🔧 Pilot - Spark Plug Replacement

Replacing the spark plugs on your Pilot helps restore smooth starting, idle quality, fuel economy, and acceleration. The V6 engine uses six spark plugs: three at the front of the engine and three at the rear near the firewall.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool completely before starting. Spark plugs thread into aluminum cylinder heads, and hot aluminum threads can be damaged.
• ⚠️ Disconnect the negative battery terminal before unplugging ignition coils.
• ⚠️ Work on one spark plug at a time so coils and connectors do not get mixed up.
• ⚠️ Do not overtighten spark plugs. The cylinder head is aluminum and can strip if too much force is used.
• ⚠️ Keep dirt out of the spark plug wells. Anything that falls in can enter the engine when the plug is removed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8-inch ratchet
• 3/8-inch torque wrench
• 5/8-inch spark plug socket
• 6-inch 3/8-inch drive extension
• 12-inch 3/8-inch drive extension
• 3/8-inch drive universal joint adapter
• Needle-nose pliers
• Compressed air blow gun
• Spark plug gap gauge
• Dielectric grease
• Magnetic pickup tool
• Fender cover
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Iridium spark plugs - Qty: 6
• Intake manifold cover clips - Qty: As needed

---

📋 Before You Begin

• 🅿️ Park your Pilot on level ground, shift to Park, and set the parking brake.
• ❄️ Let the engine cool for at least 1-2 hours if it was recently driven.
• 🔋 Use a 10mm socket to disconnect the negative battery cable. Move the cable aside so it cannot touch the battery post.
• 🧼 Clean around the top of the engine before removing parts. A clean work area helps prevent dirt from falling into the plug wells.
• 📏 Spark plug gap should be checked gently with a spark plug gap gauge. Most iridium plugs are pre-gapped; do not pry hard on the center electrode.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the Engine Cover

• Use your hands to lift the plastic engine cover straight up from its rubber mounts.
• If a clip is stuck, use needle-nose pliers gently to help free it.
• Set the cover aside where it will not get stepped on.
• Tip: Pull upward evenly, not sideways.

Step 2: Locate the Ignition Coils

• Your Pilot has six ignition coils. An ignition coil is the small electrical unit mounted directly above each spark plug.
• Three coils are visible at the front of the engine.
• Three coils are at the rear of the engine, closer to the firewall.
• Use a fender cover to protect the paint while leaning over the engine bay.

Step 3: Clean the First Spark Plug Area

• Choose one front ignition coil to start with.
• Use compressed air blow gun to blow dirt away from the coil and surrounding area.
• Wear safety glasses while using compressed air.
• Only work on one cylinder at a time.

Step 4: Disconnect the Ignition Coil Connector

• Press the locking tab on the ignition coil electrical connector with your thumb.
• Pull the connector straight off the coil.
• If it is stubborn, use needle-nose pliers gently on the connector body, not the wires.
• Tip: Never pull on the wiring.

Step 5: Remove the Ignition Coil

• Use a 10mm socket and 3/8-inch ratchet to remove the ignition coil retaining bolt.
• Twist the coil slightly by hand to loosen the rubber boot.
• Pull the coil straight up and out.
• Inspect the coil boot for oil, cracking, carbon tracking, or swelling.

Step 6: Blow Out the Spark Plug Well

• Use compressed air blow gun to clean inside the spark plug well before removing the plug.
• A spark plug well is the deep tube where the spark plug sits.
• Keep your face away from the well and wear safety glasses.

Step 7: Remove the Old Spark Plug

• Install the 5/8-inch spark plug socket onto a 6-inch 3/8-inch drive extension and 3/8-inch ratchet.
• Lower the socket straight down onto the spark plug.
• Turn counterclockwise slowly to loosen the spark plug.
• Once loose, spin it out carefully and lift it out with the spark plug socket.
• If the plug does not come out with the socket, use a magnetic pickup tool.

