mm serpentine belt tool or 14mm socket with 3/8-inch drive ratchet to rotate the tensioner again.
• Slide the belt over the final pulley by hand.
• Slowly release the tensioner until it rests against the belt.
• Do not release the tensioner suddenly.

Step 9: Check Belt Seating

• Use a flashlight to inspect every pulley.
• Confirm all belt ribs are fully seated in the pulley grooves.
• The belt must not hang off the edge of any pulley.
• If the belt is misaligned, use the 14mm serpentine belt tool to relieve tension and reseat it.

Step 10: Reconnect the Battery

• Place the negative battery cable back on the battery post.
• Use a 10mm wrench to tighten the terminal snugly.
• Do not overtighten the battery terminal clamp.

Step 11: Start and Verify Operation

• Start the engine and let it idle.
• Use a flashlight to watch the belt from a safe distance.
• The belt should run smoothly with no wobble, squeal, slap, or edge walking.
• Shut the engine off immediately if the belt moves off-center or makes loud noise.

---

✅ After Repair

• ✅ Let the engine idle for 1-2 minutes, then shut it off and recheck belt seating.
• ✅ Turn the A/C on and listen for squealing or chirping.
• ✅ If the belt squeals, recheck routing and pulley alignment before driving.
• ✅ After the first short drive, open the hood and visually confirm the belt is still centered on all pulleys.
• ✅ If the battery was disconnected, reset the clock and any one-touch window settings if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$220 (parts + labor)

DIY Cost: $25-$60 (parts only)

You Save: $95-$160 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1 hour.

---
