🔧 CX-5 - Front Brake Pad Replacement

This repair replaces the front brake pads on your CX-5. Front pads wear faster than rear pads because they do most of the stopping, and replacing them before they get too thin protects the rotors from damage.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

Assumption: Front rotors are reusable and not being replaced.

---

⚠️ Safety & Precautions

• 🧤 Wear safety glasses and gloves; brake dust and brake cleaner can irritate skin and eyes.
• 🚗 Support your CX-5 with jack stands before removing any wheel. Never rely on the jack alone.
• 🛑 Do not press the brake pedal while the caliper is removed.
• 🔥 Brakes can be very hot after driving. Let them cool before starting.
• ⚠️ Open the brake fluid reservoir cap carefully before compressing the caliper piston. Brake fluid can damage paint.
• 🔋 Battery disconnect is not required for front brake pads on your CX-5.
• ℹ️ The electric parking brake service mode is for rear brakes only, not the front pads.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 21mm lug nut socket
• Ratchet wrench 3/8-inch drive
• 17mm wrench
• 14mm socket
• 17mm socket
• Breaker bar 1/2-inch drive
• Torque wrench 1/2-inch drive
• Torque wrench 3/8-inch drive
• Disc brake piston compressor tool (specialty)
• Flathead screwdriver medium
• Brake caliper hanger hook (specialty)
• Wire brush small
• Brake cleaner aerosol
• Shop towels
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit - Qty: 1
• Brake caliper slide pin grease - Qty: 1
• High-temperature brake lubricant - Qty: 1
• DOT 3 brake fluid - Qty: 1 bottle

---

📋 Before You Begin

• 🅿️ Park your CX-5 on level ground and shift to Park.
• 🧱 Place wheel chocks behind the rear wheels.
• 🔓 Leave the parking brake off during the front brake job.
• 🛞 Loosen the front lug nuts slightly before lifting the vehicle.
• 🧴 Open the hood and locate the brake fluid reservoir. Clean around the cap with a shop towel before opening it.
• 📏 Check brake fluid level. If it is near MAX, remove a small amount with a clean suction tool before compressing the caliper piston.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Wheel Lug Nuts

• Use a 21mm lug nut socket and breaker bar 1/2-inch drive to loosen each front lug nut about 1/2 turn.
• Do not remove the lug nuts yet.
• Break them loose before lifting.

Step 2: Raise and Support the Front of the Vehicle

• Use a floor jack rated 3-ton minimum at the front center jacking point.
• Place jack stands rated 3-ton minimum under the proper front side support points.
• Slowly lower your CX-5 onto the jack stands.
• Gently shake the vehicle to confirm it is stable before working near the wheels.

Step 3: Remove the Front Wheels

• Use the 21mm lug nut socket to remove the loosened lug nuts.
• Remove both front wheels and place them flat under the vehicle as an extra safety backup.

Step 4: Inspect the Brake Assembly

• Use a flashlight if needed and inspect the rotor surface, caliper, rubber brake hose, and pad thickness.
• A caliper is the clamp-shaped part that squeezes the brake pads against the rotor.
• If the rotor has deep grooves, heavy rust scaling, or vibration while braking, replace or resurface the rotors.

Step 5: Remove the Lower Caliper Slide Bolt

• Use a 17mm wrench to hold the slide pin if it tries to spin.
• Use a 14mm socket and ratchet wrench 3/8-inch drive to remove the lower caliper slide bolt.
• A slide pin lets the caliper move side-to-side so both pads wear evenly.

Step 6: Swing the Caliper Up

• Use a flathead screwdriver medium to gently pry the caliper upward if it is snug.
• Swing the caliper up and support it with a brake caliper hanger hook.
• Do not let the caliper hang by the rubber brake hose.

Step 7: Remove the Old Brake Pads

• Slide the inner and outer brake pads out of the caliper bracket by hand.
• Use a flathead screwdriver medium only if the pads are stuck.
• Note the pad wear sensor or squealer position before removing the pads.

Step 8: Remove and Clean the Pad Hardware

• Use a flathead screwdriver medium to remove the old stainless pad clips from the caliper bracket.
• Use a wire brush small to clean rust and dirt from the bracket where the clips sit.
• Use brake cleaner aerosol and shop towels to clean the contact areas.
• Pad clips are thin metal guides that help the pads slide smoothly.

Step 9: Install New Brake Pad Hardware

• Install the new front brake pad hardware kit clips into the caliper bracket by hand.
• Apply a very thin layer of high-temperature brake lubricant to the pad contact points on the clips.
• Do not get lubricant on the pad friction material or rotor surface.
• Less grease is better here.

Step 10: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use a disc brake piston compressor tool to slowly push the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing the piston so it does not overflow.
• The piston is the round part inside the caliper that pushes the inner pad.

Step 11: Lubricate the Slide Pins

• Pull the accessible slide pin out by hand.
• Wipe it clean with shop towels.
• Apply a light coat of brake caliper slide pin grease.
• Push the slide pin back into the rubber boot until it moves smoothly.
• Repeat for the other slide pin if accessible.

Step 12: Install the New Front Brake Pads

• Install the new inner and outer pads into the caliper bracket by hand.
• Make sure the pads slide freely in the new clips.
• If a pad is tight, remove it and clean the bracket again with the wire brush small.

Step 13: Reinstall the Caliper

• Swing the caliper down over the new pads by hand.
• Install the lower caliper slide bolt by hand first to avoid cross-threading.
• Use the 17mm wrench to hold the slide pin if needed.
• Use the 14mm socket and torque wrench 3/8-inch drive to tighten the caliper slide bolt to Torque to 28-34 Nm (21-25 ft-lbs).

Step 14: Repeat on the Other Front Side

• Repeat Steps 4 through 13 on the other front brake.
• Always replace front brake pads in pairs, left and right together.

Step 15: Reinstall the Front Wheels

• Put each wheel back onto the hub by hand.
• Install the lug nuts by hand first.
• Use the 21mm lug nut socket to snug the lug nuts in a star pattern.

Step 16: Lower the Vehicle and Torque the Lug Nuts

• Use the floor jack rated 3-ton minimum to lift slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower your CX-5 until the tires touch the ground.
• Use the 21mm lug nut socket and torque wrench 1/2-inch drive to tighten the lug nuts in a star pattern to Torque to 108-147 Nm (80-108 ft-lbs).

Step 17: Pump the Brake Pedal

• Before driving, press the brake pedal slowly several times until it feels firm.
• This moves the caliper pistons back out against the new pads.
• If the pedal feels soft or sinks, do not drive until the issue is corrected.

Step 18: Check Brake Fluid Level

• Use shop towels to clean around the brake fluid reservoir.
• Check that the level is between MIN and MAX.
• Add DOT 3 brake fluid only if the level is low.
• Reinstall the reservoir cap securely by hand.

---

✅ After Repair

• 🧪 Start your CX-5 and confirm the brake pedal stays firm.
• 🚦 Test brakes at very low speed in a safe area before normal driving.
• 👂 Listen for grinding, scraping, or clicking noises.
• 🛞 Recheck lug nut torque after the first short drive.
• 🔥 Bed in the pads with 8-10 gentle stops from about 30 mph to 5 mph, allowing cooling time between stops.
• ⚠️ Avoid hard braking for the first 100-200 miles unless needed for safety.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $200-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
