🔧 Accord - Front Brake Pad Replacement

This job replaces the front brake pads on your Accord. The front pads wear faster than the rear because they handle most of the stopping force.

Because your Accord is a hybrid, brake service must be done carefully so the brake system does not automatically pressurize while your hands are near the caliper.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Keep the key fob away from the vehicle while working so the hybrid brake system does not wake up unexpectedly.
• ⚠️ Do not open the driver door, press the brake pedal, or turn the vehicle on while a caliper is removed.
• ⚠️ Support your Accord with jack stands. Never work under or around a vehicle held only by a jack.
• ⚠️ Brake dust can irritate your lungs. Wear a dust mask and do not blow dust with compressed air.
• ⚠️ Brake fluid damages paint. Wipe spills immediately with clean water and a rag.
• ⚠️ Battery disconnect is recommended before pushing the caliper piston back in on your hybrid brake system.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 3-ton floor jack
• 3-ton jack stands
• Wheel chocks
• 19mm lug nut socket
• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench
• 3/8-inch drive ratchet
• 14mm socket
• 17mm open-end wrench
• Flat-blade screwdriver
• Brake caliper compression tool (specialty)
• Brake parts cleaning brush
• Brake cleaner spray
• Bungee cord
• Turkey baster or fluid syringe
• Mechanic gloves
• Safety glasses
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit - Qty: 1
• Brake caliper slide pin grease - Qty: 1
• Brake cleaner spray - Qty: 1
• DOT 3 brake fluid - Qty: 1 small bottle

---

📋 Before You Begin

• 🚗 Park your Accord on level ground and shift to Park.
• 🧱 Place wheel chocks behind both rear wheels.
• 🔑 Turn the vehicle fully off and move the key fob at least 15 feet away.
• 🔋 Disconnect the negative 12-volt battery cable before opening the brake system area. The 12-volt battery is in the engine compartment on this Accord.
• 🧰 A caliper is the clamp that squeezes the brake pads against the rotor. The rotor is the round metal disc behind the wheel.
• 🧴 Check the brake fluid reservoir. If it is near MAX, use a turkey baster or fluid syringe to remove a small amount so it does not overflow when the piston is pushed back.
• 🛑 Do not press the brake pedal while the caliper is off the rotor.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use the 19mm lug nut socket and 1/2-inch drive breaker bar to loosen each front lug nut about half a turn.
• Do this while the tires are still touching the ground so the wheels do not spin.
• Loosen only, do not remove yet.

Step 2: Raise and Support the Front

• Use the 3-ton floor jack at the front center jacking point to lift the front of your Accord.
• Place 3-ton jack stands under the left and right front pinch weld lift points.
• Lower the vehicle gently onto the jack stands using the 3-ton floor jack.
• Lightly shake the vehicle by hand to confirm it is stable before removing the wheels.

Step 3: Remove the Front Wheels

• Use the 19mm lug nut socket and 3/8-inch drive ratchet to remove the loosened lug nuts.
• Remove both front wheels and place them flat under the side of the vehicle as an added safety backup.

Step 4: Inspect the Brake Assembly

• Wear safety glasses, mechanic gloves, and a dust mask.
• Use brake cleaner spray to lightly clean dust from the caliper and pad area.
• Look at the rotor surface. If it has deep grooves, heavy rust, cracks, or vibration symptoms, the rotors should be resurfaced or replaced.

Step 5: Remove the Lower Caliper Bolt

• Use the 17mm open-end wrench to hold the slide pin steady.
• Use the 14mm socket and 3/8-inch drive ratchet to remove the lower caliper bolt.
• A slide pin is a smooth pin that lets the caliper move evenly as the pads wear.

Step 6: Swing the Caliper Up

• Use the flat-blade screwdriver gently between the old pad and rotor to create a little clearance.
• Swing the caliper upward by hand.
• Use a bungee cord to support the caliper from the strut spring area.
• Do not let the caliper hang by the rubber brake hose.

Step 7: Remove the Old Brake Pads and Hardware

• Pull the inner and outer pads out of the caliper bracket by hand.
• Use the flat-blade screwdriver to carefully remove the old stainless pad clips from the bracket.
• Pad clips are thin metal guides that help the pads slide smoothly.
• Use the brake parts cleaning brush and brake cleaner spray to clean the pad contact areas on the bracket.

Step 8: Compress the Caliper Piston

• Check the brake fluid reservoir again before compressing the piston.
• Use the brake caliper compression tool to slowly push the caliper piston fully back into the caliper bore.
• The piston is the round part inside the caliper that pushes the inner brake pad.
• Go slowly so brake fluid does not overflow from the reservoir.
• If fluid rises near MAX, use the turkey baster or fluid syringe to remove a small amount.

Step 9: Install New Brake Hardware

• Install the new front brake pad hardware kit clips into the caliper bracket by hand.
• Make sure each clip sits fully flat in the bracket.
• Apply a thin film of brake caliper slide pin grease to the pad ears where they touch the clips.
• Do not get grease on the pad friction material or rotor face.

Step 10: Install the New Front Brake Pads

• Slide the new front brake pad set into the bracket by hand.
• Make sure the pads move smoothly in the clips without forcing them.
• If your pad set includes wear indicators, place them in the same orientation as the original pads.
• Pads should slide, not jam.

Step 11: Reinstall the Caliper

• Swing the caliper back down over the new pads by hand.
• Use the 17mm open-end wrench to hold the slide pin steady.
• Use the 14mm socket and 3/8-inch drive ratchet to install the lower caliper bolt.
• Torque to 34 Nm (25 ft-lbs) using the 1/2-inch drive torque wrench with the proper adapter if needed.

Step 12: Repeat on the Other Side

• Repeat Steps 4 through 11 on the other front brake assembly.
• Always replace front brake pads in pairs so braking stays even left to right.

Step 13: Reinstall the Front Wheels

• Place each wheel back onto the hub by hand.
• Start all lug nuts by hand to avoid cross-threading.
• Use the 19mm lug nut socket and 3/8-inch drive ratchet to snug the lug nuts in a star pattern.

Step 14: Lower the Vehicle and Torque the Lug Nuts

• Use the 3-ton floor jack to raise the vehicle slightly off the jack stands.
• Remove the 3-ton jack stands.
• Lower your Accord until the tires touch the ground.
• Use the 19mm lug nut socket and 1/2-inch drive torque wrench to tighten the lug nuts in a star pattern.
• Torque to 108 Nm (80 ft-lbs).

Step 15: Reconnect the Battery and Seat the Pads

• Reconnect the negative 12-volt battery cable by hand, then tighten it securely with the correct hand tool if needed.
• Before turning the vehicle on, press the brake pedal slowly several times until it feels firm.
• This moves the caliper pistons back out against the new pads.
• Check the brake fluid level and top off with DOT 3 brake fluid if needed.

---

✅ After Repair

• ✅ Start your Accord and confirm the brake pedal feels firm before driving.
• ✅ Check around both front calipers for fluid leaks.
• ✅ Test brakes at very low speed in a safe area before normal driving.
• ✅ Bed in the new pads with 8-10 gentle stops from about 30 mph to 5 mph. Do not come to a complete stop and hold the pedal hard during bedding.
• ✅ Avoid hard braking for the first 100-200 miles unless needed for safety.
• ✅ Recheck lug nut torque after the first short drive: 108 Nm (80 ft-lbs).
• ✅ If brake warning lights remain on, the pedal feels soft, or the vehicle pulls while braking, stop driving and recheck the repair.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $130-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