Step 8: Check the New Spark Plug

• Use a spark plug gap gauge to gently verify the gap.
• The spark plug gap for your Pilot is 1.0-1.1 mm (0.039-0.043 in).
• Do not use anti-seize on the new spark plug threads unless the plug manufacturer specifically requires it.
• Most modern iridium spark plugs have plated threads and are installed dry.

Step 9: Install the New Spark Plug by Hand First

• Place the new spark plug into the 5/8-inch spark plug socket.
• Use the 6-inch 3/8-inch drive extension to lower it straight into the spark plug well.
• Turn clockwise by hand only for the first several turns.
• If it does not turn easily, stop and restart. This prevents cross-threading, which means damaging the threads by starting the plug crooked.
• Tip: Hand-starting prevents expensive thread damage.

Step 10: Torque the New Spark Plug

• Attach the 3/8-inch torque wrench to the 5/8-inch spark plug socket and extension.
• Tighten the spark plug to Torque to 18 Nm (13 ft-lbs).
• Do not tighten past the click on the torque wrench.

Step 11: Reinstall the Ignition Coil

• Apply a small pea-sized amount of dielectric grease inside the end of the coil boot.
• Dielectric grease helps seal moisture out of the rubber boot; it does not go on the spark plug threads.
• Push the ignition coil straight down until it seats on the spark plug.
• Install the coil retaining bolt with a 10mm socket and 3/8-inch torque wrench.
• Tighten the ignition coil bolt to Torque to 12 Nm (9 ft-lbs).
• Reconnect the electrical connector until it clicks.

Step 12: Repeat for the Other Front Spark Plugs

• Use compressed air blow gun before removing each coil.
• Use the 10mm socket to remove each coil bolt.
• Use the 5/8-inch spark plug socket, 6-inch extension, and 3/8-inch ratchet to remove each plug.
• Install each new spark plug by hand first, then torque to Torque to 18 Nm (13 ft-lbs).
• Reinstall each ignition coil bolt to Torque to 12 Nm (9 ft-lbs).

Step 13: Replace the Rear Spark Plugs

• Move to the rear bank near the firewall.
• Use the 12-inch 3/8-inch drive extension and 3/8-inch drive universal joint adapter where access is tight.
• A universal joint adapter lets the socket bend slightly so you can reach around obstacles.
• Use a 10mm socket to remove each rear ignition coil bolt.
• Disconnect each coil connector by pressing the tab and pulling on the connector body.
• Remove one coil at a time, then blow out the spark plug well with compressed air blow gun.
• Use the 5/8-inch spark plug socket, extension, universal joint adapter, and 3/8-inch ratchet to remove each rear spark plug.
• Install each new spark plug by hand first, then torque to Torque to 18 Nm (13 ft-lbs).
• Reinstall each ignition coil bolt to Torque to 12 Nm (9 ft-lbs).
• Tip: Patience matters on the rear bank.

Step 14: Reinstall the Engine Cover

• Use your hands to align the plastic engine cover with the rubber mounting points.
• Press straight down until it seats fully.
• Make sure no tools, rags, or loose parts are left in the engine bay.

Step 15: Reconnect the Battery

• Use a 10mm socket to reconnect the negative battery cable.
• Tighten the terminal snugly so it cannot rotate by hand.
• Do not overtighten the battery terminal clamp.

---

✅ After Repair

• ✅ Start the engine and let it idle for 1-2 minutes.
• 👂 Listen for smooth idle. A rough idle or flashing check engine light usually means a coil connector is loose or a coil is not seated.
• 🔍 Check that all six ignition coil connectors are fully clicked in.
• 🚗 Take a short test drive. Acceleration should feel smooth with no hesitation.
• 🪟 If the battery was disconnected, reset the auto-up window function if needed by fully lowering and fully raising the window while holding the switch briefly at the top.
• 📻 Re-enter radio presets or clock settings if they were lost after battery disconnect.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $90-$180 (parts only)

You Save: $260-$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
