🔧 CR-V - Spark Plug Replacement

Replacing the spark plugs on your CR-V helps restore smooth starts, clean idle, fuel economy, and proper turbo engine performance. The 1.5L turbo engine uses four ignition coils, one on top of each spark plug, and the job is very manageable if you work slowly and keep dirt out of the plug wells.

Difficulty Level: Beginner | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool completely before starting; aluminum cylinder heads can be damaged if plugs are removed hot.
• ⚠️ Disconnect the negative battery cable to prevent accidental ignition coil activation.
• ⚠️ Keep dirt, sand, and debris out of the spark plug wells so nothing falls into the engine.
• ⚠️ Do not overtighten spark plugs; the cylinder head threads are aluminum and can strip.
• ⚠️ Do not apply anti-seize unless the spark plug manufacturer specifically requires it; most modern plugs are pre-coated.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8-inch ratchet
• 3/8-inch 6-inch extension
• 14mm thin-wall spark plug socket
• 3/8-inch torque wrench rated 10-50 Nm
• Flat trim tool
• Compressed air blow gun
• Spark plug gap gauge
• Needle-nose pliers
• Clean shop towels
• Dielectric grease
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs - Qty: 4

---

📋 Before You Begin

• Park your CR-V on level ground, shift to Park, and set the parking brake.
• Let the engine cool for at least 1 hour if it was recently driven.
• Open the hood and remove loose debris from the top of the engine.
• Disconnect the negative battery cable using a 10mm socket. A negative battery cable is the black cable marked “-”.
• Only replace one spark plug at a time so the ignition coils go back in the same positions.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Cover

• Put on safety glasses and nitrile gloves.
• Grip the plastic engine cover with both hands and pull straight upward.
• If it feels stuck, use a flat trim tool gently near the rubber mounting points.
• Set the cover aside where it will not get stepped on.
• Pull upward, not sideways.

Step 2: Locate the Ignition Coils

• Look across the top of the engine for four black ignition coils.
• An ignition coil is the small electrical part that sits directly above each spark plug.
• Each coil has an electrical connector and one hold-down bolt.

Step 3: Disconnect the First Ignition Coil Connector

• Start with one coil at the end of the engine.
• Press the locking tab on the connector with your thumb.
• If the connector is tight, use needle-nose pliers gently on the connector body, not the wires.
• Pull the connector straight back from the ignition coil.
• Never pull on the wires.

Step 4: Remove the First Ignition Coil

• Use a 10mm socket, 3/8-inch ratchet, and 3/8-inch 6-inch extension to remove the coil hold-down bolt.
• Twist the ignition coil slightly by hand to loosen the rubber boot.
• Pull the coil straight upward and out of the spark plug well.
• Place the coil in a clean area in the same order it was removed.

Step 5: Clean the Spark Plug Well

• Use a compressed air blow gun to blow dirt out of the spark plug well.
• A spark plug well is the deep tube where the spark plug sits.
• Use clean shop towels around the area to catch loosened debris.
• Do not skip this step; dirt can fall into the cylinder when the plug is removed.

Step 6: Remove the Old Spark Plug

• Install the 14mm thin-wall spark plug socket on the 3/8-inch 6-inch extension and 3/8-inch ratchet.
• A thin-wall spark plug socket is a narrow socket that fits into the tight plug well and grips the spark plug.
• Lower the socket straight down onto the spark plug.
• Turn counterclockwise slowly to loosen the spark plug.
• Once loose, spin it out by hand using the extension.
• Lift the old spark plug out carefully.
• Keep the socket straight.

Step 7: Check the New Spark Plug

• Use a spark plug gap gauge to verify the gap on the new plug.
• A gap gauge measures the small space at the firing tip of the spark plug.
• The correct spark plug gap for your CR-V is 0.7-0.8 mm.
• Do not force-adjust fine-wire iridium plugs unless absolutely necessary; the tips are delicate.
• Confirm the new plug is clean, dry, and undamaged.

Step 8: Install the New Spark Plug by Hand

• Place the new spark plug into the 14mm thin-wall spark plug socket.
• Lower it straight into the spark plug well using the 3/8-inch 6-inch extension.
• Turn the extension clockwise by hand only for several turns.
• If it does not turn easily, stop and restart the threads.
• Cross-threading means the plug is going in crooked and can damage the engine threads.
• Hand-start every plug first.

Step 9: Torque the New Spark Plug

• Attach the 3/8-inch torque wrench rated 10-50 Nm to the 14mm thin-wall spark plug socket and 3/8-inch 6-inch extension.
• Tighten the spark plug carefully.
• Torque to 22 Nm (16 ft-lbs).
• Stop as soon as the torque wrench clicks.

Step 10: Reinstall the Ignition Coil

• Apply a very small dab of dielectric grease inside the end of the coil boot.
• Dielectric grease is a non-conductive silicone grease that helps seal the rubber boot from moisture.
• Slide the ignition coil straight down onto the new spark plug.
• Press until you feel it seat fully.
• Install the coil hold-down bolt using a 10mm socket, 3/8-inch 6-inch extension, and 3/8-inch torque wrench rated 10-50 Nm.
• Torque to 12 Nm (9 ft-lbs).

Step 11: Reconnect the Ignition Coil Connector

• Push the electrical connector straight onto the ignition coil by hand.
• Listen and feel for a click from the locking tab.
• Use needle-nose pliers only if needed, and only on the connector body.

Step 12: Repeat for the Remaining Spark Plugs

• Repeat Steps 3 through 11 for the other three spark plugs.
• Use the 10mm socket, 3/8-inch ratchet, 3/8-inch 6-inch extension, 14mm thin-wall spark plug socket, and 3/8-inch torque wrench rated 10-50 Nm the same way for each plug.
• Work one cylinder at a time to avoid mixing parts.

Step 13: Reinstall the Engine Cover

• Line up the engine cover with its rubber mounting points.
• Press straight down by hand until it seats securely.
• Use clean shop towels to wipe off any fingerprints or grease from the engine cover.

Step 14: Reconnect the Battery

• Reconnect the negative battery cable.
• Use a 10mm socket and 3/8-inch ratchet to snug the terminal clamp.
• Torque to 5 Nm (44 in-lbs).
• Do not overtighten the battery terminal.

---

✅ After Repair

• ✅ Start the engine and let it idle for 1-2 minutes.
• ✅ The idle may be slightly uneven for a few seconds after the battery was disconnected.
• ✅ Listen for ticking, popping, or misfire sounds.
• ✅ Make sure the check engine light stays off.
• ✅ Take a short test drive with gentle acceleration first.
• ✅ Recheck that all four ignition coil connectors are fully clicked in place.
• ✅ If the power window auto-up feature needs relearning, close the window fully and hold the switch up for 2 seconds.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$380 (parts + labor)

DIY Cost: $55-$120 (parts only)

You Save: $165-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
