🔧 Pathfinder - Rear Brake Pad Replacement

Replacing the rear brake pads involves removing both rear calipers, compressing their pistons, and installing new pads and hardware. Your Pathfinder uses a separate drum-style parking brake inside the rear rotor, so no electronic parking-brake service mode is required.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level, solid ground and support your Pathfinder with jack stands. Never work beneath a vehicle supported only by a jack.
• ⚠️ Release the parking brake before removing the calipers. Use wheel chocks at both sides of a front tire to prevent movement.
• ⚠️ Replace the pads on both rear wheels so braking remains balanced.
• ⚠️ Do not press the brake pedal while either caliper is removed.
• ⚠️ Never allow a caliper to hang from its rubber brake hose.
• ⚠️ Brake dust may be harmful. Do not blow it away with compressed air.
• ⚠️ Battery disconnection is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Hydraulic floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• 21mm deep socket
• 14mm socket
• 19mm open-end wrench
• 3/8-inch drive ratchet
• 1/2-inch drive breaker bar
• 3/8-inch drive torque wrench rated 10-80 ft-lbs
• 1/2-inch drive torque wrench rated 20-150 ft-lbs
• Disc brake piston compression tool (specialty)
• Small flat-blade screwdriver
• Nylon brake-cleaning brush
• Brake caliper hanger (specialty)
• Plastic trim tool
• Disposable drain pan
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1 set for both rear wheels
• Rear brake pad hardware kit - Qty: 1 set
• High-temperature ceramic brake lubricant - Qty: 1 tube
• Non-chlorinated brake cleaner - Qty: 1 can
• DOT 3 brake fluid - Qty: 1 small sealed bottle, only if fluid adjustment is needed

Replace in pairs: Always install the complete rear pad set on both sides.

---

📋 Before You Begin

• 📋 Park your Pathfinder on level pavement, shift the CVT into Park, and switch off the engine.
• 📋 Leave the parking brake released because it acts inside the rear brake rotors.
• 📋 Place wheel chocks tightly against the front and rear of one front tire.
• 📋 Open the hood and inspect the brake-fluid reservoir. If it is near the MAX line, remove a small amount with a clean suction tool before compressing the pistons.
• 📋 Do not leave the reservoir uncovered. Brake fluid absorbs moisture and damages paint.
• 📋 No infotainment menu, scan tool, coding, or electronic parking-brake service mode is needed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the rear wheel nuts

• Use a 21mm deep socket and 1/2-inch drive breaker bar to loosen each rear wheel nut about one-quarter turn.
• Keep the tires on the ground while loosening the nuts. Do not remove them yet.

Step 2: Raise and support the rear

• Use the hydraulic floor jack under the approved rear lifting point to raise your Pathfinder.
• Place the jack stands beneath the reinforced rear side support points. A jack stand is a rigid support that safely holds the vehicle after lifting.
• Lower the vehicle gently onto the stands and verify that it is stable before continuing.

Step 3: Remove both rear wheels

• Use the 21mm deep socket and 1/2-inch drive breaker bar to remove the wheel nuts.
• Remove both rear wheels and place them flat away from the work area.
• Finish one brake side before dismantling the other.

Step 4: Inspect the brakes

• Use the safety glasses, nitrile gloves, non-chlorinated brake cleaner, and nylon brake-cleaning brush to remove loose dust.
• Inspect the rotor for deep grooves, cracks, heavy rust, or blue heat spots. A damaged or undersized rotor must be replaced or professionally measured before new pads are installed.
• Inspect the brake hose for cracking, wetness, or swelling. Stop the repair if the hose or caliper is leaking.

Step 5: Remove the caliper

• Use a 14mm socket and 3/8-inch drive ratchet to remove the upper and lower caliper guide-pin bolts.
• If a guide pin rotates, hold its flat section with the 19mm open-end wrench while loosening the bolt with the 14mm socket.
• Lift the caliper from the bracket. Use the brake caliper hanger to suspend it from the suspension.
• Do not twist, stretch, or place weight on the brake hose.

