🔧 CR-V - Side View Mirror Assembly Replacement

This procedure replaces the complete driver-side or passenger-side mirror assembly on your CR-V. The interior door panel must be loosened so you can disconnect the power-mirror wiring, then three mounting nuts secure the mirror to the door.

Difficulty Level: Beginner | Estimated Time: 0.75-1.25 hours per side

---

⚠️ Safety & Precautions

• ⚠️ Wear gloves because broken mirror glass can have extremely sharp edges.
• 🔋 Disconnect the negative battery cable before unplugging the mirror wiring.
• 🚪 Support the mirror before removing its final nut so it cannot fall against the door.
• 🛡️ Apply painter’s tape around the mirror base to protect the paint.
• ⚠️ Do not switch the ignition on while door electrical connectors are disconnected.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 10mm socket
• 1/4-inch drive ratchet
• 1/4-inch drive 3-inch extension
• Torque wrench rated 2-20 Nm
• Phillips #2 screwdriver
• Plastic trim removal tool set
• 25mm painter’s tape
• Magnetic parts tray
• Cut-resistant work gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Complete power side-view mirror assembly, correct side - Qty: 1 per damaged side
• Mirror mounting gasket - Qty: 1 per replaced mirror if not included
• Interior door trim clips - Qty: 3-5 spares per door

Your LX uses a power-adjustable mirror without the turn-signal equipment fitted to higher trims. Match the left or right side and the original electrical connector before installation.

---

📋 Before You Begin

• 🅿️ Park your CR-V on level ground, select Park, apply the parking brake, and lower the affected window.
• 🔑 Switch the ignition off and keep the key away from the vehicle.
• 🪟 If the mirror is broken, cover loose glass with painter’s tape before handling it.
• 🔋 Open the hood and disconnect the negative battery terminal with a 10mm socket. Wait at least three minutes before working on the door wiring.
• 🧰 A plastic trim removal tool is a nonmetal wedge used to release interior panels without scratching them.
• 📦 Compare the replacement mirror’s mounting studs, connector, housing, and glass shape with the original mirror.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Protect the Work Area

• Apply 25mm painter’s tape around the outside edge of the mirror base and along the upper door trim.
• Put on cut-resistant work gloves and safety glasses before touching damaged glass.
• Fold a towel over the door edge.

Step 2: Remove the Inner Handle Cover

• Use a plastic trim removal tool to carefully lift the small cover behind the interior door-release handle.
• Use a Phillips #2 screwdriver to remove the screw exposed behind the cover.
• Place the screw in a magnetic parts tray.

Step 3: Remove the Door-Pull Screw

• Use a plastic trim removal tool to lift the rubber mat or small cover inside the door-pull recess.
• Use a Phillips #2 screwdriver to remove the screw underneath it.
• Keep this screw separate in the magnetic parts tray.

Step 4: Release the Door Panel Clips

• Insert a plastic trim removal tool between the lower rear edge of the door panel and the metal door.
• Work around the bottom and both sides, releasing each push clip individually.
• Lift the panel straight upward to unhook it from the window ledge.
• Do not pull the panel far away yet because cables and electrical connectors remain attached.

Step 5: Disconnect the Door Panel

• Support the panel with one hand while pressing the connector locking tabs by hand.
• Unplug the window-switch and door electrical connectors without pulling on their wires.
• Release the interior handle cable from its bracket by hand, then rotate the cable end out of the handle lever.
• Set the door panel on a clean padded surface.

Step 6: Remove the Mirror Corner Trim

• Use a plastic trim removal tool to pull the triangular interior garnish away from the upper front corner of the door.
• Pull toward the cabin rather than sliding it upward.
• Inspect its retaining clips and replace any damaged clip.

Step 7: Disconnect the Mirror Wiring

• Locate the mirror electrical connector behind the upper front portion of the door.
• Press its locking tab by hand and disconnect it.
• Release the mirror harness from its retaining clips by hand so it can pass through the door opening.

Step 8: Remove the Old Mirror

• Use an 8mm socket, 3-inch extension, and 1/4-inch drive ratchet to loosen the three mirror mounting nuts.
• Hold the mirror from outside while removing the final nut.
• Feed the connector through the opening and lift the mirror away from the door.
• Keep the nuts in the magnetic parts tray if replacements were not supplied.
• Never let a mounting nut fall inside.

Step 9: Clean and Inspect the Mounting Area

• Use gloved fingers to remove loose gasket material from the mounting surface.
• Inspect the door opening for bent metal, corrosion, or damaged paint.
• Confirm that the replacement mirror gasket sits flat and completely surrounds the wiring opening.

Step 10: Install the Replacement Mirror

• Feed the replacement mirror connector through the door opening by hand.
• Align the three studs and hold the mirror base firmly against the door.
• Start all three mounting nuts by hand to prevent cross-threading.
• Use an 8mm socket and 1/4-inch drive ratchet to seat the nuts evenly.
• Use a torque wrench and 8mm socket to tighten each nut to 9 Nm (7 ft-lbs).
• Do not overtighten the nuts because the mirror base can crack or distort.

Step 11: Connect and Route the Wiring

• Push the mirror connector together by hand until its locking tab clicks.
• Secure the harness in the original retaining clips by hand.
• Make sure the harness does not interfere with the window glass or regulator mechanism.

Step 12: Reinstall the Mirror Corner Trim

• Align the triangular garnish clips with their openings.
• Press the garnish evenly by hand until every clip snaps into place.
• Do not strike the trim or use the ratchet as a pressing tool.

Step 13: Reinstall the Door Panel

• Reconnect the interior handle cable by hand and lock its housing into the bracket.
• Reconnect every door electrical connector by hand until each locking tab clicks.
• Hook the top edge of the panel over the window ledge, then align the perimeter clips.
• Press directly over each clip by hand until it engages.
• Use a Phillips #2 screwdriver to reinstall the door-pull and interior-handle screws until snug. These are small trim screws; do not overtighten them.
• Press the covers and rubber mat into place by hand.

Step 14: Reconnect the Battery

• Place the negative battery cable fully onto its terminal.
• Use a torque wrench and 10mm socket to tighten the terminal nut to 5.4 Nm (48 in-lbs).
• Remove the painter’s tape and inspect the paint around the mirror.

---

✅ After Repair

• 🔍 Switch the ignition on and move the mirror through its full up, down, left, and right adjustment range.
• 🪟 Operate the affected window fully down and up while listening for wiring contact inside the door.
• 🔒 Test the power lock, window switch, interior handle, and speaker before driving.
• 💡 Confirm that no warning lights remain illuminated after the engine starts.
• 🚗 Adjust the mirror for proper rearward visibility before driving.
• 💧 After the first wash or rainfall, inspect the inside of the door near the mirror for water intrusion.
• 🪟 If the automatic window function was lost, fully close the window and hold the switch up for two additional seconds.

---

💰 DIY vs Shop Cost

Shop Cost: ₹12,000-₹28,000 per side (parts + labor)

DIY Cost: ₹6,000-₹18,000 per side (parts only)

You Save: ₹6,000-₹10,000 per side by doing it yourself!

Labor rates around Sonīpat vary by workshop. This repair takes a shop approximately 0.5-1.0 hour per side, and painted mirror caps may add paint costs.

---
