🔧 Colorado - Outer Tie Rod End Replacement

This repair replaces a worn outer tie rod end, which connects the steering rack to the front wheel knuckle and helps steer your Colorado. A bad tie rod end can cause loose steering, tire wear, clunking, or poor alignment.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours per side

---

⚠️ Safety & Precautions

• ⚠️ Support your Colorado with jack stands before working under or near the wheel area.
• ⚠️ Do not rely on a floor jack alone. A floor jack lifts the truck; jack stands hold it safely.
• ⚠️ Replace only one side at a time so you can compare parts and thread position.
• ⚠️ A wheel alignment is required after replacing a tie rod end to prevent tire wear and steering pull.
• ⚠️ Do not hammer directly on the steering knuckle threads or new tie rod stud.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 19mm socket
• 21mm socket
• 22mm wrench
• Adjustable wrench
• Ratchet
• Breaker bar
• Torque wrench (10-150 ft-lbs)
• Tie rod end puller (specialty)
• Needle-nose pliers
• Paint marker
• Tape measure
• Penetrating oil
• Wire brush
• Hammer
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Outer tie rod end - Qty: 1 per side
• New tie rod end castle nut - Qty: 1 per side
• New cotter pin - Qty: 1 per side
• Chassis grease - Qty: 1 tube if replacement part has grease fitting

---

📋 Before You Begin

• 🅿️ Park your Colorado on level ground and set the parking brake.
• 🧱 Place wheel chocks behind the rear wheels.
• 📏 Keep the steering wheel straight before lifting the truck.
• 🧴 Spray penetrating oil on the outer tie rod jam nut and tie rod stud nut, then let it soak for several minutes.
• 📌 A jam nut is the locking nut on the inner tie rod that keeps the outer tie rod end from turning out of adjustment.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Wheel Lug Nuts

• Use a 19mm socket and breaker bar to loosen the front lug nuts about 1/2 turn while the tire is still on the ground.
• Do not remove the lug nuts yet.
• Loose on ground, remove in air.

Step 2: Raise and Support the Front of the Truck

• Use a floor jack under the front crossmember to lift the front of your Colorado.
• Place jack stands under the approved front frame support points.
• Lower the truck gently onto the jack stands.
• Shake the truck lightly by hand to make sure it is stable before removing the wheel.

Step 3: Remove the Front Wheel

• Use a 19mm socket and ratchet to remove the lug nuts.
• Remove the wheel and place it flat under the frame area as an extra safety backup.

Step 4: Mark the Tie Rod Position

• Use a paint marker to mark where the outer tie rod end meets the jam nut.
• Use a tape measure to measure from the center of the tie rod stud to a fixed point on the inner tie rod.
• Write this measurement down. This helps keep the alignment close enough to drive to an alignment shop.
• This does not replace alignment.

Step 5: Loosen the Jam Nut

• Use a 22mm wrench on the jam nut.
• Hold the outer tie rod end with an adjustable wrench if it tries to turn.
• Turn the jam nut loose about 1/4 turn only. Do not spin it far down the inner tie rod.
• If the nut is rusty, clean the threads with a wire brush and apply penetrating oil.

Step 6: Remove the Cotter Pin

• Use needle-nose pliers to straighten and pull the cotter pin from the tie rod stud.
• A cotter pin is a small safety pin that keeps the castle nut from backing off.
• Discard the old cotter pin. Do not reuse it.

Step 7: Remove the Tie Rod Stud Nut

• Use a 21mm socket and ratchet to remove the castle nut from the outer tie rod stud.
• If the stud spins, apply upward pressure under the tie rod end with the tie rod end puller while loosening the nut.

Step 8: Separate the Tie Rod End from the Steering Knuckle

• Install the tie rod end puller over the tie rod stud and steering knuckle.
• Tighten the puller with the correct socket from your puller kit until the stud pops loose from the knuckle.
• A steering knuckle is the heavy metal part the wheel hub and steering parts attach to.
• If needed, tap the side of the steering knuckle lightly with a hammer while the puller is tight.
• Do not hit the threaded stud if you are trying to remove it cleanly.

Step 9: Count Turns and Remove the Old Tie Rod End

• Turn the old outer tie rod end counterclockwise by hand to remove it from the inner tie rod.
• Count the exact number of turns during removal.
• Write the number down.
• This helps install the new tie rod end close to the old position.

Step 10: Install the New Tie Rod End

• Thread the new outer tie rod end onto the inner tie rod by hand.
• Use the same number of turns you counted during removal.
• Line it up with your paint marker mark and measurement as closely as possible.
• Do not tighten the jam nut yet.

Step 11: Attach the Tie Rod End to the Steering Knuckle

• Insert the new tie rod stud into the steering knuckle by hand.
• Install the new castle nut by hand first so it does not cross-thread.
• Use a 21mm socket and torque wrench to tighten the tie rod stud nut to Torque to 50 Nm (37 ft-lbs).
• If the cotter pin hole does not line up, tighten the nut slightly more until the hole lines up. Do not loosen the nut to align the hole.
• Install the new cotter pin using needle-nose pliers, then bend the pin ends over the nut.

Step 12: Tighten the Jam Nut

• Hold the outer tie rod end steady with an adjustable wrench.
• Use a 22mm wrench to tighten the jam nut against the outer tie rod end.
• Tighten the jam nut securely to Torque to 75 Nm (55 ft-lbs).

Step 13: Grease the Tie Rod End if Required

• If the new tie rod end has a grease fitting, use a grease gun with chassis grease to add grease until the boot just begins to swell.
• A grease fitting is a small metal nipple where a grease gun attaches.
• Do not overfill the boot because it can split.

Step 14: Reinstall the Wheel

• Place the wheel back onto the hub.
• Install the lug nuts by hand first.
• Use a 19mm socket and ratchet to snug the lug nuts in a star pattern.

Step 15: Lower the Truck and Torque the Lug Nuts

• Use the floor jack to lift the truck slightly off the jack stands.
• Remove the jack stands.
• Lower the truck to the ground.
• Use a 19mm socket and torque wrench to tighten the lug nuts in a star pattern to Torque to 190 Nm (140 ft-lbs).

---

✅ After Repair

• ✅ Turn the steering wheel left and right while parked. Listen for rubbing, popping, or binding.
• ✅ Test drive slowly on a quiet road. The steering wheel may be slightly off-center until alignment is performed.
• ✅ Schedule a professional front wheel alignment as soon as possible.
• ✅ Recheck the lug nut torque after 25-50 miles using a 19mm socket and torque wrench.
• ✅ If the steering feels loose, pulls hard, or the truck wanders, stop driving and recheck the repair.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 per side including parts, labor, and alignment-related labor

DIY Cost: $35-$120 per side for parts only

You Save: $150-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-1.5 hours per side, plus alignment time.

---
