🔧 Highlander - Front Windshield Wiper Blade Replacement

Replacing the front windshield wiper blades on your Highlander is a quick beginner-friendly repair. Fresh blades improve visibility, reduce streaking, and help prevent scratching the windshield.

Difficulty Level: Beginner | Estimated Time: 10-15 minutes

---

⚠️ Safety & Precautions

• ⚠️ Do not let the bare metal wiper arm snap back onto the windshield; it can crack the glass.
• ⚠️ Work with the ignition off and the wipers switched off.
• ⚠️ Place a towel on the windshield while each wiper arm is lifted for protection.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Microfiber towel
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front wiper blades - Driver: 26", Passenger: 20" - Qty: 2

---

📋 Before You Begin

• 🅿️ Park your Highlander on level ground and turn the ignition off.
• 🧼 Clean the lower windshield area with a microfiber towel so dirt does not scratch the glass.
• 🧤 Put on nitrile gloves and safety glasses.
• 📌 A wiper arm is the spring-loaded metal arm that holds the rubber blade against the windshield.
• 📌 A J-hook is the curved end of the wiper arm that locks into the wiper blade connector.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift the Driver Wiper Arm

• Use your hands to carefully lift the driver-side wiper arm away from the windshield.
• Use a microfiber towel and place it on the windshield under the lifted arm.
• Do not pull the arm too far. It only needs to stand up enough to access the blade.
• Keep one hand on the arm.

Step 2: Unlock the Old Driver Blade

• Use your fingers to find the small locking tab on the wiper blade connector.
• Press the locking tab while sliding the blade downward toward the base of the wiper arm.
• The blade will slide out of the J-hook once the lock releases.
• No torque spec applies; this part snaps on and off by hand.

Step 3: Remove the Old Driver Blade

• Use your hands to guide the old blade completely out of the J-hook.
• Keep the wiper arm raised and controlled with one hand.
• Set the old blade aside away from the windshield.
• Never release the bare arm.

Step 4: Install the New Driver Blade

• Use your hands to line up the 26" driver-side blade connector with the J-hook on the wiper arm.
• Slide the new blade upward into the J-hook until it clicks.
• Gently tug the blade with your hand to make sure it is locked in place.
• No torque spec applies; the connector must click and lock by hand.

Step 5: Lower the Driver Wiper Arm

• Use both hands to carefully lower the wiper arm back onto the windshield.
• Remove the microfiber towel once the blade is resting safely on the glass.
• Do not drop the arm onto the windshield.

Step 6: Replace the Passenger Blade

• Use your hands to lift the passenger-side wiper arm away from the windshield.
• Use the microfiber towel under the lifted arm to protect the glass.
• Press the locking tab with your fingers and slide the old blade downward out of the J-hook.
• Use your hands to install the new 20" passenger-side blade into the J-hook until it clicks.
• Gently tug the blade by hand to confirm it is locked.
• Carefully lower the arm back onto the windshield.

Step 7: Check Blade Position

• Use your hands to make sure both blades sit flat against the windshield.
• Check that the rubber edge is not twisted or folded.
• Make sure the driver and passenger blades are not swapped; the driver side uses the longer 26" blade.

---

✅ After Repair

• 💧 Spray windshield washer fluid and run the wipers for 5-10 seconds.
• 👀 Check for streaking, skipping, chattering, or loose movement.
• 🔁 If a blade streaks, wipe the rubber edge with a clean microfiber towel and retest.
• ✅ Confirm both blades park normally at the bottom of the windshield.

---

💰 DIY vs Shop Cost

Shop Cost: $45-$90 (parts + labor)

DIY Cost: $20-$45 (parts only)

You Save: $25-$45 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.2-0.3 hours.

---
