🔧 Front Brake Pads - Replacement

The front pads on your Corolla wear down from normal braking and should be replaced before they get too thin. This job involves removing the front caliper, swapping the pads, and compressing the caliper piston so the new pads fit correctly.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work on a flat surface and chock the rear wheels.
• Use jack stands. Never rely on the jack alone.
• Do not press the brake pedal with the caliper removed.
• Brake parts can be hot after driving. Let them cool first.
• Support the caliper with wire or a hook so the brake hose is not stretched.
• No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 21mm lug wrench or socket
• 14mm socket
• 17mm socket
• Ratchet
• Breaker bar
• Torque wrench
• C-clamp or brake piston compressor (specialty)
• Flat blade screwdriver
• Bungee cord or mechanic's hook
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Wire brush
• Brake cleaner

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake hardware kit - Qty: 1
• Brake grease - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Put the transmission in Park.
• Loosen the front wheel lug nuts before lifting the vehicle.
• Raise the front and support it securely on jack stands.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the front wheel

• Use the 21mm lug wrench or socket to loosen and remove the lug nuts.
• Remove the wheel and set it aside.

Step 2: Remove the caliper

• Use a 14mm socket and ratchet to remove the caliper slide pin bolts.
• Lift the caliper off the bracket.
• Hang the caliper with a bungee cord or mechanic's hook.
• Do not let it dangle by the brake hose.

Step 3: Remove the old pads

• Slide the old brake pads and anti-rattle clips out of the bracket.
• Use a flat blade screwdriver if the pads are stuck.
• Remove any worn hardware from the bracket.

Step 4: Inspect and clean the bracket

• Use a wire brush and brake cleaner to clean rust and dust from the bracket.
• Check the rotor surface for deep grooves or cracks.
• Inspect the slide pins for smooth movement.

Step 5: Compress the caliper piston

• Use a C-clamp or brake piston compressor (specialty) to push the piston back in slowly.
• Place one of the old pads against the piston face to spread the pressure.
• Compress the piston fully and evenly.
• Go slow to avoid damaging the seal.

Step 6: Install the new hardware and pads

• Install the new hardware from the brake hardware kit into the bracket.
• Apply a thin layer of brake grease to the contact points where the pads touch the hardware.
• Install the new pads in the bracket.

Step 7: Reinstall the caliper

• Slide the caliper back over the new pads.
• Install the caliper slide pin bolts with a 14mm socket.
• Torque to 25 Nm (18 ft-lbs).

Step 8: Reinstall the wheel

• Put the wheel back on and hand-tighten the lug nuts.
• Lower the vehicle to the ground.
• Use the 21mm lug wrench or socket to torque the lug nuts in a star pattern.
• Torque to 103 Nm (76 ft-lbs).

Step 9: Repeat on the other side

• Replace the front pads on the other side as well.
• Always replace front pads in pairs.

---

✅ After Repair

• Press the brake pedal several times until it feels firm.
• Check the brake fluid level in the reservoir.
• Test the brakes at low speed before normal driving.
• Listen for abnormal noise and recheck bolt torque after a short drive.
• Follow a gentle break-in for the first 200 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$420 (parts + labor)

DIY Cost: $60-$140 (parts only)

You Save: $160-$280 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