Step 6: Remove the old pads and hardware

• Pull the inner and outer pads from the caliper bracket by hand.
• Use the small flat-blade screwdriver to carefully remove the stainless-steel pad clips from the bracket.
• Compare the old pads. Uneven wear can indicate a seized guide pin, sticking pad, or faulty caliper.
• Note the position of any wear indicator on the old pads and match that arrangement when installing the new set.

Step 7: Clean the caliper bracket

• Place the disposable drain pan below the brake assembly.
• Use the non-chlorinated brake cleaner and nylon brake-cleaning brush to clean the pad-contact areas on the bracket.
• Install the new hardware clips by hand. Use the plastic trim tool to seat them fully without bending them.
• Apply a very thin layer of high-temperature ceramic brake lubricant to the pad ears where they touch the clips.
• Keep lubricant away from the rotor and pad friction surfaces.

Step 8: Check the guide pins

• Slide each guide pin in and out by hand. It should move smoothly and its rubber boot should be intact.
• If a pin is dry but undamaged, wipe it clean and apply a light coating of high-temperature ceramic brake lubricant.
• Do not interchange the upper and lower pins. Stop if a pin is rusted, bent, or seized.

Step 9: Compress the caliper piston

• Place one old pad against the piston, then use the disc brake piston compression tool to push the piston slowly and straight into the caliper.
• This piston presses directly inward; it does not need to be rotated.
• Watch the brake-fluid reservoir while compressing the piston. Stop before fluid reaches or spills above the MAX line.
• Inspect the rubber piston boot and make sure it is not twisted, pinched, or torn.

Step 10: Install the new pads

• Fit the new inner and outer pads into the clean hardware clips by hand.
• Confirm that each pad slides freely in the bracket without excessive looseness.
• Position the wear indicator in the same location as the original pad.
• Do not touch the pad friction material or rotor face with greasy gloves.

Step 11: Reinstall the caliper

• Remove the brake caliper hanger and lower the caliper over the new pads without twisting the hose.
• Start both guide-pin bolts by hand to prevent crossed threads.
• If needed, hold the guide pin with the 19mm open-end wrench.
• Use the 14mm socket and 3/8-inch drive torque wrench to tighten both guide-pin bolts to 32 Nm (24 ft-lbs).

Step 12: Repeat on the opposite side

• Repeat Steps 4 through 11 on the other rear wheel using the same listed tools.
• Compare both completed sides and confirm that the hoses, pad clips, and wear indicators are correctly positioned.

Step 13: Reinstall the wheels

• Install each rear wheel and start all wheel nuts by hand.
• Use the 21mm deep socket and 1/2-inch drive torque wrench to snug the nuts in a crisscross pattern.
• Use the hydraulic floor jack to raise the vehicle slightly, remove the jack stands, and lower the tires to the ground.
• With the full vehicle weight on the tires, tighten the wheel nuts in a crisscross pattern to 113 Nm (83 ft-lbs).

---

✅ After Repair

• ✅ Before starting the engine, press and release the brake pedal several times until it feels firm. This seats the pistons against the new pads.
• ✅ Check the brake-fluid reservoir and adjust to the MAX line with fresh DOT 3 brake fluid only if necessary. Do not overfill it.
• ✅ Start the engine and confirm that the pedal remains firm. Check around both calipers for leaks.
• ✅ Apply and release the parking brake to verify normal operation, even though its shoes were not disturbed.
• ✅ Perform a slow test in a traffic-free area. Verify that your Pathfinder stops straight and has no scraping, pulling, or unusually soft pedal.
• ✅ Bed in the pads with 8-10 moderate stops from about 50 km/h to 10 km/h. Allow approximately 30 seconds between stops and avoid holding the hot brakes while stationary.
• ✅ Avoid hard braking for the first 300 km unless required for safety.
• ✅ Recheck wheel-nut torque after approximately 80-160 km.

---

💰 DIY vs Shop Cost

Shop Cost: ₹9,000-₹18,000 (parts + labor)

DIY Cost: ₹3,500-₹8,000 (parts only)

You Save: ₹5,500-₹10,000 by doing it yourself!

Labor rates around Sonīpat vary by workshop. This repair takes a shop approximately 1-1.5 hours.

---
