🔧 Battery Replacement

On your Explorer, the battery is under the hood. You’ll disconnect the old battery, remove the hold-down, swap in the new battery, and then reconnect everything in the correct order. This is a straightforward job, but correct cable order matters to avoid sparks and electrical issues.

Difficulty Level: Beginner | Estimated Time: 0.5-1 hour

---

⚠️ Safety & Precautions

• Ignition off, key out of the vehicle, and all accessories off before starting.
• Wear safety glasses and gloves. Battery acid and corrosion can burn skin and eyes.
• Do not let tools touch both battery posts at once. That can short the battery.
• Remove the negative cable first and reconnect it last.
• If your battery has a vent tube, transfer it to the new battery if equipped.
• No battery disconnect programming is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm wrench
• 13mm socket
• Ratchet
• Extension
• Battery terminal puller (specialty)
• Battery brush
• Safety glasses
• Mechanic gloves
• Memory saver (optional specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V battery - Qty: 1
• Battery terminal protectant spray - Qty: 1
• Battery terminal cleaning brush - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Make sure the ignition is fully off.
• Open the hood and locate the battery in the engine bay.
• If you use a memory saver, connect it before disconnecting the battery.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the negative battery cable

• Use a 10mm wrench to loosen the negative terminal clamp.
• Lift the negative cable off the battery post and tuck it aside so it cannot spring back.
• Negative first, always.

Step 2: Remove the positive battery cable

• Use a 10mm wrench to loosen the positive terminal clamp.
• Remove the positive cable and keep it away from metal parts.

Step 3: Remove the battery hold-down

• Use a 13mm socket, ratchet, and extension to remove the battery hold-down bracket or clamp.
• Set the hardware aside in order so it goes back the same way.

Step 4: Lift out the old battery

• Carefully lift the battery straight up and out of the tray. Batteries are heavy, so use both hands.
• If there is corrosion in the tray, clean it before installing the new battery.

Step 5: Clean the terminals and tray

• Use a battery brush to clean the cable ends and the battery posts area.
• Wipe the tray clean and make sure nothing is loose in the battery compartment.

Step 6: Install the new battery

• Place the new battery into the tray in the same orientation as the old one.
• Reinstall the hold-down bracket using a 13mm socket and ratchet.
• Torque to 8 N·m (71 in-lbs).

Step 7: Reconnect the positive cable

• Install the positive cable onto the positive post first.
• Use a 10mm wrench to tighten the clamp.
• Torque to 5 N·m (44 in-lbs).

Step 8: Reconnect the negative cable

• Install the negative cable onto the negative post last.
• Use a 10mm wrench to tighten the clamp.
• Torque to 5 N·m (44 in-lbs).

Step 9: Finish up

• Apply a light coat of battery terminal protectant spray to help slow corrosion.
• Close the hood and make sure the battery is secure.

---

✅ After Repair

• Start the engine and confirm it cranks normally.
• Check for warning lights on the dash.
• Reset any clock or radio settings if needed.
• If a window auto-up/down or steering angle feature acts odd, cycle the ignition and recheck operation.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $140-$260 (parts only)

You Save: $110-$190 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1 hour.

---
