🔧 Edge - 12V Battery Replacement

This repair replaces the 12-volt starting battery in your Edge. A weak or failed battery can cause slow cranking, warning lights, no-start issues, and electrical glitches.

Difficulty Level: Beginner | Estimated Time: 30-60 minutes

---

⚠️ Safety & Precautions

• ⚠️ Wear safety glasses and gloves. Car batteries contain acid and can release explosive gas.
• ⚠️ Always remove the negative cable first and install it last. This reduces the chance of an electrical short.
• ⚠️ Do not let metal tools touch the positive terminal and any body metal at the same time.
• ⚠️ The battery is heavy. Lift with both hands and keep it upright.
• ⚠️ Battery management reset is required after replacement so the charging system learns the new battery.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 8mm socket
• Ratchet wrench
• 6-inch extension
• Battery terminal puller (specialty)
• Battery terminal cleaning brush
• Battery carrier strap
• Memory saver 12V OBD-II adapter (specialty)
• OBD-II scan tool with Ford BMS reset capability (specialty)
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 12V AGM battery - Qty: 1
• Battery terminal anti-corrosion protectant - Qty: 1
• Battery terminal felt washers - Qty: 2

---

📋 Before You Begin

• Park your Edge on level ground, shift to Park, and set the parking brake.
• Turn off all lights, climate controls, radio, and accessories.
• Open the hood and keep the key at least 10 feet away from the vehicle.
• If using a memory saver, plug the memory saver 12V OBD-II adapter into the diagnostic port under the driver side dash before disconnecting the battery. A memory saver supplies low power to keep radio presets and module memory alive.
• The battery is located under the hood on the driver side, near the firewall area.
• Use an AGM replacement battery if your Edge is equipped with the factory AGM battery. AGM means Absorbent Glass Mat, a sealed battery type used by many modern vehicles.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open the hood and inspect the battery area

• Use your hands to release the hood latch and raise the hood fully.
• Put on safety glasses and nitrile gloves.
• Look for white or green crust on the battery terminals. This is corrosion and can irritate skin.
• Take a phone photo first.

Step 2: Remove the battery cover or access panel

• Use your hands to remove the battery cover if fitted.
• If a fastener is present, use an 8mm socket with a ratchet wrench to remove it.
• Set the cover and fastener aside where they will not fall into the engine bay.

Step 3: Disconnect the negative battery cable

• Find the negative terminal. It is marked with a minus sign - and usually has a black cable.
• Use a 10mm socket with a ratchet wrench to loosen the negative terminal clamp nut.
• Lift the negative cable off the battery post by hand.
• If it is stuck, use the battery terminal puller (specialty). A terminal puller gently lifts the clamp without cracking the battery post.
• Move the negative cable aside so it cannot spring back and touch the battery.

Step 4: Disconnect the positive battery cable

• Find the positive terminal. It is marked with a plus sign + and usually has a red cover.
• Lift the red protective cover by hand.
• Use a 10mm socket with a ratchet wrench to loosen the positive terminal clamp nut.
• Lift the positive cable off the battery post by hand.
• If needed, use the battery terminal puller (specialty) to remove it carefully.
• Keep the positive cable away from metal body parts.

Step 5: Remove the battery hold-down clamp

• Look at the lower front edge of the battery tray for the hold-down clamp. This clamp locks the battery in place.
• Use an 8mm socket, 6-inch extension, and ratchet wrench to remove the hold-down bolt.
• Remove the hold-down clamp by hand and set it aside.

Step 6: Remove the old battery

• Attach the battery carrier strap to the battery if it does not have a built-in handle.
• Lift the battery straight up and out using both hands.
• Keep the battery upright. Do not tip it.
• Place it on cardboard or a stable surface away from children and pets.

Step 7: Clean the battery tray and cable terminals

• Use the battery terminal cleaning brush to clean the inside of both cable clamps.
• Use the same battery terminal cleaning brush to clean the battery tray contact area if needed.
• If there is heavy corrosion, avoid breathing dust and do not touch it with bare hands.
• Clean metal improves starting.

Step 8: Install the new battery

• Use the battery carrier strap to lower the new 12V AGM battery into the tray.
• Make sure the positive and negative posts are in the same positions as the old battery.
• Push the battery fully down and seat it squarely in the tray.

Step 9: Reinstall the hold-down clamp

• Place the hold-down clamp back at the lower edge of the battery.
• Use an 8mm socket, 6-inch extension, and ratchet wrench to tighten the hold-down bolt.
• Torque to 9 Nm (80 in-lbs).
• Try to wiggle the battery by hand. It should not move.

Step 10: Connect the positive cable first

• Install one battery terminal felt washer onto the positive battery post.
• Place the positive cable clamp fully down onto the positive post.
• Use a 10mm socket with a ratchet wrench to tighten the clamp nut.
• Torque to 5 Nm (44 in-lbs).
• Close the red protective cover by hand.

Step 11: Connect the negative cable last

• Install one battery terminal felt washer onto the negative battery post.
• Place the negative cable clamp fully down onto the negative post.
• Use a 10mm socket with a ratchet wrench to tighten the clamp nut.
• Torque to 5 Nm (44 in-lbs).
• Apply battery terminal anti-corrosion protectant to both terminals after tightening.

Step 12: Reinstall the battery cover or access panel

• Reinstall the battery cover by hand.
• If it uses a fastener, use an 8mm socket with a ratchet wrench to snug it down.
• Do not overtighten small plastic fasteners.

Step 13: Reset the Battery Monitoring System

• Use an OBD-II scan tool with Ford BMS reset capability (specialty). OBD-II is the diagnostic connector under the driver side dash.
• Connect the scan tool to the OBD-II port.
• Turn the ignition on without starting the engine.
• Select the Ford service function for Battery Monitoring System Reset or BMS Reset.
• Follow the scan tool prompts until the reset is complete.
• If your scan tool asks for battery type, select AGM if an AGM battery was installed.

---

✅ After Repair

• Start your Edge and make sure it cranks normally.
• Check that the battery warning light turns off after the engine starts.
• Set the clock, radio presets, and window auto-up/down if they lost memory.
• To relearn the power windows, fully lower each front window, then fully raise it and hold the switch up for 2 seconds.
• Drive normally for 10-15 minutes so the charging system can stabilize.
• Recycle the old battery at a parts store or battery recycler. Do not put it in household trash.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $170-$300 (parts only)

You Save: $80-$150 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
