🔧 Escape - Front Lower Control Arm Bushing Replacement

On your Escape, the front suspension bushings are serviced most cleanly by replacing the complete front lower control arm assembly. This avoids needing a hydraulic press and gives you new bushings and a new ball joint in one repair.

This repair helps fix clunks, loose steering feel, wandering, and uneven tire wear caused by worn control arm bushings.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Never work under your Escape while it is supported only by a jack. Always use jack stands.
• ⚠️ Wear safety glasses. Rust, dirt, and metal flakes often fall when suspension bolts are removed.
• ⚠️ Do not loosen the strut center nut. The strut contains a compressed spring.
• ⚠️ Keep the brake hose and CV axle boot from being stretched or pulled while the control arm is separated.
• ⚠️ Final-tighten the control arm bushing bolts at normal ride height. Tightening them while the suspension hangs can twist and damage the new bushings.
• ⚠️ A wheel alignment is required after this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• 19mm lug nut socket
• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench
• 3/8-inch drive ratchet
• 15mm socket
• 18mm socket
• 21mm socket
• 15mm wrench
• 18mm wrench
• 21mm wrench
• Ball joint separator tool (specialty)
• 18-inch pry bar
• Rubber mallet
• Needle-nose pliers
• Paint marker
• Penetrating oil spray
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front lower control arm assembly - Qty: 1 per side
• Front lower control arm assemblies - Replace in pairs if both sides are worn - Qty: 2
• Lower ball joint pinch bolt and nut - Qty: 1 per side
• Front lower control arm mounting bolts - Qty: 2 per side
• Sway bar end link nut - Qty: 1 per side if removed

---

📋 Before You Begin

• Park your Escape on flat, solid ground.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Spray penetrating oil spray on the control arm bolts, ball joint pinch bolt, and sway bar end link nut. Let it soak for 10-15 minutes.
• Use a paint marker to mark where the old control arm bolts sit. This helps keep alignment close enough for a short drive to the alignment shop.
• A ball joint separator is a tool that safely separates the ball joint from the steering knuckle without damaging nearby parts.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Wheel

• Use a 19mm lug nut socket and 1/2-inch drive breaker bar to loosen the front lug nuts half a turn.
• Do not remove the lug nuts yet.
• Loosen before lifting the vehicle.

Step 2: Lift and Support Your Escape

• Use a floor jack rated 2-ton minimum to lift the front of the vehicle.
• Place jack stands rated 2-ton minimum under the approved front support points.
• Lower the vehicle slowly onto the jack stands.
• Gently shake the vehicle by hand to confirm it is stable.

Step 3: Remove the Wheel

• Use the 19mm lug nut socket to remove the lug nuts.
• Remove the wheel.
• Place the wheel flat under the side of the vehicle as an extra safety backup.

Step 4: Disconnect the Sway Bar End Link if Needed

• The sway bar end link is a small rod that connects the suspension to the sway bar to reduce body roll.
• If the end link blocks the control arm from moving, use a 15mm socket and 15mm wrench to remove the nut.
• Move the end link aside by hand.

Step 5: Remove the Lower Ball Joint Pinch Bolt

• The ball joint is the pivot point between the lower control arm and the steering knuckle.
• Use an 18mm socket and 18mm wrench to remove the lower ball joint pinch bolt and nut.
• If the bolt is stuck, spray more penetrating oil spray and work the bolt slowly back and forth with the 18mm socket.

Step 6: Separate the Ball Joint from the Steering Knuckle

• Use a ball joint separator tool to loosen the ball joint from the steering knuckle.
• Use an 18-inch pry bar to gently push the lower control arm downward.
• Guide the ball joint stud out of the knuckle.
• Do not pull the brake hose tight.
• Do not let the CV axle hang or bind.
• Move slowly and protect rubber boots.

Step 7: Remove the Control Arm Mounting Bolts

• Use a paint marker to mark the front and rear control arm bolt positions.
• Use an 18mm socket and 18mm wrench to remove the front control arm mounting bolt.
• Use a 21mm socket and 21mm wrench to remove the rear control arm mounting bolt.
• Hold the control arm with one hand as the last bolt comes out.

Step 8: Remove the Old Control Arm

• Use an 18-inch pry bar to gently work the old control arm out of the subframe mounting pockets.
• Use a rubber mallet for light tapping only if it is stuck.
• Compare the old and new control arms before installation.
• Make sure the bushing locations, ball joint position, and mounting holes match.

Step 9: Install the New Control Arm

• Slide the new front lower control arm assembly into the subframe pockets by hand.
• Install the front and rear mounting bolts by hand first.
• Use an 18mm socket and 21mm socket to snug the bolts only.
• Do not fully tighten the bushing bolts yet.

Step 10: Reconnect the Ball Joint

• Use an 18-inch pry bar to guide the lower ball joint stud into the steering knuckle.
• Install the new ball joint pinch bolt and nut by hand.
• Use an 18mm socket and 18mm wrench to tighten the pinch bolt.
• Torque to 63 Nm (46 ft-lbs)

Step 11: Reconnect the Sway Bar End Link

• If removed, place the sway bar end link back into position.
• Use a 15mm socket and 15mm wrench to tighten the sway bar end link nut.
• Torque to 55 Nm (41 ft-lbs)

Step 12: Load the Suspension

• Place the floor jack rated 2-ton minimum under the outer end of the lower control arm.
• Raise the jack slowly until the suspension is close to normal ride height.
• Normal ride height means the control arm is positioned like it would be when the vehicle is sitting on the ground.
• Keep fingers clear of pinch points.

Step 13: Final-Tighten the Control Arm Bolts

• Use an 18mm socket and 18mm wrench to tighten the front lower control arm mounting bolt.
• Torque to 175 Nm (129 ft-lbs)
• Use a 21mm socket and 21mm wrench to tighten the rear lower control arm mounting bolt.
• Torque to 175 Nm (129 ft-lbs)
• Loaded tightening prevents bushing twist.

Step 14: Reinstall the Wheel

• Put the wheel back on by hand.
• Use the 19mm lug nut socket to snug the lug nuts in a star pattern.
• Use the floor jack rated 2-ton minimum to lift the vehicle slightly.
• Remove the jack stands rated 2-ton minimum.
• Lower the vehicle to the ground.
• Use a 1/2-inch drive torque wrench and 19mm lug nut socket to tighten the lug nuts in a star pattern.
• Torque to 135 Nm (100 ft-lbs)

---

✅ After Repair

• ✅ Drive slowly around the block first and listen for clunks, pops, or rubbing.
• ✅ If the steering wheel is crooked, the vehicle pulls, or warning lights appear, stop driving and inspect the repair.
• ✅ Get a professional wheel alignment as soon as possible.
• ✅ Recheck lug nut torque after 50-100 miles using a 1/2-inch drive torque wrench and 19mm lug nut socket.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 per side, or $800-$1,400 for both sides including alignment

DIY Cost: $120-$300 per side, or $240-$600 for both sides in parts

You Save: $300-$800 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours plus alignment time.

---
