🔧 1500 - Spark Plug Replacement

Replacing the spark plugs on your 1500 helps restore smooth idle, fuel economy, and proper ignition performance. The 3.6L V6 uses six spark plugs, and access is fairly tight because the upper intake manifold must be removed.

Difficulty Level: Intermediate | Estimated Time: 2.5-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool completely before starting. Hot aluminum threads can be damaged easily.
• ⚠️ Disconnect the negative battery cable before removing ignition components.
• ⚠️ Your 1500 has a mild-hybrid eTorque system. Do not touch orange high-voltage wiring or hybrid components.
• ⚠️ Keep dirt, bolts, and tools out of the intake ports once the upper intake manifold is removed.
• ⚠️ Do not use an impact tool on spark plugs. Use hand tools only to avoid cylinder head damage.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 8mm socket
• 5/8-inch spark plug socket
• 3/8-inch drive ratchet
• 3/8-inch drive torque wrench
• 3-inch extension
• 6-inch extension
• Plastic trim removal tool
• Needle-nose pliers
• Flathead screwdriver
• Magnetic pickup tool
• Compressed air blow gun
• Spark plug gap gauge
• Clean shop towels
• Masking tape
• Permanent marker
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Spark plugs - Qty: 6
• Upper intake manifold gaskets - Qty: 1 set
• Throttle body gasket - Qty: 1
• Dielectric grease - Qty: 1 tube

---

📋 Before You Begin

• Park your 1500 on level ground and set the parking brake.
• Open the hood and let the engine cool fully.
• Disconnect the negative battery cable with a 10mm socket.
• Use masking tape and a permanent marker to label connectors and hoses as you remove them.
• A spark plug socket is a deep socket with a rubber insert or magnet that grips the spark plug so it does not fall.
• A torque wrench tightens bolts to an exact tightness so parts are not damaged.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Cover

• Use both hands to lift the plastic engine cover straight up from the rubber mounting posts.
• If it feels stuck, use a plastic trim removal tool to gently help release the cover.
• Set the cover aside where it will not be stepped on.
• Pull upward, not sideways.

Step 2: Disconnect the Air Intake Tube

• Use a flathead screwdriver or 8mm socket to loosen the clamp at the throttle body.
• Use the same tool to loosen the clamp at the air filter box side.
• Disconnect any small breather hose attached to the intake tube using needle-nose pliers if the clamp is spring-loaded.
• Remove the intake tube and set it aside.

Step 3: Disconnect Throttle Body and Intake Connectors

• Use your fingers or a plastic trim removal tool to unlock the throttle body electrical connector.
• Press the release tab and pull the connector straight off.
• Label the connector with masking tape and a permanent marker.
• Disconnect any vacuum hose or sensor connector attached to the upper intake manifold.

Step 4: Remove the Upper Intake Manifold

• Use a 10mm socket, 6-inch extension, and 3/8-inch drive ratchet to remove the upper intake manifold bolts.
• Keep the bolts organized so they go back in the same locations.
• Lift the upper intake manifold carefully off the engine.
• Use clean shop towels to cover the open intake ports immediately.
• Do not drop anything inside.

Step 5: Remove the Ignition Coils

• Each spark plug has one ignition coil on top. The ignition coil creates the spark for the plug.
• Use your fingers or a plastic trim removal tool to unlock each coil electrical connector.
• Use a 10mm socket and 3/8-inch drive ratchet to remove each coil retaining bolt.
• Twist each coil gently by hand, then pull it straight up.
• Lay the coils in order so each one can go back to the same cylinder.

Step 6: Clean Around the Spark Plug Wells

• Put on safety glasses.
• Use a compressed air blow gun to blow dirt out of each spark plug well.
• This prevents grit from falling into the engine when the spark plug is removed.

Step 7: Remove the Old Spark Plugs

• Use a 5/8-inch spark plug socket, 6-inch extension, and 3/8-inch drive ratchet to loosen each spark plug.
• Turn counterclockwise slowly until the plug is free.
• Lift each plug out carefully using the spark plug socket.
• If a plug feels stuck, stop and work it back and forth gently by hand pressure only.
• Slow is safer here.

Step 8: Check the New Spark Plugs

• Use a spark plug gap gauge to verify the new plugs are gapped to the correct specification for your 1500.
• Most modern replacement plugs are pre-gapped, but shipping can bend the small ground strap.
• Do not apply anti-seize unless the spark plug manufacturer specifically requires it.

Step 9: Install the New Spark Plugs

• Place one new spark plug into the 5/8-inch spark plug socket.
• Use the 6-inch extension by hand to thread the spark plug into the cylinder head.
• Turn clockwise by hand until the plug seats. It should thread smoothly.
• If it does not turn easily, remove it and start again to avoid cross-threading.
• Use a 3/8-inch drive torque wrench to tighten each spark plug to Torque to 18 Nm (13 ft-lbs).

Step 10: Reinstall the Ignition Coils

• Apply a small dab of dielectric grease inside each coil boot. Dielectric grease helps seal moisture out of the rubber boot.
• Push each ignition coil straight down onto its spark plug until fully seated.
• Use a 10mm socket and 3/8-inch drive torque wrench to tighten each coil bolt to Torque to 8 Nm (71 in-lbs).
• Reconnect each coil electrical connector until it clicks.

Step 11: Replace Intake Manifold Gaskets

• Remove the old upper intake manifold gaskets by hand.
• Use clean shop towels to wipe the gasket grooves and sealing surface.
• Install the new upper intake manifold gaskets into the manifold grooves.
• Make sure each gasket sits flat and is not twisted.

Step 12: Reinstall the Upper Intake Manifold

• Remove the clean shop towels from the intake ports.
• Carefully set the upper intake manifold back into place.
• Start all bolts by hand first.
• Use a 10mm socket, 6-inch extension, and 3/8-inch drive torque wrench to tighten the intake manifold bolts evenly.
• Tighten in a crisscross pattern to Torque to 12 Nm (106 in-lbs).

Step 13: Reconnect Hoses and Electrical Connectors

• Reconnect all labeled vacuum hoses and sensor connectors by hand.
• Use needle-nose pliers to reinstall spring clamps if removed.
• Reconnect the throttle body electrical connector until it clicks.
• Check that no connector is hanging loose.

Step 14: Reinstall the Air Intake Tube

• Position the intake tube between the throttle body and air filter box.
• Use a flathead screwdriver or 8mm socket to tighten both hose clamps snugly.
• Reconnect any breather hose removed earlier.

Step 15: Reconnect the Battery and Engine Cover

• Use a 10mm socket to reconnect the negative battery cable.
• Tighten the cable clamp until secure; do not overtighten.
• Push the engine cover straight down onto the rubber mounting posts.

---

✅ After Repair

• Start the engine and let it idle for a few minutes.
• The idle may be slightly uneven at first while the throttle body relearns after battery disconnect.
• Listen for hissing sounds near the intake manifold. A hiss may mean a vacuum leak.
• Check that the check engine light stays off.
• Take a gentle 10-15 minute test drive and confirm smooth acceleration.
• If the engine misfires, shut it off and recheck coil connectors, intake hoses, and spark plug seating.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 (parts + labor)

DIY Cost: $90-$180 (parts only)

You Save: $360-$570 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
