🔧 Fusion - Radiator Hose Replacement

Replacing a radiator hose on your Fusion means draining some engine coolant, removing the old hose, installing the new hose, and refilling the cooling system. Radiator hoses carry hot coolant between the engine and radiator, so a weak, swollen, cracked, or leaking hose should be replaced before it causes overheating.

Assumption: This guide covers the upper or lower radiator hose replacement procedure. The lower hose may have tighter access from underneath.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant reservoir cap when the engine is hot. Hot coolant can spray out and cause burns.
• ⚠️ Let the engine cool completely before starting. Wait at least 2-3 hours after driving.
• ⚠️ Coolant is poisonous to people and pets. Keep it off the ground and store it in a sealed container.
• ⚠️ Support your Fusion with jack stands if you raise the front. Never work under a vehicle supported only by a jack.
• ⚠️ Battery disconnect is not normally required for this repair, but keep hands and tools away from the cooling fan area.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Drain pan, 2-gallon minimum
• Flat-blade screwdriver, medium
• Hose clamp pliers
• Slip-joint pliers, 10-inch
• Pick tool, 90-degree
• Ratcheting hose clamp pliers with cable (specialty)
• 8mm socket
• 10mm socket
• 3/8-inch drive ratchet
• 3/8-inch drive extension, 6-inch
• Torque wrench, inch-pound
• Funnel with long neck
• Trim clip removal tool
• Floor jack, rated 2-ton minimum
• Jack stands, rated 2-ton minimum
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Radiator hose - Qty: 1
• Radiator hose clamps - Qty: 2
• Motorcraft Orange-compatible coolant concentrate or premixed coolant - Qty: 1-2 gallons
• Distilled water - Qty: 1 gallon if using concentrate

---

📋 Before You Begin

• 🅿️ Park your Fusion on level ground and set the parking brake.
• ❄️ Let the engine cool fully before opening the cooling system.
• 🧰 A hose clamp is the metal band that squeezes the hose onto the fitting. Hose clamp pliers are made to squeeze and hold spring-style clamps safely.
• 🧪 Use the correct Ford-approved coolant type. Mixing incompatible coolants can cause sludge or cooling system problems.
• 🪣 Place a drain pan under the radiator area before loosening any hose.
• 🚗 If replacing the lower radiator hose, raise the front of your Fusion with a floor jack and support it with jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Cool the Engine and Remove the Coolant Cap

• Put on safety glasses and nitrile gloves.
• Make sure the engine is completely cool to the touch.
• Slowly loosen the coolant reservoir cap by hand to release any leftover pressure.
• Remove the cap and set it somewhere clean.
• Cold engine only.

Step 2: Raise the Front if Needed

• If replacing the lower hose, use a floor jack, rated 2-ton minimum to lift the front of your Fusion at the front jacking point.
• Place jack stands, rated 2-ton minimum under the approved support points.
• Gently lower the vehicle onto the jack stands and check that it is stable.
• If replacing only the upper hose, you may not need to raise the vehicle.

Step 3: Remove the Lower Splash Shield if Needed

• Use a trim clip removal tool to remove the plastic push clips from the lower splash shield.
• Use an 8mm socket, 3/8-inch drive ratchet, and 6-inch extension to remove any small shield screws.
• Lower the splash shield and set it aside.
• When reinstalling small splash shield screws later, tighten them snugly only. Do not overtighten plastic fasteners.

Step 4: Drain Some Coolant

• Place a drain pan, 2-gallon minimum under the radiator hose connection area.
• If accessible, loosen the radiator drain petcock by hand or with a flat-blade screwdriver, medium.
• If the drain petcock is not easy to access, leave it alone and drain coolant when the hose is loosened.
• Drain enough coolant so the hose level is below the coolant level. Usually 1-2 quarts is enough for the upper hose; more may drain from the lower hose.
• Close the drain petcock gently if opened. Do not force it.

Step 5: Locate the Radiator Hose Ends

• Use a shop towel to wipe around both hose ends so dirt does not fall into the cooling system.
• The upper radiator hose runs between the top area of the radiator and the engine coolant outlet.
• The lower radiator hose runs between the lower radiator area and the engine/water pump area.
• Look carefully at hose routing before removal. Take a phone photo if needed.

