🔧 Highlander - Oxygen Sensor Replacement

This repair replaces a faulty oxygen/air-fuel ratio sensor in your Highlander’s exhaust system. On this hybrid V6, the upstream sensors help the engine computer adjust fuel mixture, while the downstream sensors monitor catalytic converter performance.

Assumption: This guide covers replacing one oxygen-related exhaust sensor after a diagnostic trouble code identifies the failed sensor location.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Exhaust parts get extremely hot. Let your Highlander cool for at least 2 hours before starting.
• ⚠️ Work on level ground only, with the parking brake applied and the wheels chocked.
• ⚠️ Use jack stands if raising the vehicle. Never rely on a floor jack alone.
• ⚠️ This is a hybrid vehicle. Do not touch orange high-voltage cables or hybrid components.
• ⚠️ Disconnect the 12-volt battery negative terminal before unplugging oxygen sensor wiring.
• ⚠️ Do not use impact tools on oxygen sensors. Exhaust bungs can be damaged.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8-inch ratchet
• 3/8-inch extension set
• 22mm oxygen sensor socket (specialty)
• 22mm crowfoot oxygen sensor wrench (specialty)
• Torque wrench 10-80 Nm
• Flat-blade screwdriver
• Trim clip removal tool
• Needle-nose pliers
• Penetrating oil
• OBD2 scan tool
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Mechanic gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Air-fuel ratio sensor upstream Bank 1 Sensor 1 - Qty: 1 if code identifies B1S1
• Air-fuel ratio sensor upstream Bank 2 Sensor 1 - Qty: 1 if code identifies B2S1
• Oxygen sensor downstream Bank 1 Sensor 2 - Qty: 1 if code identifies B1S2
• Oxygen sensor downstream Bank 2 Sensor 2 - Qty: 1 if code identifies B2S2
• Anti-seize compound rated for oxygen sensors - Qty: 1 small packet if not pre-applied
• Replacement wire retaining clips - Qty: As needed

---

📋 Before You Begin

• 📋 Park your Highlander on level ground, shift to Park, and set the parking brake.
• 📋 Let the exhaust cool completely before touching any sensor or exhaust pipe.
• 📋 Use an OBD2 scan tool to read the code and identify the sensor. “Bank 1” is the engine bank with cylinder 1; “Sensor 1” is before the catalytic converter, and “Sensor 2” is after the catalytic converter.
• 📋 If raising the front, use a floor jack rated 3-ton minimum and support the vehicle with jack stands rated 3-ton minimum.
• 📋 Disconnect the 12-volt battery negative cable using a 10mm socket. On this model, the 12-volt battery is in the rear cargo area.
• 📋 A 22mm oxygen sensor socket is a slotted socket that fits over the sensor wire while gripping the hex-shaped sensor body.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Read and Save the Trouble Code

• Use an OBD2 scan tool at the diagnostic port under the driver side dash.
• Write down the exact code before clearing anything.
• Common oxygen-related codes include P0136, P0137, P0138, P0141, P0156, P0157, P0158, P0161, P2195, or P2197.
• Do not replace a random sensor. Match the code to Bank 1/Bank 2 and Sensor 1/Sensor 2.
• Codes point to a circuit, not always the part.

Step 2: Power Down the Vehicle Safely

• Make sure the READY light is off.
• Remove the key fob from the vehicle area.
• Use a 10mm socket to loosen the 12-volt battery negative terminal nut.
• Remove the negative cable and position it so it cannot spring back onto the battery post.
• Wait 5 minutes before unplugging sensor connectors.

Step 3: Raise and Support the Vehicle if Needed

• Place wheel chocks behind the rear wheels if lifting the front.
• Use a floor jack rated 3-ton minimum at the front center lift point.
• Place jack stands rated 3-ton minimum under the front support points.
• Gently lower the vehicle onto the stands and shake the vehicle lightly to confirm it is stable.
• Wear safety glasses and mechanic gloves.

Step 4: Remove Any Lower Covers Blocking Access

• Use a 10mm socket to remove underbody cover bolts if the sensor is accessed from below.
• Use a trim clip removal tool or flat-blade screwdriver to remove plastic push clips.
• Set the clips and bolts aside in order so they go back in the same places.
• Torque underbody cover bolts to 5 Nm (44 in-lbs) during reassembly.

