🔧 Forester - A/C Compressor Replacement

Replacing the A/C compressor on your Forester requires recovering the refrigerant, removing the drive belt, disconnecting the A/C lines, swapping the compressor, then vacuuming and recharging the system. The A/C system must be opened carefully because moisture or dirt can damage the new compressor.

Difficulty Level: Advanced | Estimated Time: 3-5 hours

---

⚠️ Safety & Precautions

• ⚠️ Refrigerant must be professionally recovered before opening the system; do not vent refrigerant into the air.
• ⚠️ Wear safety glasses and gloves because refrigerant can cause frostbite on skin or eyes.
• ⚠️ Disconnect the negative battery terminal before unplugging the compressor electrical connector.
• ⚠️ Keep dirt and moisture out of open A/C lines; cap the lines immediately after removal.
• ⚠️ If the old compressor failed internally, the condenser/receiver-drier and expansion valve may also need replacement, and the lines must be flushed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 14mm socket
• 3/8-inch drive ratchet
• 3/8-inch drive extension set
• Torque wrench 5-80 Nm
• Serpentine belt tool 14mm
• Flat-blade screwdriver
• Plastic trim clip remover
• A/C line disconnect caps set
• A/C manifold gauge set R-134a
• Vacuum pump 2-stage A/C service
• Refrigerant recovery machine R-134a (specialty)
• Digital refrigerant scale
• PAG oil measuring cup
• Safety glasses
• Nitrile gloves
• Fender cover

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• A/C compressor with clutch assembly - Qty: 1
• A/C compressor O-ring seal kit - Qty: 1
• PAG 46 refrigerant oil - Qty: As needed
• R-134a refrigerant - Qty: 16.9 oz / 480 g
• A/C condenser with receiver-drier - Qty: 1 if compressor failed internally
• A/C expansion valve - Qty: 1 if compressor failed internally
• Serpentine drive belt - Qty: 1 if worn, cracked, or oil-contaminated

---

📋 Before You Begin

• Park your Forester on level ground, shift to Park, set the parking brake, and let the engine cool completely.
• Have the R-134a refrigerant professionally recovered using a recovery machine before loosening any A/C line.
• A manifold gauge set reads high-side and low-side A/C pressure so you can evacuate and recharge the system correctly.
• A vacuum pump removes air and moisture from the A/C system before refrigerant is added.
• Disconnect the negative battery cable using a 10mm socket and move it where it cannot touch the battery post.
• Compare the new compressor to the old one before installation: pulley, electrical connector, mounting ears, and line ports must match.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Recover the Refrigerant

• Use the refrigerant recovery machine R-134a (specialty) and A/C manifold gauge set R-134a to recover the refrigerant from the high-side and low-side service ports.
• Confirm both gauges read 0 psi before opening the A/C system.
• Never vent refrigerant.

Step 2: Disconnect the Battery

• Use a 10mm socket to loosen the negative battery terminal clamp.
• Lift the negative cable off the battery and secure it away from the post.

Step 3: Remove the Engine Under Cover if Needed

• Use a plastic trim clip remover to remove the lower splash shield clips if you need extra belt access from below.
• Use a 10mm socket to remove any under-cover bolts.
• Set the clips and bolts aside in order so they go back into the same locations.

Step 4: Remove the Serpentine Drive Belt

• Locate the belt tensioner at the front of the engine.
• Use a serpentine belt tool 14mm or 14mm socket with ratchet to rotate the tensioner and release belt tension.
• Slide the belt off the A/C compressor pulley, then slowly release the tensioner.
• If reusing the belt, note the belt routing before removal.
• Take a photo first.

Step 5: Unplug the A/C Compressor Connector

• Press the lock tab on the compressor electrical connector by hand.
• If the tab is tight, use a flat-blade screwdriver gently to help release it.
• Move the wiring harness away from the compressor so it cannot be pulled or pinched.

Step 6: Disconnect the A/C Lines from the Compressor

• Use a 10mm socket or 12mm socket to remove the A/C suction and discharge line retaining bolts at the compressor.
• Carefully pull the line blocks straight away from the compressor ports.
• Use the A/C line disconnect caps set to cap the open lines and compressor ports immediately.
• Remove and discard the old O-rings from the line fittings.
• Do not reuse O-rings.

