🔧 Ridgeline - Battery Replacement

Replacing the battery involves disconnecting the negative and positive cables, removing the hold-down bracket, and lifting the battery from the engine compartment. Your Ridgeline does not require battery registration or programming after replacement.

Difficulty Level: Beginner | Estimated Time: 30-45 minutes

---

⚠️ Safety & Precautions

• 🧤 Wear gloves and safety glasses. A battery contains corrosive acid and can release flammable gas.
• 🚫 Keep sparks, cigarettes, and open flames away from the battery.
• ⚡ Always disconnect the negative terminal first and reconnect it last.
• 🔧 Never allow a tool to touch the positive terminal and body metal simultaneously.
• 🏋️ The battery is heavy. Use a battery carrier strap and lift with both hands.
• 🔌 Do not pry against or strike the battery sensor attached to the negative cable.
• 🔋 Battery disconnection is required. Some saved settings may be erased.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8-inch-drive ratchet
• 3/8-inch-drive 6-inch extension
• 3/8-inch-drive inch-pound torque wrench
• Battery terminal cleaning brush
• Battery carrier strap
• Plastic trim brush
• Safety glasses
• Acid-resistant work gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Group 24F 12-volt automotive battery, minimum 550 CCA - Qty: 1
• Battery terminal protectant spray - Qty: 1

---

📋 Before You Begin

• 🅿️ Park your Ridgeline on level ground, select Park, apply the parking brake, and open the hood.
• 🔑 Switch off the ignition, remove the key from the vehicle, and turn off every electrical accessory.
• ⏱️ Wait at least three minutes before disconnecting the battery so the vehicle’s electronic modules can shut down.
• 🪟 Lower the driver’s window before disconnecting power so you cannot accidentally lock yourself out.
• 📦 Confirm the replacement is a Group 24F battery with the positive and negative posts in the correct positions.
• 🔌 No scan tool, security code entry, or battery registration is required.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Locate and inspect the battery

• Put on the safety glasses and acid-resistant work gloves.
• Locate the battery on the driver’s side of the engine compartment.
• Check for a cracked case, leaking fluid, or badly swollen sides. Do not handle a leaking or frozen battery; have it professionally removed.

Step 2: Disconnect the negative cable

• Use the 10mm socket and 3/8-inch-drive ratchet to loosen the negative terminal clamp marked “−”.
• Twist the clamp gently and lift it straight off the battery post. Do not pull on the cable or strike the battery sensor.
• Move the cable aside where it cannot spring back onto the post.
• Negative comes off first and goes on last.

Step 3: Disconnect the positive cable

• Open the red positive-terminal cover.
• Use the 10mm socket and 3/8-inch-drive ratchet to loosen the positive terminal clamp marked “+”.
• Lift the clamp straight off and position it away from the battery post.
• Keep the ratchet from contacting body metal while it touches the positive clamp.

Step 4: Remove the battery hold-down

• Use the 10mm socket, 3/8-inch-drive 6-inch extension, and 3/8-inch-drive ratchet to loosen the two hold-down nuts evenly.
• Unhook the hold-down rods and remove the upper bracket. A hold-down is the bar that prevents the battery from moving.
• Place the bracket and rods where they cannot fall into the engine compartment.

Step 5: Remove the old battery

• Attach the battery carrier strap securely. This strap grips the battery and provides safer lifting handles.
• Lift the battery straight upward without tipping it. Keep it upright because liquid electrolyte may be present inside.
• Place it upright on a stable surface away from children and pets.

Step 6: Clean and inspect the mounting area

• Use the plastic trim brush to remove dry dirt and debris from the battery tray.
• Use the battery terminal cleaning brush to clean corrosion from the cable clamps.
• Inspect the tray, hold-down rods, cables, and clamps for damage. Replace damaged hardware before installing the battery.

Step 7: Install the replacement battery

• Use the battery carrier strap to lower the Group 24F battery into the tray with the terminals facing the same direction as the original battery.
• Make sure the battery sits flat and does not trap either cable underneath it.
• Remove the carrier strap after the battery is fully seated.

Step 8: Install the hold-down bracket

• Position the upper bracket and engage both hold-down rods correctly in the battery tray.
• Use the 10mm socket, 3/8-inch-drive 6-inch extension, and 3/8-inch-drive inch-pound torque wrench to tighten the nuts evenly.
• Torque the battery hold-down nuts to 4.4 Nm (39 in-lbs).
• Check that the battery cannot slide or rock. Do not overtighten the bracket because the battery case can crack.

Step 9: Connect the positive cable

• Push the positive clamp completely down onto the positive post.
• Use the 10mm socket and 3/8-inch-drive inch-pound torque wrench to tighten the clamp nut.
• Torque the positive terminal nut to 6 Nm (53 in-lbs).
• Apply a light coating of battery terminal protectant spray around the outside of the connected clamp. Do not spray between the post and clamp.
• Close the red positive-terminal cover.

Step 10: Connect the negative cable

• Push the negative clamp completely down onto the negative post without twisting or stressing the battery sensor.
• Use the 10mm socket and 3/8-inch-drive inch-pound torque wrench to tighten the clamp nut.
• Torque the negative terminal nut to 6 Nm (53 in-lbs).
• Apply a light coating of battery terminal protectant spray around the outside of the connected clamp.

Step 11: Restore the driver’s window auto function

• Start the engine and close the driver’s door.
• Use the driver’s window switch to lower the window completely.
• Pull the switch upward until the window closes completely, then continue holding it for at least two seconds.
• Check that one-touch automatic lowering and closing work normally.

---

✅ After Repair

• ✅ Start the engine and verify that it cranks normally.
• 🔍 Confirm that the charging-system warning light turns off after the engine starts.
• 🧪 Switch on the headlights and climate-control blower to verify stable electrical operation.
• 🕒 Reset the clock, audio presets, and other personalized settings if they were erased.
• 🚗 Turn the steering wheel from center to near full left and right, then take a short drive if stability-system warning lights remain illuminated. They should clear after the systems relearn.
• ♻️ Return the old battery upright to a battery retailer or authorized recycler. Do not place it in household trash.

---

💰 DIY vs Shop Cost

Shop Cost: ₹14,000-₹24,000 (parts + labor)

DIY Cost: ₹10,000-₹19,000 (parts only)

You Save: ₹4,000-₹5,000 by doing it yourself!

Pricing around Sonīpat can vary because Group 24F batteries for a U.S.-market Ridgeline may require specialty sourcing. This repair takes a shop approximately 0.3-0.5 hour.

---
