🔧 Escape - Front Brake Pad Replacement

This repair replaces the front brake pads on your Escape. Brake pads wear down over time and should be replaced before the friction material gets too thin or damages the brake rotors.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack alone; always support your Escape with jack stands.
• ⚠️ Wear safety glasses and gloves. Brake dust and rust flakes can irritate your eyes and skin.
• ⚠️ Do not press the brake pedal while a caliper is removed.
• ⚠️ Support the brake caliper with a hanger or bungee cord. Do not let it hang by the rubber brake hose.
• ⚠️ The front brakes do not require electronic parking brake service mode. The EPB service mode applies to rear brake work only.
• ⚠️ Battery disconnect is not required for front brake pad replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 19mm lug nut socket
• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench
• 3/8-inch drive ratchet
• 7mm hex socket
• Flat-head screwdriver
• Needle-nose pliers
• Brake caliper piston compressor tool (specialty)
• Brake caliper hanger (specialty)
• Wire brush
• Brake cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit - Qty: 1
• Brake lubricant - Qty: 1

---

📋 Before You Begin

• 🅿️ Park your Escape on level ground and shift to Park.
• 🧱 Place wheel chocks behind both rear tires.
• 🧤 Put on safety glasses and gloves before lifting the vehicle.
• 📌 A brake caliper is the clamp-shaped part that squeezes the pads against the rotor to stop the vehicle.
• 📌 A torque wrench is a tool that tightens fasteners to the correct tightness so they are not too loose or too tight.
• 📌 A caliper piston compressor tool pushes the caliper piston back into the caliper so the new, thicker pads fit.
• 📌 Open the hood and check the brake fluid reservoir level. If it is near the MAX line, use shop towels around the reservoir because fluid may rise when the caliper pistons are compressed.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 19mm lug nut socket and 1/2-inch drive breaker bar to loosen the front wheel lug nuts about 1/2 turn.
• Do this while the tires are still touching the ground.
• Tip: Loosen only, do not remove yet.

Step 2: Lift and Support the Front of the Vehicle

• Use a floor jack at the proper front lift point to raise the front of your Escape.
• Place jack stands under the approved front support points.
• Slowly lower the vehicle onto the jack stands with the floor jack.
• Gently shake the vehicle by hand to confirm it is stable before working underneath or around the wheels.

Step 3: Remove the Front Wheels

• Use the 19mm lug nut socket and 3/8-inch drive ratchet to remove the loosened lug nuts.
• Remove both front wheels and place them flat under the side of the vehicle as an extra safety backup.

Step 4: Remove the Caliper Spring Clip

• Use a flat-head screwdriver to carefully pry the outer caliper spring clip off the front brake caliper.
• Use needle-nose pliers if needed to control the clip as it comes loose.
• Keep your face out of the spring clip path because it can pop outward.
• Tip: Take a phone photo first.

Step 5: Remove the Caliper Guide Pin Bolts

• Locate the two guide pin bolt caps on the back of the front caliper.
• Use a flat-head screwdriver to remove the rubber/plastic caps if equipped.
• Use a 7mm hex socket and 3/8-inch drive ratchet to remove the two caliper guide pin bolts.
• Set the guide pins aside on a clean shop towel.

Step 6: Remove the Caliper

• Use a flat-head screwdriver to gently wiggle the caliper loose from the pads and rotor.
• Lift the caliper off the brake rotor by hand.
• Hang the caliper from the strut spring using a brake caliper hanger.
• Do not stretch, twist, or pull on the brake hose.

Step 7: Remove the Old Brake Pads and Hardware

• Remove the outer brake pad from the caliper bracket by hand.
• Remove the inner brake pad from the caliper piston area by hand.
• Use a flat-head screwdriver to remove the old pad hardware clips from the caliper bracket.
• Use a wire brush to clean the pad contact areas on the caliper bracket.
• Spray the bracket contact areas with brake cleaner spray and wipe with shop towels.

Step 8: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use the brake caliper piston compressor tool to slowly push the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing the piston. Use shop towels to catch any overflow.
• Compress slowly to avoid pushing fluid backward too quickly through the brake system.

Step 9: Install New Brake Hardware

• Install the new front brake pad hardware kit clips into the caliper bracket by hand.
• Use a flat-head screwdriver only if needed to gently seat the clips.
• Apply a thin layer of brake lubricant to the metal pad contact points on the hardware clips.
• Do not get lubricant on the brake pad friction material or rotor face.
• Tip: A thin film is enough.

Step 10: Install the New Front Brake Pads

• Install the new inner brake pad into the caliper piston side by hand.
• Install the new outer brake pad into the caliper bracket by hand.
• Make sure both pads sit flat and slide smoothly in the hardware clips.

Step 11: Reinstall the Caliper

• Remove the caliper from the brake caliper hanger.
• Carefully place the caliper over the new pads and rotor by hand.
• Install the two guide pin bolts by hand first to avoid cross-threading.
• Use a 7mm hex socket and 3/8-inch drive ratchet to snug the guide pin bolts.
• Use a torque wrench with the 7mm hex socket to tighten the caliper guide pin bolts to Torque to 35 Nm (26 ft-lbs).
• Reinstall the guide pin caps by hand if equipped.

Step 12: Reinstall the Caliper Spring Clip

• Use needle-nose pliers and a flat-head screwdriver to reinstall the outer caliper spring clip.
• Make sure the spring clip is fully seated in the caliper holes and centered against the outer face of the caliper.
• Compare it to the photo you took earlier.

Step 13: Repeat on the Other Front Side

• Repeat Steps 4 through 12 on the other front wheel.
• Always replace front brake pads in pairs so braking stays even left to right.

Step 14: Reinstall the Front Wheels

• Place each wheel back onto the hub by hand.
• Install the lug nuts by hand first.
• Use a 19mm lug nut socket and 3/8-inch drive ratchet to snug the lug nuts in a star pattern.

Step 15: Lower the Vehicle and Torque the Lug Nuts

• Use the floor jack to raise the front of the vehicle slightly off the jack stands.
• Remove the jack stands.
• Lower the vehicle fully to the ground with the floor jack.
• Use a 1/2-inch drive torque wrench and 19mm lug nut socket to tighten the lug nuts in a star pattern to Torque to 135 Nm (100 ft-lbs).

Step 16: Pump the Brake Pedal

• Sit in the driver seat and press the brake pedal slowly several times until it feels firm.
• This moves the caliper pistons back out against the new pads.
• Do not drive until the brake pedal feels firm.

---

✅ After Repair

• ✅ Check the brake fluid reservoir and make sure the level is between MIN and MAX.
• ✅ Start your Escape and press the brake pedal again. It should feel firm and steady.
• ✅ Test the brakes at very low speed in a safe area before normal driving.
• ✅ Bed in the pads if the pad manufacturer recommends it. A common method is several moderate stops from about 30-35 mph, allowing cooling time between stops.
• ✅ Avoid hard braking for the first 100-200 miles unless needed for safety.
• ✅ Listen for scraping, grinding, or clunking. If you hear these, stop and recheck the installation.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $130-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