Step 7: Remove the Old Compressor

• Support the compressor by hand so it does not drop when the bolts are removed.
• Use a 12mm socket or 14mm socket with a 3/8-inch drive ratchet and 3/8-inch drive extension set to remove the compressor mounting bolts.
• Lift the compressor out of the engine bay carefully without bending the A/C lines.

Step 8: Check Compressor Oil Amount

• Drain the oil from the old compressor into a PAG oil measuring cup by turning the compressor ports downward and rotating the pulley by hand.
• Drain the shipping oil from the new compressor into a clean PAG oil measuring cup.
• Add the same amount of clean PAG 46 refrigerant oil to the new compressor that came out of the old compressor, unless the compressor supplier instructions specify a different pre-filled amount.
• Rotate the new compressor clutch plate by hand 10-15 turns to distribute the oil.

Step 9: Install the New Compressor

• Position the new compressor onto the engine bracket.
• Start all mounting bolts by hand to avoid cross-threading.
• Use a 12mm socket or 14mm socket to snug the mounting bolts evenly.
• Use a torque wrench 5-80 Nm to tighten the compressor mounting bolts to Torque to 25 Nm (18 ft-lbs).

Step 10: Reconnect the A/C Lines

• Lightly coat the new O-rings with clean PAG 46 refrigerant oil.
• Install the new O-rings onto the A/C line fittings by hand.
• Remove the caps and seat each A/C line block squarely onto the compressor port.
• Use a 10mm socket or 12mm socket to install the line retaining bolts.
• Use a torque wrench 5-80 Nm to tighten the A/C line bolts to Torque to 8 Nm (71 in-lbs).

Step 11: Reconnect the Compressor Electrical Connector

• Push the electrical connector onto the compressor until the lock clicks.
• Gently tug the connector by hand to confirm it is locked in place.

Step 12: Reinstall the Serpentine Belt

• Route the belt around the pulleys using your photo or belt routing diagram.
• Use the serpentine belt tool 14mm or 14mm socket to rotate the tensioner.
• Slide the belt over the A/C compressor pulley, then slowly release the tensioner.
• Check that the belt ribs sit fully inside every pulley groove.
• Misaligned belts shred quickly.

Step 13: Reinstall the Under Cover

• Raise the lower splash shield into position by hand.
• Use a plastic trim clip remover to reinstall the clips without bending them.
• Use a 10mm socket to reinstall any under-cover bolts.
• Use a torque wrench 5-80 Nm to tighten small under-cover bolts to Torque to 5 Nm (44 in-lbs).

Step 14: Evacuate the A/C System

• Connect the A/C manifold gauge set R-134a to the high-side and low-side service ports.
• Connect the center hose to the vacuum pump 2-stage A/C service.
• Open both manifold valves and run the vacuum pump for at least 30-45 minutes.
• Close both valves and turn the pump off.
• Watch the gauges for 10-15 minutes; vacuum should hold steady. If vacuum drops, there is a leak that must be fixed before charging.

Step 15: Recharge the A/C System

• Use the digital refrigerant scale to charge the system with R-134a refrigerant.
• Charge by weight: 16.9 oz / 480 g of R-134a.
• Start charging through the low-side port with the engine off until flow slows.
• Reconnect the negative battery cable using a 10mm socket and tighten the clamp snugly.
• Start the engine, set A/C to MAX COOL, blower high, and continue charging through the low side only until the specified weight is reached.
• Do not add extra refrigerant. Overcharging can damage the compressor.

---

✅ After Repair

• ✅ Let the engine idle with A/C on MAX COOL for 5-10 minutes.
• ✅ Check that the compressor clutch engages smoothly and does not chatter.
• ✅ Check the A/C line fittings for oily residue or hissing, which can indicate a leak.
• ✅ Confirm cold air from the center vents; typical vent temperature should drop noticeably within a few minutes depending on outside temperature.
• ✅ Recheck belt tracking while the engine is running; the belt should run straight and quiet.
• ✅ If the compressor failed internally, do not skip condenser/receiver-drier and expansion valve replacement, or the new compressor can fail quickly.

---

💰 DIY vs Shop Cost

Shop Cost: $1,000-$1,700 (parts + labor + refrigerant service)

DIY Cost: $350-$850 (parts only, not including recovery equipment rental/service)

You Save: $500-$900 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-4 hours.

---
