🔧 Tucson - Ignition Coil Replacement

Replacing the ignition coils on your Tucson is a straightforward repair. The ignition coils sit on top of the spark plugs and create the high voltage needed to fire each plug. A bad coil can cause misfires, rough idle, poor acceleration, or a check engine light.

Difficulty Level: Beginner | Estimated Time: 30-60 minutes

---

⚠️ Safety & Precautions

• ⚠️ Let the engine cool completely before working. Hot engine parts can burn your hands.
• ⚠️ Disconnect the negative battery cable before unplugging ignition coils.
• ⚠️ Do not pull on wiring. Always release the connector tab first.
• ⚠️ Keep dirt and debris away from the spark plug wells.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 3/8-inch ratchet
• 3/8-inch extension 6-inch
• Torque wrench 3/8-inch drive
• Plastic trim removal tool
• Needle-nose pliers
• Compressed air duster
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Ignition coil - Qty: 1-4
• Dielectric grease - Qty: 1 small tube

Tip: If one coil has failed, you can replace just the failed coil. If mileage is high or multiple misfire codes are present, replacing all four coils is often smarter.

---

📋 Before You Begin

• Park your Tucson on level ground and set the parking brake.
• Turn the ignition off and remove the key from the vehicle.
• Open the hood and let the engine cool fully.
• Disconnect the negative battery cable using a 10mm socket.
• Take a photo of the coil locations before removal so everything goes back the same way.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Disconnect the Battery

• Put on safety glasses and nitrile gloves.
• Use a 10mm socket and 3/8-inch ratchet to loosen the negative battery terminal clamp.
• Move the negative cable aside so it cannot spring back and touch the battery post.
• Negative terminal is marked minus.

Step 2: Remove the Engine Cover

• The plastic engine cover is held by rubber grommets. A grommet is a rubber holder that grips a post.
• Use both hands to lift the cover straight upward.
• If it feels stuck, use a plastic trim removal tool to gently help lift the cover.
• Set the cover aside where it will not get stepped on.

Step 3: Locate the Ignition Coils

• The four ignition coils are lined up across the top of the engine.
• Each coil has one electrical connector and one mounting bolt.
• Use a compressed air duster to blow loose dirt away from the coil area before removal.
• Clean first, remove second.

Step 4: Unplug the Coil Connector

• Press the locking tab on the electrical connector with your thumb.
• If the tab is hard to press, use a plastic trim removal tool gently.
• Pull the connector straight back from the coil.
• If needed, use needle-nose pliers only on the connector body, not the wires.

Step 5: Remove the Coil Mounting Bolt

• Use a 10mm socket, 3/8-inch extension 6-inch, and 3/8-inch ratchet to remove the coil bolt.
• Place the bolt in a small safe spot so it does not fall into the engine bay.

Step 6: Remove the Ignition Coil

• Twist the coil gently left and right by hand to loosen the rubber boot. The boot is the long rubber part that reaches down to the spark plug.
• Pull the coil straight up and out of the spark plug well.
• Do not use metal pry tools on the coil.
• Inspect the old coil boot for oil, cracks, burning, or moisture.

Step 7: Prepare the New Coil

• Compare the new coil to the old coil. The shape, connector, bolt hole, and rubber boot should match.
• Apply a very small amount of dielectric grease inside the end of the rubber boot. Dielectric grease helps seal out moisture and prevents the boot from sticking later.
• Do not fill the boot with grease.
• A pea-size amount is enough.

Step 8: Install the New Coil

• Push the new ignition coil straight down into the spark plug well by hand.
• You should feel the boot seat onto the spark plug.
• Align the coil mounting hole with the bolt hole on the valve cover.

Step 9: Reinstall the Coil Bolt

• Start the bolt by hand first to avoid cross-threading. Cross-threading means the bolt is going in crooked and can damage the threads.
• Use a 10mm socket, 3/8-inch extension 6-inch, and torque wrench 3/8-inch drive to tighten the bolt.
• Torque to 9.8 Nm (87 in-lbs).
• Do not overtighten. The valve cover can be damaged.

Step 10: Reconnect the Electrical Connector

• Push the connector onto the new ignition coil until it clicks.
• Give the connector a gentle tug by hand to make sure it is locked.

Step 11: Replace the Remaining Coils if Needed

• Repeat Steps 4-10 for any other ignition coils you are replacing.
• Use the same 10mm socket, 3/8-inch extension 6-inch, and torque wrench 3/8-inch drive for each coil bolt.
• Torque each coil bolt to 9.8 Nm (87 in-lbs).

Step 12: Reinstall the Engine Cover

• Line up the plastic engine cover with the mounting posts.
• Push down firmly by hand until the cover seats into the rubber grommets.

Step 13: Reconnect the Battery

• Place the negative battery cable back on the battery post.
• Use a 10mm socket and 3/8-inch ratchet to tighten the terminal clamp snugly.
• Do not overtighten the battery terminal.

---

✅ After Repair

• Start your Tucson and let it idle for 1-2 minutes.
• Listen for smooth idle and check that the engine is not shaking.
• If the check engine light was on, a scan tool may be needed to clear stored misfire codes.
• Take a short test drive and confirm smooth acceleration.
• If a misfire remains, the spark plug, injector, wiring, or engine mechanical condition may need diagnosis.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$550 depending on whether one coil or all four are replaced

DIY Cost: $35-$260 parts only

You Save: $145-$290 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hour.

---