Step 6: Release the Hose Clamps

• Use hose clamp pliers or ratcheting hose clamp pliers with cable (specialty) to squeeze each spring clamp.
• Slide each clamp several inches back onto the hose.
• If the hose uses worm-drive clamps, use a flat-blade screwdriver, medium or 8mm socket to loosen the clamp screw.
• Do not crush plastic radiator fittings. They can become brittle with age.
• Move clamps before twisting hose.

Step 7: Break the Hose Loose

• Grip the hose near the end with slip-joint pliers, 10-inch and gently twist it back and forth.
• If the hose is stuck, use a pick tool, 90-degree to carefully lift the edge of the hose and break the seal.
• Do not stab or pry hard against the radiator neck or plastic coolant outlet.
• Once loose, pull the hose straight off the fitting by hand.

Step 8: Remove the Old Hose

• Use hose clamp pliers to move the second clamp back from the other end of the hose.
• Twist and pull the second end off by hand.
• Keep the drain pan, 2-gallon minimum under the hose because more coolant may spill.
• Compare the old hose to the new hose. The bends and length should match.

Step 9: Clean and Inspect the Fittings

• Use shop towels to clean the radiator and engine hose fittings.
• Inspect plastic fittings for cracks, soft spots, or broken lips.
• If a fitting is cracked, do not install the new hose until the damaged part is replaced.
• Make sure no old hose rubber is stuck to the fittings.

Step 10: Install the New Radiator Hose

• Slide the new radiator hose clamps onto the new radiator hose.
• Push one hose end fully onto the radiator fitting by hand.
• Push the other hose end fully onto the engine-side fitting by hand.
• Use hose clamp pliers to position each spring clamp behind the raised bead on the fitting.
• If using worm-drive clamps, tighten with a flat-blade screwdriver, medium or 8mm socket until snug. Torque to 3-4 Nm (27-35 in-lbs) if the clamp manufacturer allows torqueing.
• Do not overtighten worm-drive clamps on plastic fittings.

Step 11: Refill the Cooling System

• Place a funnel with long neck into the coolant reservoir.
• Add the correct Motorcraft Orange-compatible coolant mixture to the reservoir.
• If using concentrate, mix coolant and distilled water to a 50/50 ratio before filling.
• Fill to the cold fill line on the coolant reservoir.
• Install the coolant reservoir cap by hand.

Step 12: Warm the Engine and Check for Leaks

• Start the engine and let it idle.
• Set the cabin heat to full hot using the climate controls.
• Watch the hose ends closely with a flashlight if available.
• If you see a leak, shut the engine off and let it cool before adjusting the clamp.
• Let the engine reach normal operating temperature.

Step 13: Cool Down and Top Off

• Turn the engine off and let it cool fully.
• Remove the coolant reservoir cap by hand only after the system is cool.
• Use the funnel with long neck to top off the reservoir to the cold fill line.
• Reinstall the cap by hand.

Step 14: Reinstall the Splash Shield

• Raise the splash shield into place by hand.
• Use an 8mm socket, 3/8-inch drive ratchet, and 6-inch extension to reinstall the screws.
• Use a trim clip removal tool by hand to help align and reinstall plastic push clips.
• If using original small splash shield screws, tighten snugly only. Plastic underbody fasteners do not need heavy torque.

Step 15: Lower the Vehicle

• Use the floor jack, rated 2-ton minimum to lift the front slightly off the jack stands.
• Remove the jack stands, rated 2-ton minimum.
• Lower your Fusion slowly to the ground.

---

✅ After Repair

• ✅ Drive your Fusion for 10-15 minutes while watching the temperature gauge.
• ✅ After the engine cools completely, recheck the coolant level and top off if needed.
• ✅ Recheck the new hose ends for dried coolant stains or wetness.
• ✅ Dispose of old coolant properly at a recycling or hazardous waste facility. Do not pour it onto the ground or into drains.
• ✅ If the engine overheats, the heater blows cold, or the coolant level keeps dropping, stop driving and recheck for air pockets or leaks.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $35-$95 (parts only)

You Save: $145-$255 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
