🔧 Edge - Oxygen Sensor Replacement

This repair replaces a faulty oxygen sensor, also called an O2 sensor, which helps the engine computer adjust fuel mixture and emissions. Your Edge has multiple oxygen sensors, so the procedure below covers the common replacement process for either the upstream sensor near the turbo/exhaust manifold area or the downstream sensor after the catalytic converter.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

Assumption: Replace the sensor identified by your diagnostic trouble code, such as Bank 1 Sensor 1 or Bank 1 Sensor 2.

---

⚠️ Safety & Precautions

• ⚠️ Let the exhaust cool completely before touching the sensor; exhaust parts can cause severe burns.
• ⚠️ Support your Edge with jack stands if working underneath. Never rely on a floor jack alone.
• ⚠️ Disconnect the negative battery cable before unplugging the oxygen sensor wiring.
• ⚠️ Do not twist, stretch, or pull on the new sensor wiring harness.
• ⚠️ Avoid spraying penetrating oil onto hot exhaust parts.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 7/8-inch oxygen sensor socket (specialty)
• 3/8-inch drive ratchet
• 3/8-inch drive 6-inch extension
• 3/8-inch drive torque wrench
• 10mm socket
• Flathead screwdriver
• Trim clip removal tool
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Penetrating oil
• Mechanic gloves
• Safety glasses
• OBD2 scan tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Oxygen sensor - Qty: 1
• Anti-seize compound - Qty: 1 small packet

---

📋 Before You Begin

• Park your Edge on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear wheels if lifting the front.
• Use an OBD2 scan tool to read the fault code and identify the correct sensor location.
• Bank 1 Sensor 1 is the upstream oxygen sensor before the catalytic converter.
• Bank 1 Sensor 2 is the downstream oxygen sensor after the catalytic converter.
• Let the exhaust cool for at least 1 hour before starting.
• Disconnect the negative battery cable using a 10mm socket.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Read the Code and Confirm Sensor Position

• Use an OBD2 scan tool to read the stored engine code.
• Match the code to the correct oxygen sensor before removing anything.
• Common codes include P0130-P0135 for upstream sensor faults and P0136-P0141 for downstream sensor faults.
• Replace the coded sensor only.

Step 2: Disconnect the Battery

• Open the hood and locate the battery.
• Use a 10mm socket to loosen the negative battery terminal clamp.
• Move the negative cable aside so it cannot spring back onto the battery post.

Step 3: Raise and Secure the Vehicle if Needed

• If replacing the downstream sensor, place wheel chocks at the wheels that stay on the ground.
• Use a floor jack rated 3-ton minimum at the proper front jacking point.
• Set your Edge securely on jack stands rated 3-ton minimum.
• Gently shake the vehicle by hand to confirm it is stable before getting underneath.

Step 4: Remove Any Access Shielding

• Use a trim clip removal tool to remove plastic push clips from the lower splash shield if it blocks access.
• Use a flathead screwdriver to help release stubborn clips carefully.
• Set clips aside in order so they go back into the same locations.

Step 5: Locate the Oxygen Sensor

• For the upstream sensor, look near the turbocharger/exhaust manifold area at the front side of the engine bay.
• For the downstream sensor, look in the exhaust pipe after the catalytic converter from underneath.
• Follow the sensor wire to its electrical connector before loosening the sensor.
• An oxygen sensor socket is a deep socket with a slot cut in the side so the wire can pass through it.

Step 6: Unplug the Sensor Connector

• Press the lock tab on the connector by hand.
• Use a flathead screwdriver only if the lock tab is stuck, and pry gently.
• Do not pull on the wires. Pull on the plastic connector body only.
• Release the wiring from any clips using a trim clip removal tool.

Step 7: Loosen the Old Oxygen Sensor

• Spray a small amount of penetrating oil at the sensor threads where it enters the exhaust.
• Wait 5-10 minutes for the oil to work.
• Slide the 7/8-inch oxygen sensor socket over the sensor with the wire through the slot.
• Use a 3/8-inch drive ratchet and 3/8-inch drive 6-inch extension to turn the sensor counterclockwise.
• If it is very tight, apply steady pressure instead of jerking the ratchet.

Step 8: Remove the Old Sensor

• Once loose, unscrew the sensor by hand while wearing mechanic gloves.
• Compare the old sensor with the new oxygen sensor to confirm the connector and wire length match.
• Keep dirt and grease away from the sensing tip of the new sensor.

Step 9: Prepare the New Sensor

• If the new sensor does not already have anti-seize on the threads, apply a very thin coat of anti-seize compound to the threads only.
• Do not put anti-seize on the sensor tip or openings.
• Many new sensors come pre-coated; if so, do not add more.

Step 10: Install the New Oxygen Sensor

• Thread the new oxygen sensor into the exhaust by hand first.
• This prevents cross-threading, which means the threads start crooked and can damage the exhaust bung.
• Use the 7/8-inch oxygen sensor socket and 3/8-inch drive torque wrench to tighten it.
• Torque to 48 Nm (35 ft-lbs)

Step 11: Reconnect the Wiring

• Route the new sensor wire exactly like the old one.
• Keep the wire away from the exhaust pipe, turbocharger, steering shaft, and moving parts.
• Push the connector together until it clicks.
• Use the original wiring clips and a trim clip removal tool if needed to reseat harness retainers.

Step 12: Reinstall Access Shielding

• Reinstall the lower splash shield if removed.
• Push plastic clips in by hand.
• Use a flathead screwdriver only to help guide clips into place if needed.

Step 13: Lower the Vehicle and Reconnect Battery

• Use the floor jack rated 3-ton minimum to raise your Edge slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower the vehicle slowly with the floor jack.
• Reconnect the negative battery cable using a 10mm socket.
• Tighten the clamp snugly; do not over-tighten it.

---

✅ After Repair

• Use the OBD2 scan tool to clear the check engine light.
• Start the engine and let it idle for 2-3 minutes.
• Listen for exhaust leaks near the sensor. A leak may sound like ticking or puffing.
• Take a 10-15 minute test drive with gentle acceleration and steady cruising.
• Recheck for codes with the OBD2 scan tool.
• If the light returns, check the sensor connector, wiring route, and whether the correct sensor was replaced.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $190-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.5 hours.

---
