🔧 Mustang - Front Strut Replacement

This repair replaces the front MacPherson struts on your Mustang. The front strut is the large suspension unit that supports the spring, controls bounce, and helps keep the tire planted on the road.

For a beginner, the safest approach is to install complete loaded front strut assemblies. A loaded strut already includes the spring, mount, and strut together, so you avoid compressing the coil spring.

Difficulty Level: Intermediate | Estimated Time: 2.5-4 hours

---

⚠️ Safety & Precautions

• ⚠️ The front coil spring is under very high tension. Do not remove the center strut shaft nut unless the spring is safely compressed with the correct spring compressor.
• ⚠️ For a first-time DIYer, use complete loaded strut assemblies instead of swapping springs onto bare struts.
• ⚠️ Support your Mustang with jack stands only. Never work under a vehicle supported only by a floor jack.
• ⚠️ Replace front struts in pairs. Replacing only one side can cause uneven handling and braking feel.
• ⚠️ Do not let the brake caliper, brake hose, or ABS wire hang by tension while the knuckle is loose.
• ⚠️ An alignment is required after this repair because the strut-to-knuckle position affects front wheel alignment.
• Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench rated to 200 ft-lbs
• 3/8-inch drive ratchet
• 13mm socket
• 15mm socket
• 18mm socket
• 21mm socket
• 22mm socket
• 13mm wrench
• 15mm wrench
• 18mm wrench
• 21mm wrench
• 22mm wrench
• Impact wrench optional
• Trim clip removal tool
• Paint marker
• Rubber mallet
• Pry bar 18-inch
• Bungee cord
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front loaded strut assemblies - Left: 1, Right: 1
• Front strut-to-knuckle bolts - Qty: 4
• Front strut-to-knuckle nuts - Qty: 4
• Front stabilizer bar link nuts - Qty: 2
• Front upper strut mount nuts - Qty: 6

Replace in pairs: Always replace both front struts together.

---

📋 Before You Begin

• Park your Mustang on level ground.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Open the hood before lifting the car. You will need access to the upper strut mount nuts.
• Loosen the front lug nuts slightly before lifting the vehicle.
• A loaded strut assembly means the spring, strut, and top mount are already assembled as one safe replacement unit.
• A torque wrench tightens fasteners to a specific amount. This is important for suspension safety.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Wheel Lug Nuts

• Use a 21mm socket and 1/2-inch drive breaker bar to loosen each front wheel lug nut about half a turn.
• Do not remove the lug nuts yet.
• Loosen wheels while tires touch ground.

Step 2: Raise and Support the Front of the Car

• Use a floor jack rated 2-ton minimum to lift the front of your Mustang at the proper front jacking point.
• Place jack stands rated 2-ton minimum under the correct front support points.
• Slowly lower the car onto the jack stands.
• Gently shake the vehicle by hand to confirm it is stable before working.

Step 3: Remove the Front Wheels

• Use a 21mm socket to remove the loosened lug nuts.
• Remove both front wheels and set them flat on the ground.

Step 4: Mark the Strut-to-Knuckle Position

• Use a paint marker to draw alignment marks across the lower strut bracket and steering knuckle.
• The steering knuckle is the large metal part that holds the wheel hub and connects to the strut.
• These marks help you install the new strut close enough to drive carefully to an alignment shop.

Step 5: Disconnect the Brake Hose and ABS Wire Brackets

• Use a 13mm socket or 15mm socket as equipped to remove the brake hose bracket bolt from the strut.
• Use a trim clip removal tool to gently release any ABS wire clips attached to the strut.
• Move the hose and wire aside carefully. Do not pull or stretch them.

Step 6: Disconnect the Stabilizer Bar Link from the Strut

• The stabilizer bar link is the small vertical link attached to the strut that helps reduce body roll in turns.
• Use an 18mm socket and 18mm wrench to remove the stabilizer bar link nut from the strut bracket.
• If the stud spins, hold the stud with the matching internal hex or wrench feature while turning the nut with the 18mm wrench.
• Move the link away from the strut.

Step 7: Support the Steering Knuckle

• Use a bungee cord to support the steering knuckle so it cannot fall outward when the strut bolts are removed.
• You can also use the floor jack rated 2-ton minimum lightly under the control arm to support the suspension.
• Do not lift the car off the jack stand.

