🔧 Ascent - Front Windshield Wiper Blade Replacement

This is an easy first DIY job. Replace both front blades together: 26 inches on the driver side and 20 inches on the passenger side. The front wiper set is already showing in the parts sidebar.

Difficulty Level: Beginner | Estimated Time: 10-15 minutes

---

⚠️ Safety & Precautions

• ⚠️ Turn the ignition off and keep the wiper control in the OFF position.
• ⚠️ Hold each metal wiper arm securely whenever its blade is removed.
• ⚠️ Never release a bare wiper arm against the glass. The spring-loaded arm can crack the windshield.
• ⚠️ Replace one blade at a time so the other arm remains safely lowered.
• ⚠️ Battery disconnection and EyeSight calibration are not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Microfiber towel
• Safety glasses
• Nitrile work gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 26-inch front driver-side wiper blade - Qty: 1
• 20-inch front passenger-side wiper blade - Qty: 1

Replace both front blades as a pair. A matched 26-inch and 20-inch beam-blade set is the cleanest buy. Nobody misses streaky glass once it starts raining.

---

📋 Before You Begin

• Park your Ascent on level ground and switch the ignition completely off.
• Confirm the wiper stalk is in the OFF position.
• Close the hood before lifting the wiper arms.
• Place a folded microfiber towel on the windshield beneath the blade being replaced.
• No infotainment menu, scan tool, battery disconnect, or special service mode is needed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise the Driver-Side Wiper Arm

• Use your gloved hand to lift the driver-side wiper arm away from the windshield.
• Stop when the arm remains raised without forcing it farther.
• Keep the microfiber towel positioned beneath the blade.
• Work on only one arm at a time.

Step 2: Release the Old Driver-Side Blade

• Rotate the blade slightly so you can see the connection between the blade and arm.
• Use your thumb to press the small release button or locking tab on the connector.
• While holding the release, slide the blade toward the base of the wiper arm.
• Guide the blade free without twisting or bending the metal arm.

Step 3: Protect the Windshield

• Use your gloved hand to keep control of the bare wiper arm.
• Gently lower the arm onto the folded microfiber towel while preparing the new blade.
• Do not allow the metal end to touch the windshield directly.

Step 4: Install the 26-Inch Driver-Side Blade

• Remove the protective packaging from the 26-inch blade.
• If the blade includes several adapters, use the preinstalled push-button adapter specified for your Ascent.
• Use your gloved hand to raise the wiper arm and align its end with the blade connector.
• Slide the blade into the connector until the locking tab makes an audible click.
• Pull gently on the blade to confirm it is locked.
• No fastener is used, so there is no torque specification.

Step 5: Lower the Driver-Side Wiper

• Use both hands to rotate the blade until it lies flat against the windshield.
• Lower the arm gently onto the glass.
• Do not let the arm snap down.

Step 6: Replace the Passenger-Side Blade

• Move the microfiber towel beneath the passenger-side blade.
• Use your gloved hand to raise the passenger-side wiper arm.
• Press its release button or locking tab and slide the old blade off.
• Install the 20-inch passenger-side blade in the same direction as the old blade.
• Slide it into place until the connector clicks.
• Pull gently to verify the lock, then lower the arm carefully.

Step 7: Remove the Blade Protectors

• Use your fingers to remove any plastic shipping cover from each rubber wiping edge.
• Check that neither blade is upside down, loose, or touching the windshield trim.

---

✅ After Repair

• Turn the ignition on only after both wiper arms are lowered completely.
• Spray windshield-washer fluid and operate the wipers through several complete sweeps.
• Confirm both blades move quietly, clear the glass evenly, and remain securely attached.
• If a blade skips or streaks, switch the ignition off and recheck that its connector clicked fully into place.
• Clean road film from the windshield with mild glass cleaner if new blades still leave streaks. Subaru also recommends checking the blades regularly for damaged rubber, chatter, or persistent streaking. parts.subaru.com

---

💰 DIY vs Shop Cost

Shop Cost: $45-$90 equivalent, depending on local blade and labor pricing

DIY Cost: $20-$45 equivalent for both blades

You Save: Approximately $25-$45 by doing it yourself!

Local labor rates vary. A shop normally needs about 0.1-0.2 hour for this replacement.

---
