🔧 AC Compressor - Replacement

Assumption: This guide covers the belt-driven AC compressor and related seal service on your Equinox. Because the refrigerant must be recovered with equipment, this is best handled with proper A/C recovery gear or by a shop before opening the system.

The compressor is the heart of the A/C system. Replacing it means removing the drive belt, disconnecting refrigerant lines, swapping the compressor, and then evacuating and recharging the system with the correct oil and refrigerant.

Difficulty Level: Advanced | Estimated Time: 4-6 hours

---

⚠️ Safety & Precautions

• Do not open the A/C system until the refrigerant has been properly recovered.
• Refrigerant can cause frostbite and eye injury.
• Keep the engine off and cool before working near the belt drive.
• Disconnect the negative battery cable before unplugging compressor electrical connectors.
• Use jack stands if you need access from underneath.
• Replace all disturbed O-rings and add the correct A/C compressor oil.
• After repair, the system must be evacuated and recharged to specification.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Metric socket set
• Ratchet
• Extensions
• Serpentine belt tool
• Torque wrench
• Line wrench set
• Trim clip tool
• Drain pan
• Safety glasses
• Nitrile gloves
• Jack and jack stands
• A/C recovery, vacuum, and recharge machine (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• AC compressor - Qty: 1
• AC compressor oil - Qty: 1 bottle
• AC line O-ring kit - Qty: 1
• Serpentine belt - Qty: 1
• Receiver drier or accumulator - Qty: 1
• AC system refrigerant - Qty: 1 charge

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Let the engine cool fully.
• Recover the refrigerant with proper A/C equipment before opening the system.
• Disconnect the negative battery cable.
• Keep dirt out of the open lines. Cap every opening right away.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Recover refrigerant and disconnect power

• Use the A/C recovery, vacuum, and recharge machine to remove the refrigerant from the system.
• Disconnect the negative battery cable using a 10mm socket.
• Wait a few minutes before touching any electrical connectors.

Step 2: Remove the drive belt

• Use the serpentine belt tool to release belt tension.
• Slip the belt off the compressor pulley and remove it from the engine bay.
• Take a photo of the belt route first.

Step 3: Access the compressor

• If needed, raise the front of the vehicle with a jack and support it on jack stands.
• Remove any splash shields or covers with a metric socket set and trim clip tool.
• Clean the area around the compressor lines before opening anything.

Step 4: Disconnect the compressor

• Unplug the compressor electrical connector by hand.
• Use a line wrench set to remove the refrigerant line fittings.
• Remove the old O-rings and keep dirt out of the open ports.

Step 5: Remove the compressor

• Use a metric socket set and ratchet to remove the compressor mounting bolts.
• Support the compressor as you remove the last bolt.
• Lift the compressor out carefully.

Step 6: Prepare the replacement compressor

• Drain and measure the oil from the old compressor if possible.
• Add the correct amount and type of AC compressor oil to the new compressor.
• Install new O-rings and lightly lubricate them with clean A/C oil.

Step 7: Install the new compressor

• Set the new compressor in place by hand.
• Install the mounting bolts with a metric socket set and tighten to factory specification.
• Reconnect the refrigerant lines with a line wrench set and tighten to factory specification.
• Reconnect the electrical connector.
• Do not overtighten aluminum fittings.

Step 8: Reinstall the belt and covers

• Install the new serpentine belt using the serpentine belt tool.
• Make sure the belt sits fully in every pulley groove.
• Reinstall splash shields and covers with a metric socket set and trim clip tool.

Step 9: Evacuate and recharge the system

• Use the A/C recovery, vacuum, and recharge machine to pull a deep vacuum.
• Leak test the system during vacuum hold.
• Recharge with the exact refrigerant amount listed on the underhood label.
• Use the correct refrigerant type for your Equinox.

---

✅ After Repair

• Start the engine and turn the A/C on max.
• Check that the compressor engages smoothly.
• Verify cold air at the vents.
• Look for oil or refrigerant leaks at the line fittings.
• Listen for belt noise or pulley wobble.
• Recheck cooling performance after a short test drive.

---

💰 DIY vs Shop Cost

Shop Cost: $900-$1,700 (parts + labor)

DIY Cost: $250-$700 (parts only)

You Save: $650-$1,000 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 4-6 hours.

---