Step 8: Remove the Lower Strut-to-Knuckle Bolts

• Use a 21mm socket, 22mm socket, 21mm wrench, or 22mm wrench as fitted to remove the two large lower strut-to-knuckle nuts and bolts.
• Use a rubber mallet to tap the bolts out if they are snug.
• Use a pry bar 18-inch gently if the knuckle needs help separating from the strut bracket.
• Keep one hand on the knuckle so it does not swing outward.

Step 9: Remove the Upper Strut Mount Nuts

• From under the hood, locate the three upper strut mount nuts on the strut tower.
• Use a 13mm socket to remove the three upper strut mount nuts.
• Hold the strut with your other hand as the last nut comes off.
• Do not remove the large center nut on the strut assembly.

Step 10: Remove the Old Strut Assembly

• Lower the strut assembly out through the wheel well by hand.
• Use mechanic gloves because the bracket edges can be sharp.
• Compare the old strut to the new loaded strut assembly before installation.
• Make sure the left and right assemblies are on the correct side.

Step 11: Install the New Loaded Strut Assembly

• Guide the new strut assembly up into the strut tower by hand.
• Install the three new upper strut mount nuts by hand first.
• Use a 13mm socket to snug the upper nuts evenly.
• Do not fully torque them until the lower bolts are installed.

Step 12: Attach the Strut to the Steering Knuckle

• Align the lower strut bracket with the steering knuckle using your paint marks as a guide.
• Install the two new strut-to-knuckle bolts and nuts by hand.
• Use a 21mm socket, 22mm socket, 21mm wrench, or 22mm wrench as fitted to tighten the lower fasteners.
• Torque the strut-to-knuckle fasteners to 184 lb-ft (250 Nm).

Step 13: Torque the Upper Strut Mount Nuts

• Use a 13mm socket and torque wrench rated to 200 ft-lbs to tighten the upper strut mount nuts.
• Torque the upper strut mount nuts to 46 lb-ft (63 Nm).
• Tighten the nuts evenly in a triangle pattern.

Step 14: Reconnect the Stabilizer Bar Link

• Insert the stabilizer bar link stud into the new strut bracket.
• Install the new stabilizer bar link nut by hand.
• Use an 18mm socket and 18mm wrench to tighten it.
• Torque the stabilizer bar link nut to 85 lb-ft (115 Nm).

Step 15: Reattach the Brake Hose and ABS Wire Brackets

• Use a 13mm socket or 15mm socket as equipped to reinstall the brake hose bracket bolt.
• Torque the brake hose bracket bolt to 18 lb-ft (24 Nm).
• Use a trim clip removal tool if needed to guide ABS wire clips back into place.
• Make sure the brake hose and ABS wire are not twisted or stretched.

Step 16: Repeat on the Other Front Side

• Repeat Steps 4 through 15 on the opposite front strut.
• Use the same tools and torque specs.
• Finish one side before starting the other.

Step 17: Reinstall the Front Wheels

• Place each wheel back onto the hub.
• Thread the lug nuts by hand first to avoid cross-threading.
• Use a 21mm socket to snug the lug nuts in a star pattern.

Step 18: Lower the Car and Torque the Lug Nuts

• Use the floor jack rated 2-ton minimum to raise the car slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower the car until the tires touch the ground.
• Use a 21mm socket and torque wrench rated to 200 ft-lbs to torque the lug nuts in a star pattern.
• Torque the wheel lug nuts to 150 lb-ft (204 Nm).

---

✅ After Repair

• ✅ Bounce each front corner by hand. The car should settle quickly without repeated bouncing.
• ✅ Turn the steering wheel left and right while parked. Listen for clunks, spring popping, or rubbing.
• ✅ Test drive slowly first. Check braking, steering feel, and any unusual noises.
• ✅ Recheck lug nut torque after the first short drive using a 21mm socket and torque wrench.
• ✅ Schedule a four-wheel alignment as soon as possible. Do not skip this after strut replacement.
• ✅ If the steering wheel is off-center or the car pulls, drive only carefully to the alignment shop.

---

💰 DIY vs Shop Cost

Shop Cost: $850-$1,400 (parts + labor + alignment)

DIY Cost: $300-$700 (parts only, alignment not included)

You Save: $400-$750 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours plus alignment time.

---