Step 5: Locate the Correct Sensor

• Use the saved code to locate the correct sensor before unplugging anything.
• Use a flashlight if available, but do not use a flame or torch around wiring.
• Sensor 1 means upstream, before the catalytic converter, and is usually called an air-fuel ratio sensor on Toyota systems.
• Sensor 2 means downstream, after the catalytic converter, and is the rear oxygen sensor.
• Follow the sensor wire from the exhaust pipe to its electrical connector.

Step 6: Unplug the Electrical Connector

• Use your fingers to press the connector lock tab.
• If stuck, use a flat-blade screwdriver gently to help release the lock tab.
• Use needle-nose pliers to release wire retaining clips from brackets if needed.
• Do not pull on the wires. Pull only on the connector body.
• Broken connector locks can cause repeat codes.

Step 7: Loosen the Old Sensor

• Spray penetrating oil on the sensor threads where it enters the exhaust pipe.
• Let it soak for 5-10 minutes.
• Place the 22mm oxygen sensor socket over the sensor wire and onto the sensor hex.
• Use a 3/8-inch ratchet and 3/8-inch extension set to turn the sensor counterclockwise.
• If access is tight, use a 22mm crowfoot oxygen sensor wrench with the 3/8-inch ratchet.
• Work slowly. If it feels like the exhaust threads are tearing, tighten slightly, add more penetrating oil, then loosen again.

Step 8: Remove the Old Sensor

• Once loose, turn the sensor by hand until it comes out.
• Keep the sensor wire from twisting around nearby parts.
• Compare the old sensor and new sensor side by side.
• The connector shape, wire length, and mounting style must match.

Step 9: Prepare the New Sensor

• Check the new sensor threads for anti-seize compound.
• If the threads are dry, apply a tiny amount of anti-seize compound rated for oxygen sensors only to the threads.
• Do not get anti-seize on the sensor tip.
• Do not touch the sensing tip with your fingers.
• Contamination can ruin a new sensor.

Step 10: Install the New Sensor

• Thread the new sensor into the exhaust by hand first.
• Turn it clockwise several turns by hand to avoid cross-threading.
• Use the 22mm oxygen sensor socket and torque wrench 10-80 Nm to tighten it.
• Torque to 44 Nm (32 ft-lbs).
• If using a 22mm crowfoot oxygen sensor wrench, keep the crowfoot at 90 degrees to the torque wrench handle for the most accurate reading.

Step 11: Route and Connect the Wiring

• Route the new sensor wire exactly like the original wire.
• Use needle-nose pliers to secure wire retaining clips into their brackets.
• Keep the wire away from the exhaust pipe, driveshaft, steering shaft, and sharp brackets.
• Push the electrical connector together until it clicks.
• Gently tug the connector body to confirm it is locked.

Step 12: Reinstall Covers and Lower the Vehicle

• Use a trim clip removal tool to align plastic clips if covers were removed.
• Use a 10mm socket to reinstall underbody cover bolts.
• Torque underbody cover bolts to 5 Nm (44 in-lbs).
• Use the floor jack rated 3-ton minimum to raise the vehicle slightly off the stands.
• Remove the jack stands rated 3-ton minimum, then lower the vehicle slowly.

Step 13: Reconnect the 12-Volt Battery

• Place the negative cable back on the 12-volt battery post.
• Use a 10mm socket to tighten the negative terminal nut.
• Torque to 5 Nm (44 in-lbs).
• Do not overtighten the small battery terminal.

Step 14: Clear Codes and Verify Operation

• Use the OBD2 scan tool to clear the stored code.
• Start your Highlander and confirm the Check Engine light stays off.
• Watch for exhaust leaks, rattles, or warning lights.
• Take a 10-15 minute road test with gentle acceleration and steady cruising.

---

✅ After Repair

• ✅ Recheck for pending codes with the OBD2 scan tool after the road test.
• ✅ If the same code returns immediately, inspect the connector, fuse, wiring, and exhaust leaks before replacing another sensor.
• ✅ Some emissions monitors need several drive cycles before showing “ready.” This is normal after codes are cleared.
• ✅ If the vehicle runs rough after battery reconnection, let it idle for a few minutes so the engine computer can relearn idle control.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$650 per sensor, depending on sensor location and labor access

DIY Cost: $80-$250 per sensor, parts only

You Save: $220-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
