🔧 1500 - Serpentine Belt Replacement

The serpentine belt drives important accessories on your 1500, including the alternator, A/C compressor, power steering system, and water pump drive system depending on equipment. Replacing it is a good DIY job if the belt is cracked, squealing, glazed, frayed, or stretched.

Difficulty Level: Beginner | Estimated Time: 30-60 minutes

---

⚠️ Safety & Precautions

• ⚠️ Work only with the engine completely off and cool.
• ⚠️ Keep fingers, hair, sleeves, and tools away from the belt path and pulleys.
• ⚠️ Do not bump the starter or crank the engine while the belt is removed.
• ⚠️ Battery disconnect is recommended for first-time DIYers: disconnect the negative battery cable before putting hands near the belt system.
• ⚠️ Take a photo of the belt routing before removal. This prevents mistakes during installation.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 3/8-inch drive serpentine belt tool
• 3/8-inch drive ratchet
• 15mm wrench
• 10mm socket
• 3/8-inch drive extension
• Flathead screwdriver
• Work light
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Serpentine belt - Qty: 1

---

📋 Before You Begin

• Park your 1500 on level ground.
• Shift to Park and set the parking brake.
• Let the engine cool fully before reaching near the belt area.
• Open the hood and use the hood prop or hood struts securely.
• Use a work light to view the front of the engine clearly.
• Take a clear photo of the belt routing before removing the old belt.
• If disconnecting the battery, use a 10mm socket to loosen the negative battery terminal and move the cable aside.
• A serpentine belt tool is a long, thin handle used to rotate the spring-loaded belt tensioner in tight spaces.
• The belt tensioner is the pulley arm with a spring inside it that keeps the belt tight automatically.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate the Belt Routing

• Use a work light to look at the front of the engine.
• Find the belt routing decal under the hood or near the radiator support if equipped.
• Use your phone to take a photo of the belt path around every pulley.
• If the decal is missing, use your photo and the old belt position as your guide.
• Photo first, remove second.

Step 2: Remove Any Intake Duct Obstruction

• If the air intake duct blocks access, use a flathead screwdriver to loosen the hose clamp.
• Use a 10mm socket if your clamp uses a 10mm screw head.
• Move the duct just enough to create hand clearance near the belt tensioner.
• Do not unplug sensors unless needed.

Step 3: Find the Belt Tensioner

• Use a work light to locate the spring-loaded tensioner pulley on the front of the engine.
• The tensioner has a pulley mounted to an arm and a square drive opening or bolt head for releasing tension.
• Check the new belt against the old belt before removal to make sure the length and rib count match.

Step 4: Release Belt Tension

• Install the 3/8-inch drive serpentine belt tool or 3/8-inch drive ratchet into the tensioner drive opening if equipped.
• If your tensioner uses a bolt-head style release point, use a 15mm wrench on the tensioner bolt head.
• Rotate the tensioner slowly to relieve pressure from the belt.
• Do not remove the tensioner bolt. You are only rotating the tensioner arm.
• Hold the tensioner steady while removing the belt from the easiest smooth pulley.
• Move slowly; spring pressure is strong.

Step 5: Remove the Old Belt

• While holding the tensioner released with the serpentine belt tool or 15mm wrench, slide the belt off one upper pulley.
• Slowly let the tensioner return to its resting position.
• Use your hands with mechanic gloves to pull the old belt out from around the remaining pulleys.
• Do not pry the belt off with sharp tools. This can damage pulley surfaces.

Step 6: Inspect the Pulleys

• Use your hand to spin the idler pulleys and tensioner pulley.
• Listen for grinding, squeaking, or roughness.
• Check that each grooved pulley is clean and not packed with rubber debris.
• Use a clean rag by hand if light debris is present.
• If a pulley wobbles or grinds, replace that pulley before installing the new belt.

Step 7: Route the New Belt

• Use your belt routing photo to place the new belt around the lower pulleys first.
• Make sure the ribbed side of the belt sits in ribbed pulleys.
• Make sure the smooth back side of the belt rides on smooth pulleys.
• Leave the easiest upper smooth pulley for last.
• Check that the belt sits fully inside every pulley groove before adding tension.

Step 8: Install the Belt Over the Final Pulley

• Use the 3/8-inch drive serpentine belt tool, 3/8-inch drive ratchet, or 15mm wrench to rotate the tensioner again.
• Slide the new belt over the final pulley by hand.
• Slowly release the tensioner until it tightens the belt.
• Do not let the tensioner snap back. Ease it back slowly.

Step 9: Verify Belt Alignment

• Use a work light to inspect every pulley.
• Confirm the belt ribs are centered in each grooved pulley.
• Confirm the belt is not hanging off the edge of any pulley.
• If the belt is off by even one rib, use the serpentine belt tool to release tension and reseat it.

Step 10: Reinstall Removed Intake Parts

• Reposition the air intake duct if it was moved.
• Use a flathead screwdriver or 10mm socket to tighten the hose clamp snugly.
• No high torque is needed for the hose clamp; tighten until secure and stop.

Step 11: Reconnect the Battery

• If the negative battery cable was disconnected, place it back on the negative battery post.
• Use a 10mm socket to tighten the terminal nut until snug.
• Do not overtighten the battery terminal.

Step 12: Start and Check Operation

• Start the engine and watch the belt from a safe distance.
• Use a work light to confirm the belt runs straight and smoothly.
• Listen for squealing, chirping, slapping, or rubbing noises.
• Turn the engine off immediately if the belt walks off a pulley or makes loud noise.

---

✅ After Repair

• Let the engine idle for 1-2 minutes while watching the belt from a safe distance.
• Turn the A/C on and listen for belt squeal.
• Turn the steering wheel gently left and right while parked to add accessory load.
• Shut the engine off and recheck belt alignment.
• After the first short drive, recheck that the belt is still centered on every pulley.
• If squealing continues with a new belt, inspect the tensioner and pulleys next.

---

💰 DIY vs Shop Cost

Shop Cost: $150-$300 USD equivalent, depending on local labor and belt brand

DIY Cost: $35-$90 USD equivalent for the belt only

You Save: $115-$210 by doing it yourself!

Shop labor rates vary by region. This repair takes a shop approximately 0.4-0.8 hours.

---
