🔧 Explorer - A/C Compressor Replacement

This is an advanced repair, and the refrigerant must be professionally recovered before you loosen any A/C line. Once the system is empty, replacing the compressor involves removing the lower covers, releasing the drive belt, disconnecting the refrigerant manifold, and removing the compressor from below.

Your Explorer uses R-134a refrigerant and Ford-specification PAG compressor oil. Because the Platinum has front and rear climate control, the published total system capacities are 2.8 lb (1.27 kg) of R-134a and 7.3 fl oz (216 ml) of oil. Those are total-system capacities, not automatic refill amounts after changing only the compressor. fordservicecontent.com

Difficulty Level: Advanced | Estimated Time: 4-6 hours plus recovery and recharge

---

⚠️ Safety & Precautions

• ⚠️ Have a certified A/C shop recover the refrigerant before opening the system. Ford warns that the refrigerant is under high pressure and can cause injury. fordservicecontent.com
• 🧊 Escaping liquid refrigerant can cause severe frostbite and permanent eye injury.
• 🚫 Never vent R-134a into the atmosphere or use a charging hose to release pressure.
• 🛡️ Wear safety glasses and refrigerant-resistant gloves whenever the system is open.
• 🔋 Disconnect the negative battery cable after refrigerant recovery.
• 🏗️ Support your Explorer with jack stands. Never work beneath a vehicle supported only by a jack.
• 🔥 Keep refrigerant and oil away from flames, sparks, and hot exhaust components.
• 🧼 If the old compressor failed internally and produced metal debris, replacing only the compressor can ruin the new one. The condenser and expansion components may require replacement, and the remaining lines and evaporators must be professionally cleaned.

---

🔧 Required Tools

You'll need the following tools for this repair:

• R-134a recovery machine (specialty)
• R-134a manifold gauge set (specialty)
• A/C vacuum pump rated below 500 microns (specialty)
• Electronic refrigerant scale accurate to 0.1 oz (specialty)
• Metric socket set, 8mm-15mm
• Metric combination wrench set, 8mm-15mm
• 3/8-inch drive ratchet
• 3/8-inch drive 3-inch extension
• 3/8-inch drive torque wrench, 10-80 ft-lbs
• 1/4-inch drive inch-pound torque wrench
• Serpentine-belt tensioner tool (specialty)
• Trim-clip removal tool
• Plastic A/C line caps and plugs
• Drain pan, 2-quart minimum
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Refrigerant-resistant gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• A/C compressor - Qty: 1
• A/C compressor manifold O-rings - Qty: 1 set
• Ford-specification PAG refrigerant compressor oil - Qty: As measured
• R-134a refrigerant - Qty: Charged by weight
• Serpentine drive belt - Qty: 1 if worn, cracked, glazed, or contaminated
• A/C receiver-drier or desiccant component - Qty: 1 if required by the compressor warranty
• A/C expansion valve components - Qty: As required after internal compressor failure

Important: Don’t choose the oil amount by total system capacity. Measure the oil removed from the old compressor and follow the new compressor manufacturer’s oil-balancing instructions.

---

📋 Before You Begin

• 🅿️ Park on level pavement, select Park, apply the parking brake, and chock the rear wheels.
• ❄️ Have the complete R-134a charge recovered with an approved recovery machine.
• 🔎 Confirm the failure before buying parts. A pressure-sensor fault, wiring problem, low charge, clutch issue, or control-module command can imitate a failed compressor.
• 🔋 Use a metric wrench to disconnect the negative battery terminal after recovery.
• 📸 Photograph the belt routing and compressor electrical connector before disassembly.
• 🧽 Clean dirt from around both compressor refrigerant connections so contamination cannot enter the system.
• 📋 Keep the replacement compressor’s instructions nearby. Its oil-balancing and warranty requirements take priority.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Recover the Refrigerant

• Connect an R-134a recovery machine to the high- and low-side service ports.
• Recover the complete charge according to the machine instructions.
• Confirm that both gauges remain at zero before disconnecting the equipment.
• Do not continue if system pressure returns. Refrigerant may remain trapped in the system.

Step 2: Disconnect the Battery

• Switch the ignition off and keep the key away from the vehicle.
• Use the matching wrench from the 8mm-15mm combination wrench set to loosen the negative battery terminal.
• Remove and isolate the negative cable so it cannot spring back onto the terminal.

Step 3: Raise and Support the Explorer

• Place the 3-ton floor jack under the approved front lifting point.
• Raise the front and position the 3-ton jack stands under the approved support points.
• Lower the vehicle onto the stands and gently test its stability.
• Use the trim-clip removal tool and matching socket to remove the lower splash shield and access panels.

Step 4: Release the Drive Belt

• Compare the belt routing with your photograph or the routing diagram in the engine compartment.
• Fit the serpentine-belt tensioner tool onto the tensioner.
• Rotate the tensioner only in its normal release direction and slide the belt off the compressor pulley.
• Release the tensioner slowly. Don’t let it snap against its stop.
• Inspect the belt for cracks, missing ribs, glazing, oil contamination, or frayed edges.
• Draw the belt path before removing it.

Step 5: Disconnect the Compressor Wiring

• Release the locking tab by hand and unplug the compressor electrical connector.
• Inspect the terminals for heat damage, corrosion, loose fit, or compressor-oil contamination.
• Move the harness away from the compressor without stretching it.

