🔧 Wrangler - Rear Brake Pad Replacement

Replacing the rear brake pads on your Wrangler means removing the rear wheels, unbolting each rear caliper, swapping the pads, compressing the caliper piston, and reinstalling everything safely. Rear pads should be replaced in axle pairs, so do both left and right rear sides at the same time.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface and never rely on a jack alone.
• ⚠️ Use jack stands before placing any part of your body near or under your Wrangler.
• ⚠️ Brake dust can be harmful; use brake cleaner, not compressed air, to clean parts.
• ⚠️ Brake fluid may rise in the reservoir when you compress the caliper pistons. Remove excess fluid if it gets near the top.
• ⚠️ Do not press the brake pedal while a caliper is removed.
• ⚠️ Battery disconnect is not required for this rear brake pad replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 13mm socket
• 18mm socket
• 19mm socket
• 3/8-inch drive ratchet
• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench
• 3/8-inch drive torque wrench
• C-clamp or disc brake piston compressor (specialty)
• Flat-blade screwdriver
• Small wire brush
• Brake cleaner spray
• Shop rags
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear brake pad set - Qty: 1
• Rear brake hardware kit - Qty: 1
• Brake caliper slide pin grease - Qty: 1
• Brake parts cleaner - Qty: 1

---

📋 Before You Begin

• 🅿️ Park your Wrangler on level ground and shift the manual transmission into 1st gear.
• 🪨 Place wheel chocks in front of and behind the front wheels.
• 🧤 Put on safety glasses and gloves before touching brake parts.
• 🧪 Open the hood and check the brake fluid reservoir. If it is very full, remove a small amount with a clean suction tool before compressing the calipers.
• 🔩 A caliper is the clamp-shaped brake part that squeezes the pads against the rotor to stop the wheel.
• 🔧 A torque wrench tightens bolts to the correct tightness so they are not too loose or too tight.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the rear wheel lug nuts

• Use a 19mm socket and 1/2-inch drive breaker bar to loosen the rear wheel lug nuts about 1/2 turn.
• Do this while the tires are still touching the ground so the wheels do not spin.
• Do not remove them yet.

Step 2: Lift and support the rear of the Wrangler

• Use a floor jack rated 3-ton minimum under the rear axle tube or center rear axle area to lift the rear tires off the ground.
• Place jack stands rated 3-ton minimum securely under the rear axle tubes.
• Lower the Wrangler gently onto the jack stands using the floor jack.
• Lightly shake the vehicle by hand to confirm it is stable before continuing.

Step 3: Remove the rear wheels

• Use the 19mm socket and 3/8-inch drive ratchet to remove the loosened lug nuts.
• Remove both rear wheels and set them flat on the ground.
• Keep lug nuts together in a small tray.

Step 4: Inspect the brake assembly

• Look at the rear caliper, brake pads, and rotor before taking anything apart.
• Use brake cleaner spray and shop rags to clean loose dust from the caliper area.
• Do not spray brake cleaner on painted body panels.

Step 5: Remove the rear caliper guide pin bolts

• Use a 13mm socket and 3/8-inch drive ratchet to remove the two rear caliper guide pin bolts.
• The guide pins let the caliper slide smoothly as the pads wear.
• Hold the caliper steady by hand as the last bolt comes out.

Step 6: Lift off the rear caliper

• Use a flat-blade screwdriver carefully between the caliper and outer pad if the caliper is stuck.
• Lift the caliper off the rotor by hand.
• Do not let the caliper hang by the rubber brake hose.
• Rest the caliper carefully on top of the axle or support it so the hose is not stretched.

Step 7: Remove the old rear brake pads

• Pull the old brake pads out of the caliper bracket by hand.
• If they are stuck, use a flat-blade screwdriver to gently pry them out.
• Notice how the pads and clips are positioned before removing the clips.
• Take a phone photo first.

Step 8: Remove and clean the pad hardware

• Use the flat-blade screwdriver to remove the old stainless pad clips from the caliper bracket.
• Use a small wire brush to clean the bracket areas where the clips sit.
• Spray the bracket contact points with brake cleaner spray and wipe with shop rags.
• Clean metal contact areas help the new pads slide freely.

Step 9: Install the new rear brake hardware

• Press the new rear brake hardware kit clips into the caliper bracket by hand.
• Make sure each clip sits fully flat in the bracket.
• Use a flat-blade screwdriver only if needed to gently seat the clips.

Step 10: Compress the rear caliper piston

• Place one old brake pad against the caliper piston.
• Use a C-clamp or disc brake piston compressor to slowly push the piston fully back into the caliper.
• Go slowly and check the brake fluid reservoir while compressing.
• If fluid rises too high, remove a small amount before it spills.
• On your Wrangler, the rear service brake caliper piston presses straight in; it does not need to be rotated for pad replacement.

Step 11: Lubricate the sliding contact points

• Use a small amount of brake caliper slide pin grease on the pad ears where they touch the new clips.
• Use the same grease lightly on the caliper guide pins if they are dry.
• Do not get grease on the pad friction surface or rotor face.
• A thin film is enough.

Step 12: Install the new rear brake pads

• Slide the new rear brake pads into the caliper bracket by hand.
• Make sure the friction material faces the rotor.
• The pads should move slightly in the clips without binding.
• If a pad is tight, remove it and re-clean the bracket using the small wire brush.

Step 13: Reinstall the rear caliper

• Lower the caliper over the new pads by hand.
• Make sure the brake hose is not twisted.
• Install the two caliper guide pin bolts by hand first to avoid cross-threading.
• Use a 13mm socket and 3/8-inch drive torque wrench to tighten the guide pin bolts to Torque to 32 Nm (24 ft-lbs).

Step 14: Repeat on the other rear side

• Use the same 13mm socket, flat-blade screwdriver, small wire brush, and C-clamp or disc brake piston compressor to repeat Steps 4-13 on the other rear brake.
• Always replace rear brake pads as a complete left-and-right axle set.

Step 15: Reinstall the rear wheels

• Place each wheel back onto the studs by hand.
• Install the lug nuts by hand first.
• Use a 19mm socket and 3/8-inch drive ratchet to snug the lug nuts in a star pattern.

Step 16: Lower the Wrangler and torque the lug nuts

• Use the floor jack rated 3-ton minimum to lift the rear axle slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower the Wrangler until the tires touch the ground.
• Use a 19mm socket and 1/2-inch drive torque wrench to tighten the lug nuts in a star pattern to Torque to 129 Nm (95 ft-lbs).

Step 17: Pump the brake pedal

• Sit in the driver seat and press the brake pedal slowly 5-10 times until it feels firm.
• This moves the caliper pistons back out against the new pads.
• Do not drive until the brake pedal feels firm.

---

✅ After Repair

• ✅ Check the brake fluid reservoir and set the level between MIN and MAX if needed.
• ✅ Start the Wrangler and press the brake pedal again. It should feel firm, not sink to the floor.
• ✅ Test drive slowly in a safe area and confirm the Wrangler stops straight without grinding or pulling.
• ✅ Avoid hard braking for the first 200 miles unless needed for safety.
• ✅ Recheck lug nut torque after the first short drive using a 19mm socket and 1/2-inch drive torque wrench: Torque to 129 Nm (95 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $220-$380 (parts + labor)

DIY Cost: $45-$110 (parts only)

You Save: $175-$270 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
