🔧 Malibu - Front Lower Ball Joint Replacement

On your Malibu, the front lower ball joint is supplied and serviced with the complete lower control arm. Replacing the control-arm assembly avoids pressing or modifying the factory joint and also renews both control-arm bushings.

Assumption: These instructions cover one front lower control arm; repeat on the opposite side if needed.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours per side

---

⚠️ Safety & Precautions

• ⚠️ Support your Malibu with jack stands. Never work beneath a vehicle supported only by a floor jack.
• ⚠️ Do not strike the steering knuckle, axle, or ball-joint stud with a hammer.
• ⚠️ Support the steering knuckle so the brake hose and CV axle are not stretched.
• ⚠️ Final control-arm fastener tightening must occur at normal ride height. Tightening with the suspension hanging can damage the new bushings.
• ⚠️ Use new torque-to-yield mounting fasteners. These fasteners stretch during final tightening and should not be reused.
• ⚠️ An alignment is required after replacing a lower control arm.
• ⚠️ Battery disconnection is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench rated 20-200 Nm
• 1/2-inch drive angle gauge
• 10mm socket
• 18mm socket
• 21mm socket
• 24mm socket
• 18mm combination wrench
• 21mm combination wrench
• 24mm combination wrench
• 6-inch socket extension
• Front-end ball-joint separator (specialty)
• Small flat-blade screwdriver
• Medium pry bar
• Rubber mallet
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Hydraulic support jack rated 1-ton minimum
• Mechanic gloves
• Safety glasses
• Wire brush

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front lower control-arm assembly with ball joint - Qty: 1 per side
• Lower control-arm mounting bolt and nut set - Qty: 1 per side
• Lower ball-joint stud nut - Qty: 1 per side

Replace both sides if both ball joints have looseness, damaged boots, or similar mileage-related wear.

---

📋 Before You Begin

• 📍 Park your Malibu on firm, level ground. Shift into Park, apply the parking brake, and switch off the ignition.
• 📍 Chock both rear wheels with wheel chocks.
• 📍 Loosen the front wheel nuts approximately one-half turn with a 21mm socket and breaker bar.
• 📍 A torque angle means rotating a fastener an additional specified number of degrees after reaching the initial torque.
• 📍 Arrange a professional four-wheel alignment immediately after the repair.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Support the Front

• Use the floor jack at the front subframe lifting point to raise your Malibu.
• Place the jack stands beneath the reinforced front support points, then lower the vehicle carefully onto them.
• Gently rock the body to verify that both stands are stable before continuing.

Step 2: Remove the Front Wheel

• Use the 21mm socket and breaker bar to remove the five wheel nuts.
• Remove the wheel and place it flat away from your work area.

Step 3: Inspect the New Control Arm

• Compare the new control-arm assembly with the removed-side location before taking anything apart.
• Confirm that the ball-joint stud, mounting holes, bushings, and arm shape match.
• Keep the protective cap on the new ball-joint stud until installation.

Step 4: Support the Steering Knuckle

• Place the hydraulic support jack beneath the steering knuckle without contacting the brake rotor shield.
• Raise it only enough to support the knuckle. Do not lift your Malibu off the jack stand.
• The steering knuckle is the metal carrier holding the wheel hub, brake, and suspension connections.

Step 5: Disconnect the Lower Ball Joint

• Use the wire brush to clean exposed threads on the ball-joint stud.
• Use the correctly fitting 18mm or 21mm socket and matching wrench to remove the lower ball-joint nut; fastener size can vary with the installed service part.
• Install the front-end ball-joint separator between the control arm and steering knuckle. A separator safely pushes the tapered stud out of its matching hole.
• Tighten the separator until the taper releases, then remove the tool.
• Use the hydraulic support jack to control the knuckle while pulling the control arm downward with the medium pry bar.
• Do not allow the knuckle to hang from the brake hose or CV axle.

Step 6: Remove the Lower Control Arm

• Use the 18mm or 21mm socket and matching wrench to remove the front control-arm bushing fastener.
• Use the 18mm or 21mm socket and matching wrench to remove the rear control-arm bushing fastener or fasteners.
• Note each fastener’s direction before removal. Take a picture if necessary.
• Use the medium pry bar and rubber mallet to work the control arm out of the subframe brackets.
• Do not bend the brackets or pry against brake, steering, or fuel lines.

Step 7: Install the New Control Arm

• Remove the protective cap from the new ball-joint stud.
• Position the new control arm in the subframe brackets.
• Install new bushing fasteners by hand, but leave them loose enough for the arm to rotate.
• Guide the ball-joint stud into the steering knuckle using the hydraulic support jack and medium pry bar as needed.
• Install the new ball-joint nut by hand. Do not use an impact wrench.

Step 8: Tighten the Ball-Joint Connection

• Use the torque wrench with the correctly fitting socket to tighten the new ball-joint stud nut.
• Torque to 50 Nm (37 ft-lbs), then rotate an additional 60 degrees with the angle gauge.
• If the replacement control-arm manufacturer supplies a different torque specification, follow the specification packaged with that arm.
• Confirm the stud is fully seated and the rubber boot is not twisted or pinched.

Step 9: Load the Suspension at Ride Height

• Place the hydraulic support jack beneath the outer end of the control arm.
• Raise the arm until the hub center is approximately at its normal position relative to the fender.
• Do not lift your Malibu away from the jack stand.
• Ride-height tightening protects the new rubber bushings.

Step 10: Tighten the Control-Arm Fasteners

• Use the torque wrench, matching socket, wrench, and angle gauge while the suspension remains loaded.
• Torque the front control-arm bushing fastener to 100 Nm (74 ft-lbs), then rotate an additional 75 degrees.
• Torque each rear control-arm bracket fastener to 58 Nm (43 ft-lbs).
• Use the exact instructions supplied with the replacement fastener kit if its fastener design differs from the factory arrangement.
• Slowly lower and remove the hydraulic support jack.

Step 11: Reinstall the Wheel

• Install the wheel and start all five wheel nuts by hand.
• Use the 21mm socket to snug the nuts in a star pattern. Do not fully tighten them while the vehicle is raised.

Step 12: Lower the Vehicle

• Use the floor jack to raise your Malibu slightly and remove both jack stands.
• Lower the vehicle completely onto the ground.
• Use the 21mm socket and torque wrench to tighten the wheel nuts in a star pattern to 140 Nm (103 ft-lbs).

---

✅ After Repair

• ✅ Turn the steering wheel fully left and right while stationary. Confirm there is no binding, rubbing, or unusual noise.
• ✅ Check that the ball-joint boot remains seated and that every fastener is installed.
• ✅ Drive slowly in a safe area and listen for clunks. Stop immediately if the steering feels loose or unstable.
• ✅ Have a four-wheel alignment performed before normal driving to prevent tire wear and poor handling.
• ✅ Recheck the wheel-nut torque after approximately 80-160 km.

---