Step 6: Disconnect the Refrigerant Manifold

• Place the 2-quart drain pan below the compressor connections.
• Use the matching socket from the 8mm-15mm socket set to remove the refrigerant-manifold retaining fastener.
• Carefully pull the manifold straight away from the compressor. Don’t bend or pry against the aluminum lines.
• Remove and discard both old O-rings.
• Immediately seal the open lines with plastic A/C line caps and plugs.
• Do not reuse the old O-rings.

Step 7: Remove the Old Compressor

• Support the compressor with one hand or a stable support.
• Use the matching socket, 3/8-inch ratchet, and 3-inch extension to remove the accessible mounting bolts.
• Remove the remaining mounting bolts while supporting the compressor’s weight.
• Lower the compressor carefully through the available lower opening.
• Keep it upright until its oil is measured.

Step 8: Inspect for Internal Failure

• Pour the old compressor oil into a clean measuring container.
• Inspect the oil under bright light for gray paste, glitter, aluminum particles, or black contamination.
• If metal is present, stop the installation. The condenser, receiver-drier or desiccant, and expansion devices require inspection or replacement.
• Never flush a replacement compressor, accumulator, receiver-drier, or expansion device.
• Metal glitter means the system needs more work.

Step 9: Prepare the New Compressor

• Keep the shipping plugs installed while positioning the new compressor.
• Check the compressor manufacturer’s instructions to determine whether it arrives dry or prefilled.
• Use only oil meeting Ford specification WSH-M1C231-B. Ford identifies this as PAG refrigerant compressor oil. fordservicecontent.com
• Balance the oil according to the measured amount removed and the compressor instructions. Don’t pour the full 7.3 fl oz system capacity into the compressor.
• Turn the compressor hub by hand approximately ten complete revolutions after the correct oil amount is installed.

Step 10: Install the New Compressor

• Lift the compressor into position and start every mounting bolt by hand.
• Use the matching socket and 3/8-inch ratchet to seat the bolts evenly.
• Use the 3/8-inch torque wrench to tighten the mounting bolts to the current Ford service specification for the exact bolt locations.
• Do not guess the torque. Thread size and attachment points can differ, and an incorrect value can damage the aluminum housing.

Step 11: Reconnect the A/C Lines

• Remove the line caps only when you’re ready to connect the manifold.
• Coat the new correct-size O-rings lightly with the specified PAG oil.
• Install the O-rings without twisting, stretching, or using petroleum grease.
• Push the manifold squarely against the compressor and start its fastener by hand.
• Use the inch-pound torque wrench to tighten the manifold fastener to the current Ford service specification.
• Reconnect the electrical connector until its lock clicks.

Step 12: Reinstall the Belt

• Route the belt around every pulley according to the original diagram.
• Use the serpentine-belt tensioner tool to rotate the tensioner and place the belt over the final pulley.
• Release the tensioner slowly.
• Check every pulley and confirm each belt rib sits completely inside its matching groove.

Step 13: Reassemble the Lower Covers

• Use the matching socket and trim-clip removal tool to reinstall the splash shields, fasteners, and clips.
• Replace damaged clips rather than leaving the shield loose.
• Raise the vehicle slightly with the 3-ton floor jack, remove the stands, and lower it fully.

Step 14: Evacuate and Leak-Test the System

• Reconnect the battery negative cable with the matching wrench.
• Connect the R-134a manifold gauge set and vacuum pump.
• Evacuate the system until the equipment reaches a deep, stable vacuum.
• Continue evacuation long enough to remove moisture, then isolate the system and perform a vacuum-decay test.
• If vacuum rises, locate and repair the leak before charging.

Step 15: Recharge by Weight

• Place the refrigerant container on the electronic refrigerant scale.
• Charge only with R-134a. Ford specifies this refrigerant for your Explorer. fordservicecontent.com
• For the factory front-and-rear climate system, charge to 2.8 lb (1.27 kg) unless the under-hood refrigerant label states otherwise. The vehicle label is the final authority. fordservicecontent.com
• Follow the recovery machine’s procedure to prevent liquid refrigerant from entering the compressor through the low side.

---

✅ After Repair

• ✅ Start the engine and let it idle with the climate control off for approximately one minute.
• ❄️ Select MAX A/C, set the blower to medium, and open the doors or windows.
• 👀 Watch the belt and compressor for wobble, slipping, or abnormal noise.
• 🔎 Leak-check both compressor line connections and the service ports with an electronic leak detector.
• 🌡️ Verify that front and rear vent temperatures drop and remain stable.
• 📊 Confirm that high- and low-side pressures respond normally for the outdoor temperature and humidity.
• 🛑 Shut the engine off immediately if the compressor knocks, binds, smokes, or causes severe belt movement.
• 🧾 Record the refrigerant weight, oil quantity, and replaced components for future service.

---

💰 DIY vs Shop Cost

Shop Cost: $1,100-$2,000 (parts, labor, recovery, and recharge)

DIY Cost: $450-$900 (parts plus professional recovery and recharge)

You Save: Approximately $400-$1,000 by doing the mechanical work yourself!

Local labor rates vary. This repair generally takes a shop approximately 3-5 hours, with additional time if contamination is found.

---
