🔧 F-150 - Front Windshield Wiper Blade Replacement

Replacing both front wiper blades restores clear visibility and helps prevent windshield scratches. Your F-150 uses one 22-inch blade on each side and normally does not require a wiper service mode.

Assumption: The original J-hook-style wiper arms are installed.

Difficulty Level: Beginner | Estimated Time: 10-15 minutes

---

⚠️ Safety & Precautions

• ⚠️ Do not allow a raised metal wiper arm to snap against the windshield.
• 🧤 Keep your fingers away from the spring-loaded hinge at the base of each arm.
• 🔑 Switch the ignition and wipers off before beginning.
• 🔋 Battery disconnection is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Work gloves
• Thick windshield-protection towel

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 22-inch front windshield wiper blade - Driver: 22" - Qty: 1
• 22-inch front windshield wiper blade - Passenger: 22" - Qty: 1

Replace in pairs for even wiping performance.

---

📋 Before You Begin

• 🅿️ Park your F-150 on level ground and engage the parking brake.
• 🔑 Turn off the wipers, allow them to return to their normal parked position, and switch off the ignition.
• 🧼 Clean dirt away from the lower windshield and wiper arms.
• 📱 No infotainment menu, scan tool, or wiper service mode is required.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Protect the Windshield

• Put on the safety glasses and work gloves.
• Place the thick windshield-protection towel beneath the driver-side blade.
• The towel helps protect the glass if the spring-loaded arm slips.

Step 2: Raise the Driver-Side Wiper Arm

• Use your gloved hand to lift the driver-side arm away from the windshield until it remains raised.
• Hold the arm securely while working. Do not bend or twist it.
• Replace one blade at a time.

Step 3: Release the Old Driver-Side Blade

• Rotate the blade so it sits nearly perpendicular to the arm.
• Locate the small plastic release tab where the blade meets the curved J-shaped end of the arm. A J-hook is the curved attachment at the end of the metal arm.
• Use your gloved thumb to press the release tab.
• While holding the tab, slide the blade downward toward the base of the arm.
• Guide the blade around and out of the J-hook.

Step 4: Install the New Driver-Side Blade

• Remove the protective packaging from one 22-inch front windshield wiper blade.
• If the blade includes several adapters, use the included J-hook adapter. Do not force an incorrect adapter onto the arm.
• Use your gloved hands to pass the J-hook through the large opening in the blade adapter.
• Slide the blade upward into the hook until the locking tab makes an audible click.
• Pull gently on the blade to confirm that it is locked.

Step 5: Lower the Driver-Side Wiper Arm

• Rotate the blade until its rubber edge faces the windshield.
• Use both gloved hands to lower the arm slowly onto the glass.
• Do not release the arm until the blade is resting against the windshield.

Step 6: Replace the Passenger-Side Blade

• Move the thick windshield-protection towel beneath the passenger-side blade.
• Use your gloved hand to raise the passenger-side arm.
• Press the adapter release tab and slide the old blade downward and out of the J-hook.
• Install the second 22-inch front windshield wiper blade and slide it into the hook until it clicks.
• Pull gently to verify that the blade is secure, then lower the arm carefully.

Step 7: Check the Installation

• Use your gloved hands to confirm both blades sit flat against the windshield.
• Check that neither adapter is loose and that each rubber wiping edge faces the glass.
• Remove the thick windshield-protection towel before testing the wipers.

---

✅ After Repair

• 💧 Apply windshield-washer fluid using the washer control, then operate the wipers at low speed.
• 👀 Confirm both blades sweep smoothly without skipping, streaking, striking the trim, or separating from the arms.
• 🛑 Stop the wipers immediately if a blade shifts. Switch off the ignition and lock its adapter completely.
• 🧼 Clean the new rubber edges with a damp cloth if light streaking remains.

---

💰 DIY vs Shop Cost

Shop Cost: ₹2,000-₹4,500 (parts + installation)

DIY Cost: ₹1,200-₹3,000 (parts only)

You Save: ₹800-₹1,500 by doing it yourself!

Local labor and imported blade prices vary. This repair takes a shop approximately 0.1-0.3 hours.

---
