🔧 Escape - Radiator Hose Replacement

On your Escape, radiator hoses carry coolant between the radiator and the engine. Replacing a leaking, swollen, or soft hose helps prevent overheating and coolant loss.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Never open the coolant cap hot—wait until fully cool.
• ⚠️ Support the vehicle with jack stands if you go underneath.
• ⚠️ Coolant is toxic—keep away from kids/pets and clean spills.
• ⚠️ Keep hands clear of cooling fans—they can turn on by themselves.
• ⚠️ Battery disconnect is not required, but keep tools away from the fan/shroud wiring.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan (at least 10-quart)
• Hose clamp pliers (specialty)
• Slip-joint pliers
• Pick tool (90-degree)
• Flat-blade screwdriver
• 7mm socket
• 8mm socket
• 1/4" ratchet
• 6" extension (1/4" drive)
• Trim clip removal tool
• Funnel
• Shop rags

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Upper radiator hose - Qty: 1
• Lower radiator hose - Qty: 1
• Radiator hose clamps - Qty: 2-4
• Engine coolant (Motorcraft-spec; verify type on reservoir/cap) - Qty: 1-2 gallons
• Distilled water - Qty: 1-2 gallons

---

📋 Before You Begin

• Park on level ground, set the parking brake, and let the engine cool completely.
• Place wheel chocks behind the rear wheels.
• Set your drain pan under the front of the vehicle.
• If you’re replacing the lower hose, plan to raise the front with a floor jack and support it on jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm which hose you’re replacing

• The upper radiator hose is typically the top hose going from the radiator to the engine area.
• The lower radiator hose is the lower hose running from the bottom of the radiator toward the engine.
• If you tell me “upper” or “lower,” I’ll tailor this.

Step 2: Relieve pressure safely

• Put on safety glasses and nitrile gloves.
• Place shop rags around the coolant reservoir cap (this is the degas bottle, meaning the pressurized coolant reservoir).
• Slowly loosen the cap by hand to release any remaining pressure, then remove it.

Step 3: Raise the front (recommended for lower hose access)

• Use a floor jack (rated 3-ton minimum) to lift the front at a safe jacking point.
• Set the vehicle down onto jack stands (rated 3-ton minimum).
• Give the vehicle a gentle push to confirm it’s stable.

Step 4: Remove the lower splash shield (if equipped)

• Use a 7mm socket, 8mm socket, and 1/4" ratchet to remove the shield fasteners.
• Use a trim clip removal tool for any push-clips.
• Set the shield and fasteners aside in a small pile.

Step 5: Drain coolant to below hose level

• Position the drain pan under the radiator lower area.
• If you can access the radiator drain, open it carefully using a flat-blade screwdriver (some drains are hand-turn; use only light force).
• If there is no easy drain access, you can drain by loosening the lower hose clamp slowly (next step) and letting coolant flow into the pan.
• Drain only what you need—less mess.

Step 6: Remove the hose clamps

• If you have spring-style clamps, squeeze them using hose clamp pliers (specialty) and slide the clamp back on the hose.
• If you have screw-style clamps, loosen them with a flat-blade screwdriver.
• Use shop rags to catch drips as you move clamps.

Step 7: Break the hose loose and remove it

• Twist the hose by hand to break the seal.
• If it’s stuck, gently work around the hose end with a pick tool (90-degree) to let air in and release it.
• Pull the hose off the fitting. Keep the hose pointed into the drain pan to control coolant flow.
• Do not pry hard on plastic fittings—they can crack.

Step 8: Prep the fittings and compare parts

• Use shop rags to wipe the radiator neck and engine-side neck clean.
• Compare the old hose to the new hose (shape, bends, and end sizes) before installing.
• Slide new radiator hose clamps onto the hose before pushing it on.

Step 9: Install the new radiator hose

• Push the hose fully onto each fitting until it bottoms out.
• Position spring clamps using hose clamp pliers (specialty) in the same spot as factory (behind the raised “bead” on the fitting).
• If using screw clamps, tighten with a flat-blade screwdriver until snug—do not crush the hose.

Step 10: Reinstall splash shield

• Reinstall the shield using a 7mm socket, 8mm socket, and 1/4" ratchet.
• Reinstall any push-clips using the trim clip removal tool as needed.

Step 11: Refill coolant

• Use a funnel to refill the degas bottle with the correct coolant mix.
• If you bought концентрат (concentrate), mix with distilled water to a 50/50 blend unless your coolant is pre-mixed.
• Fill to the “MAX” line (or slightly below) when cold.

Step 12: Bleed air (simple method) and check for leaks

• Start the engine and set the heater to high heat with the fan on medium.
• Let it idle and watch for leaks at both ends of the hose.
• As the engine warms up, the coolant level may drop—top off using the funnel.
• Shut the engine off, let it cool fully, then recheck level and add coolant as needed.

---

✅ After Repair

• Check for leaks after your first 10–15 minute drive.
• Recheck coolant level the next morning (cold) and top off to the cold “MAX” mark.
• Make sure the cabin heater blows hot—no heat can mean trapped air or low coolant.
• Dispose of old coolant properly (sealed container; do not pour on ground).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $40-$140 (parts only)

You Save: $210-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-2.0 hours.

---
