🔧 Edge - Front Brake Pad Replacement

This repair replaces the front brake pads on your Edge. The front pads create friction against the brake rotors to slow the vehicle, so worn pads can cause noise, longer stopping distance, or rotor damage.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface and never rely on a jack alone.
• ⚠️ Use jack stands under the proper front support points before working near the wheels.
• ⚠️ Brake dust can be harmful. Do not blow it with compressed air; use brake cleaner.
• ⚠️ Brake fluid can damage paint. Wipe spills immediately with a clean shop towel.
• ⚠️ The brake caliper hose is flexible but not designed to hold weight. Never let the caliper hang by the hose.
• ⚠️ Battery disconnect is not required for front brake pad replacement on your Edge.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 21mm lug nut socket
• 13mm socket
• 15mm wrench
• Torque wrench rated 20-150 ft-lbs
• 3/8-inch ratchet
• Breaker bar 1/2-inch drive
• Brake caliper piston compressor (specialty)
• Flat-blade screwdriver
• Brake cleaner spray
• Wire brush
• Bungee cord
• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit - Qty: 1
• Brake lubricant high-temperature silicone/ceramic - Qty: 1
• DOT 4 brake fluid - Qty: 1 small bottle

---

📋 Before You Begin

• Park your Edge on level ground.
• Shift to Park and apply the parking brake.
• Place wheel chocks behind the rear wheels. Wheel chocks are blocks that stop the vehicle from rolling.
• Open the hood and locate the brake fluid reservoir near the driver-side rear of the engine bay.
• Check the brake fluid level. If it is at the MAX line, remove a small amount with a clean turkey baster or fluid syringe before pushing the caliper pistons back.
• The front brakes do not require electronic parking brake service mode. That procedure applies to rear brake service only.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 21mm lug nut socket and breaker bar 1/2-inch drive to loosen each front lug nut about one turn.
• Do this while the tires are still touching the ground so the wheels do not spin.
• Tip: Loosen only, do not remove yet.

Step 2: Lift and Support the Front of the Vehicle

• Use the floor jack rated 3-ton minimum at the front jacking point to raise the front of your Edge.
• Place jack stands rated 3-ton minimum under the proper front support points.
• Gently lower the vehicle onto the jack stands.
• Lightly shake the vehicle by hand to confirm it is stable before removing the wheels.

Step 3: Remove the Front Wheels

• Use the 21mm lug nut socket and 3/8-inch ratchet to remove the loosened lug nuts.
• Remove both front wheels and set them flat under the side of the vehicle as an extra safety backup.

Step 4: Inspect the Brake Assembly

• Put on safety glasses and nitrile gloves.
• Look at the brake caliper, brake hose, rotor, and pads before taking anything apart.
• The caliper is the clamp-shaped part that squeezes the brake pads against the rotor.
• Spray dusty areas lightly with brake cleaner spray and wipe with shop towels.

Step 5: Remove the Lower Caliper Guide Pin Bolt

• Use a 15mm wrench to hold the caliper guide pin if it tries to spin.
• Use a 13mm socket and 3/8-inch ratchet to remove the lower caliper guide pin bolt.
• The guide pin is the sliding pin that lets the caliper move evenly as the pads wear.

Step 6: Swing the Caliper Up

• Use a flat-blade screwdriver gently between the caliper and outer pad if the caliper is tight.
• Swing the caliper upward away from the brake pads.
• Use a bungee cord to support the caliper from the suspension spring or strut area.
• Do not stretch, twist, or pull on the brake hose.

Step 7: Remove the Old Brake Pads and Hardware

• Slide the inner and outer brake pads out of the caliper bracket by hand.
• Use a flat-blade screwdriver if the pads are stuck in the bracket.
• Remove the old metal pad clips from the bracket by hand or with the flat-blade screwdriver.
• These clips are also called abutment clips; they help the pads slide smoothly.

Step 8: Clean the Caliper Bracket Contact Points

• Use a wire brush to clean the bracket areas where the pad clips sit.
• Spray the area with brake cleaner spray and wipe with shop towels.
• Do not get grease or oily residue on the rotor friction surface.
• Tip: Clean sliding surfaces prevent brake noise.

Step 9: Install the New Pad Hardware

• Press the new front brake pad hardware kit clips into the caliper bracket by hand.
• Make sure each clip sits fully flat in the bracket.
• Apply a very thin layer of brake lubricant high-temperature silicone/ceramic to the pad ears where they touch the clips.
• The pad ears are the small tabs on each end of the brake pad backing plate.

Step 10: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use the brake caliper piston compressor (specialty) to slowly press the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing the piston. Remove excess fluid with a clean syringe if it rises near the top.
• The piston is the round part inside the caliper that pushes the inner pad.
• Compress slowly to avoid pushing fluid back too quickly through the brake system.

Step 11: Install the New Front Brake Pads

• Install the new front brake pad set into the caliper bracket by hand.
• Make sure the friction material faces the rotor.
• The friction material is the rough pad surface that contacts the rotor.
• Confirm both pads slide easily in the new hardware clips.

Step 12: Lower the Caliper and Install the Bolt

• Remove the bungee cord while supporting the caliper by hand.
• Swing the caliper down over the new pads.
• Use a 13mm socket and 3/8-inch ratchet to install the lower caliper guide pin bolt.
• Use a 15mm wrench to hold the guide pin if it spins.
• Torque to 35 Nm (26 ft-lbs).

Step 13: Repeat on the Other Front Side

• Repeat Steps 4 through 12 on the opposite front wheel.
• Use the same tools and install the remaining pads and hardware from the set.
• Always replace front brake pads in pairs.

Step 14: Reinstall the Front Wheels

• Place each wheel back onto the hub by hand.
• Thread all lug nuts by hand first to avoid cross-threading.
• Use the 21mm lug nut socket and 3/8-inch ratchet to snug the lug nuts in a star pattern.
• Do not fully torque the lug nuts while the vehicle is still in the air.

Step 15: Lower the Vehicle and Torque the Lug Nuts

• Use the floor jack rated 3-ton minimum to raise the vehicle slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower your Edge until the tires touch the ground.
• Use the torque wrench rated 20-150 ft-lbs with the 21mm lug nut socket to tighten the lug nuts in a star pattern.
• Torque to 220 Nm (162 ft-lbs).

Step 16: Pump the Brake Pedal

• Sit in the driver seat and press the brake pedal slowly 5-10 times until it feels firm.
• This moves the caliper pistons back out against the new pads.
• Do not drive until the pedal feels firm.

Step 17: Check Brake Fluid Level

• Use shop towels to clean around the brake fluid reservoir cap.
• Check that the fluid level is between MIN and MAX.
• Add DOT 4 brake fluid only if the level is low.
• Reinstall the reservoir cap securely by hand.

---

✅ After Repair

• Start your Edge and confirm the brake pedal stays firm.
• Check around both front calipers for brake fluid leaks.
• Drive slowly in a safe area and test the brakes at low speed first.
• Bed in the new pads with 8-10 moderate stops from about 30 mph down to 5 mph, allowing cooling time between stops.
• Avoid hard braking for the first 200 miles unless needed for safety.
• Recheck lug nut torque after the first short drive: Torque to 220 Nm (162 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $130-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
