🔧 TITAN - Spark Plug Replacement

Replacing the spark plugs on your TITAN helps restore smooth idle, strong acceleration, and proper fuel economy. The 5.6L V8 uses eight coil-on-plug ignition coils, meaning each spark plug has its own ignition coil sitting directly above it.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work only on a completely cool engine. Spark plugs thread into aluminum cylinder heads, and hot aluminum threads can be damaged easily.
• ⚠️ Disconnect the negative battery cable before unplugging ignition coils.
• ⚠️ Do not force a spark plug. Cross-threading can damage the cylinder head.
• ⚠️ Do not use anti-seize on modern coated spark plug threads unless the plug manufacturer specifically requires it.
• ⚠️ Replace one plug at a time so dirt does not sit in open spark plug wells.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 12mm socket
• 5/8-inch spark plug socket
• 3/8-inch drive ratchet
• 3/8-inch drive torque wrench
• 3-inch 3/8-inch drive extension
• 6-inch 3/8-inch drive extension
• 3/8-inch drive universal joint
• Flat-blade screwdriver
• Needle-nose pliers
• Compressed air blow gun
• Spark plug gap gauge
• Dielectric grease
• Fender cover
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs - Qty: 8
• Throttle body gasket - Qty: 1, if throttle body is removed for access
• Intake duct clamp or hose clamp - Qty: As needed, only if damaged

---

📋 Before You Begin

• Park your TITAN on level ground and let the engine cool fully.
• Set the parking brake and keep the key away from the vehicle.
• Open the hood and install a fender cover to protect the paint.
• Use a 10mm socket to disconnect the negative battery cable.
• A spark plug socket has a rubber insert or magnet that holds the plug so it does not fall into the engine bay.
• A universal joint lets the socket bend slightly so you can reach angled plugs.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Cover

• Use both hands to lift the plastic engine cover upward from its rubber mounting grommets.
• Set the cover aside where it will not get stepped on.
• Pull straight up gently.

Step 2: Disconnect the Negative Battery Cable

• Use a 10mm socket to loosen the negative battery terminal nut.
• Lift the negative cable off the battery post and move it aside so it cannot spring back.

Step 3: Remove Intake Ducting for Access

• Use a flat-blade screwdriver or 10mm socket to loosen the air intake tube clamps.
• Use needle-nose pliers to release any small hose clamps attached to the intake tube.
• Unplug any intake air sensor connector by pressing the lock tab and pulling straight back.
• Remove the intake duct and set it aside.
• If more room is needed on the passenger side, use a 10mm socket to remove nearby intake resonator or bracket fasteners.

Step 4: Locate the Ignition Coils

• Your TITAN has eight ignition coils, one on top of each spark plug.
• Each coil has an electrical connector and a small retaining bolt.
• Work on one cylinder at a time to avoid mixing parts or leaving plug holes open.

Step 5: Clean Around the First Coil

• Put on safety glasses.
• Use a compressed air blow gun to clear dust and grit from around the ignition coil and spark plug well.
• This prevents debris from falling into the cylinder after the plug is removed.

Step 6: Remove the Ignition Coil

• Press the ignition coil connector lock tab and unplug the connector by hand.
• Use a 10mm socket to remove the ignition coil retaining bolt.
• Twist the coil gently by hand, then pull it straight upward.
• Inspect the rubber boot for oil, cracking, swelling, or carbon tracking, which looks like a thin black lightning mark.

Step 7: Remove the Old Spark Plug

• Place a 5/8-inch spark plug socket on a 6-inch extension and 3/8-inch drive ratchet.
• Lower the socket straight into the spark plug well until it seats fully on the plug.
• Turn counterclockwise slowly to loosen the plug.
• If the plug feels stuck, tighten it slightly, then loosen again gently.
• Remove the spark plug from the well using the spark plug socket.
• Slow and straight prevents thread damage.

Step 8: Check the New Spark Plug

• Use a spark plug gap gauge to verify the new plug gap is correct for the replacement plug specification.
• Do not pry on the fine iridium center electrode.
• Do not apply anti-seize unless the spark plug manufacturer specifically says to.

Step 9: Install the New Spark Plug by Hand

• Place the new spark plug into the 5/8-inch spark plug socket.
• Use only the extension by hand at first, without the ratchet.
• Turn clockwise gently until the plug threads in smoothly.
• If it does not turn easily, remove it and start again.
• Once seated, attach the 3/8-inch drive torque wrench.
• Tighten the spark plug to Torque to 19.6 Nm (14 ft-lbs).

Step 10: Reinstall the Ignition Coil

• Apply a small amount of dielectric grease inside the end of the ignition coil boot.
• Push the coil straight down onto the spark plug until it fully seats.
• Use a 10mm socket to install the ignition coil retaining bolt.
• Tighten the ignition coil bolt snugly to Torque to 7 Nm (62 in-lbs).
• Reconnect the ignition coil electrical connector until it clicks.

Step 11: Repeat for the Remaining Seven Spark Plugs

• Repeat Steps 5 through 10 for each remaining ignition coil and spark plug.
• Use the 3-inch extension, 6-inch extension, and universal joint as needed for tighter rear cylinders.
• Take your time on the rear plugs near the firewall.
• One plug at a time is safest.

Step 12: Reinstall Intake Ducting

• Reinstall the intake duct into its original position.
• Use a flat-blade screwdriver or 10mm socket to tighten the intake tube clamps.
• Reconnect any intake air sensor connectors until they click.
• Use needle-nose pliers to reinstall any hose clamps you removed.
• If the throttle body was removed, install a new throttle body gasket and use a 10mm socket to tighten the throttle body bolts evenly to Torque to 8 Nm (71 in-lbs).

Step 13: Reconnect the Battery and Reinstall Cover

• Use a 10mm socket to reconnect the negative battery cable.
• Tighten the battery terminal nut snugly.
• Push the engine cover back down onto its rubber mounting grommets by hand.

---

✅ After Repair

• Start your TITAN and let it idle for a few minutes.
• Listen for a smooth idle and check that there are no warning lights.
• If the idle is slightly high after intake work, let the engine warm up and idle normally for several minutes.
• Take a short test drive and confirm smooth acceleration.
• Recheck the intake duct clamps after the test drive to make sure there are no loose air leaks.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 parts + labor

DIY Cost: $90-$180 parts only

You Save: $300-$600 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
