🔧 1500 - Side View Mirror Replacement

This repair replaces a complete outside side view mirror assembly on your 1500. The front door trim panel must be removed to access the mirror wiring connector and mounting nuts inside the door.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours per side

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative 12V battery cable before unplugging mirror wiring connectors.
• ⚠️ Your 1500 has an eTorque mild-hybrid system, but this repair only involves the 12V door circuit. Do not touch orange high-voltage cables or hybrid components.
• ⚠️ Support the mirror with one hand when removing the final mounting nut so it does not fall and damage the paint.
• ⚠️ Wear safety glasses and gloves when working around the door panel and mirror glass.
• ⚠️ If your mirror has blind spot monitoring, handle the connector carefully. The warning indicator wiring is part of the mirror assembly.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 8mm socket
• 7mm socket
• Ratchet
• 3-inch socket extension
• 10mm deep socket
• Torque wrench inch-pound
• Trim panel removal tool
• Plastic pry tool set
• Small flat-blade screwdriver
• Pick tool set
• Painter’s tape 2-inch width
• Clean microfiber towel
• Safety glasses
• Work gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Side view mirror assembly - Qty: 1 per side
• Front door trim panel clips - Qty: 6-10 per door
• Mirror foam gasket - Qty: 1 per side

---

📋 Before You Begin

• 🅿️ Park your 1500 on level ground and set the parking brake.
• 🔋 Turn the ignition off, remove the key fob from the cab, and wait at least 2 minutes for the body control modules to go to sleep.
• 🔋 Use a 10mm socket to disconnect the negative 12V battery cable and position it away from the battery post.
• 🪞 Fold the mirror inward if possible to make it easier to handle.
• 🧰 A trim panel removal tool is a flat plastic lever used to pop door clips loose without damaging the panel.
• 🧰 A deep socket is a longer socket that reaches nuts mounted on studs.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Protect the Door Paint

• Use 2-inch painter’s tape around the outside mirror base where it meets the door.
• Place a clean microfiber towel below the mirror area to protect the paint if the mirror shifts.
• Tape prevents accidental scratches.

Step 2: Remove the Front Door Switch Trim

• Use a plastic pry tool to gently lift the window switch trim from the armrest.
• Use a small flat-blade screwdriver to release the electrical connector locks.
• Unplug the switch connectors by hand and set the switch trim aside.

Step 3: Remove Hidden Door Panel Screws

• Use a small flat-blade screwdriver or pick tool to remove the small trim covers in the pull handle and interior handle area.
• Use a 7mm socket with ratchet to remove the exposed door panel screws.
• Use an 8mm socket if your door panel uses an 8mm fastener behind the handle trim.
• Keep the screws in order so they return to the same locations.

Step 4: Release the Door Trim Panel

• Use a trim panel removal tool at the lower edge of the front door panel.
• Pry outward near each clip until the clips release.
• Work around the lower and side edges of the panel.
• Lift the panel straight upward to unhook it from the window ledge.
• Do not pull the panel away quickly because cables and connectors are still attached.

Step 5: Disconnect Door Panel Cables and Connectors

• Use a small flat-blade screwdriver to release any electrical connector locks.
• Unplug the door panel connectors by hand.
• Use a pick tool to release the interior door handle cable retainer.
• Lift the cable end out of the handle lever by hand.
• Set the door panel on a clean towel.
• Take a photo before unplugging connectors.

Step 6: Remove the Mirror Inner Cover

• Use a plastic pry tool to remove the triangular inner mirror cover at the upper front corner of the door.
• Pull straight outward to release the retaining clips.
• Set the cover aside where the clips will not be bent.

Step 7: Locate and Unplug the Mirror Connector

• Use a small flat-blade screwdriver to unlock the mirror electrical connector.
• Unplug the connector by hand.
• Free the mirror wiring harness from any door retainers using a pick tool.
• Do not pull on the wires. Pull only on the connector body.

Step 8: Remove the Mirror Mounting Nuts

• Support the outside mirror with one hand.
• Use a 10mm deep socket with ratchet and 3-inch extension to remove the mirror mounting nuts from inside the door.
• Remove the lower nut first, then the upper nuts.
• Keep one nut loosely threaded until you are ready to remove the mirror.
• Torque on installation: 8 Nm (71 in-lbs)

Step 9: Remove the Old Mirror

• Hold the mirror firmly from outside the door.
• Use a 10mm deep socket to remove the final loose mounting nut.
• Carefully pull the mirror straight away from the door.
• Feed the wiring harness through the door opening by hand.
• Remove the old foam gasket if it stayed stuck to the door.

Step 10: Install the New Mirror

• Confirm the new mirror has the same connector style and features as the old mirror.
• Make sure the foam gasket is seated flat on the new mirror base.
• Feed the mirror wiring harness through the door opening by hand.
• Place the mirror studs through the door holes.
• Start all 10mm mounting nuts by hand first to avoid cross-threading.

Step 11: Tighten the Mirror Mounting Nuts

• Use a 10mm deep socket to snug the mirror mounting nuts evenly.
• Use an inch-pound torque wrench with 10mm deep socket to tighten the nuts to 8 Nm (71 in-lbs).
• Do not overtighten. The mirror base and door sheet metal can be damaged.

Step 12: Connect the Mirror Wiring

• Route the mirror wiring along the original path by hand.
• Press the harness back into its retainers by hand.
• Plug in the mirror connector until it clicks.
• Use a small flat-blade screwdriver only if needed to seat the connector lock.

Step 13: Test the Mirror Before Reassembly

• Reconnect the driver door switch trim connectors by hand.
• Use a 10mm socket to reconnect the negative battery cable temporarily.
• Turn the ignition to run without starting the engine.
• Test mirror glass adjustment using the mirror switch.
• Test heat, turn signal, puddle lamp, power fold, and blind spot indicator if equipped.
• Turn ignition off after testing.
• Use a 10mm socket to disconnect the negative battery cable again before final door panel installation.

Step 14: Reinstall the Mirror Inner Cover

• Align the triangular mirror cover clips by hand.
• Press the cover straight into place until it clicks.
• Make sure it sits flush against the door trim area.

Step 15: Reinstall the Door Trim Panel

• Reconnect the interior door handle cable by hand.
• Reconnect all door panel electrical connectors by hand until each one clicks.
• Hang the top of the door panel over the window ledge.
• Align the trim clips with the holes in the door.
• Press around the edges of the panel with your palm until the clips snap in.

Step 16: Reinstall Door Panel Screws and Switch Trim

• Use a 7mm socket to reinstall the door panel screws.
• Use an 8mm socket for any 8mm fasteners removed earlier.
• Tighten the screws snug only. Plastic trim can crack if overtightened.
• Snap the trim covers back in by hand.
• Plug in the window switch trim connectors by hand.
• Press the switch trim into the armrest until it clicks.

Step 17: Final Battery Connection

• Use a 10mm socket to reconnect the negative 12V battery cable.
• Tighten the cable snugly so it cannot rotate on the battery post.
• Remove the painter’s tape and microfiber towel from the door.

---

✅ After Repair

• ✅ Test mirror adjustment in all directions.
• ✅ Test mirror heating by turning on the rear defrost/mirror heat function.
• ✅ Test the turn signal, puddle lamp, power fold, memory position, and blind spot indicator if equipped.
• ✅ Check the door panel for loose edges or rattles.
• ✅ Drive slowly and confirm the mirror stays steady with no vibration.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$950 per side (parts + labor)

DIY Cost: $180-$650 per side (parts only)

You Save: $270-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
