🔧 1500 - Front Brake Pads & Rotors Replacement

This repair replaces the front brake pads and front brake rotors on your 1500. The pads are the friction material that clamp the rotor, and the rotor is the round metal disc the wheel bolts to.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack by itself.
• ⚠️ Use jack stands rated for the weight of your 1500 before putting any part of your body near the wheel well.
• ⚠️ Brake dust can be harmful. Do not blow it off with compressed air; use brake cleaner and shop towels.
• ⚠️ Brake fluid can damage paint. Wipe spills immediately with clean water.
• ⚠️ The front brakes are not electronically retracted. No scan tool or infotainment service mode is required for the front brakes.
• ⚠️ Battery disconnect is not required for this front brake job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 22mm socket
• 1/2-inch drive breaker bar
• 1/2-inch drive torque wrench
• Ratchet wrench
• 13mm socket
• 21mm socket
• Flat blade screwdriver
• Brake caliper piston compressor (specialty)
• Bungee cord
• Dead blow hammer
• Wire brush
• Brake cleaner spray
• Shop towels
• Brake lubricant
• Safety glasses
• Nitrile gloves
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Qty: 2
• Front brake hardware kit - Qty: 1
• Brake cleaner spray - Qty: 1-2 cans
• High-temperature brake lubricant - Qty: 1 tube

---

📋 Before You Begin

• Park your 1500 on level ground and shift to Park.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Open the hood and check the brake fluid reservoir. If it is full, remove a small amount with a clean suction tool before compressing caliper pistons.
• Do one side at a time so the other side can be used as a visual reference.
• A caliper is the clamp-shaped brake part that squeezes the pads against the rotor.
• A torque wrench tightens bolts to a precise tightness so they are not too loose or too tight.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 22mm socket and 1/2-inch drive breaker bar to loosen the front lug nuts about half a turn while the tires are still on the ground.
• Do not remove the lug nuts yet.
• Loose first, lift second.

Step 2: Raise and Support the Front

• Use a floor jack under the approved front frame lifting area to raise the front of your 1500.
• Place jack stands under the frame rails.
• Slowly lower the truck onto the jack stands and gently shake the truck to confirm it is stable.
• Keep the floor jack lightly touching the lift point as a backup.

Step 3: Remove the Front Wheels

• Use the 22mm socket and ratchet wrench to remove the loosened lug nuts.
• Remove both front wheels and set them flat under the truck frame as an extra safety backup.

Step 4: Remove the Brake Caliper

• Turn the steering wheel to give yourself more room on the side you are working on.
• Use a 13mm socket and ratchet wrench to remove the two caliper slide pin bolts.
• Slide the caliper off the rotor.
• Use a bungee cord to hang the caliper from the suspension spring or upper control arm.
• Do not let the caliper hang by the rubber brake hose.

Step 5: Remove the Old Brake Pads

• Use your hands or a flat blade screwdriver to pull the old brake pads out of the caliper bracket.
• Note the position of any wear indicator tabs before removing the pads.
• The wear indicator is the small metal tab that squeals when pads are worn low.

Step 6: Remove the Caliper Bracket

• Use a 21mm socket and 1/2-inch drive breaker bar to loosen the two caliper bracket bolts.
• Remove the caliper bracket bolts fully using the 21mm socket and ratchet wrench.
• Remove the caliper bracket and set it on a clean surface.

Step 7: Remove the Old Rotor

• Pull the rotor straight off the wheel hub by hand.
• If the rotor is stuck from rust, strike the rotor hat area with a dead blow hammer.
• Do not hit the wheel studs directly.
• The wheel hub is the center metal surface the rotor sits on.

Step 8: Clean the Hub Surface

• Use a wire brush to clean rust and scale from the wheel hub face.
• Spray the area with brake cleaner spray and wipe it dry with shop towels.
• This helps the new rotor sit flat and prevents brake pedal pulsation.
• Clean hub equals smooth braking.

Step 9: Install the New Rotor

• Spray both faces of the new rotor with brake cleaner spray.
• Wipe both faces dry with shop towels to remove protective oil.
• Slide the new rotor onto the hub.
• Thread one lug nut on by hand using the 22mm socket to hold the rotor flat while you work.

Step 10: Service the Caliper Bracket

• Use a flat blade screwdriver to remove the old stainless pad clips from the caliper bracket.
• Use a wire brush to clean the clip contact areas on the bracket.
• Install the new clips from the front brake hardware kit by hand.
• Apply a thin layer of high-temperature brake lubricant to the pad contact points on the clips.
• Do not get lubricant on the rotor or pad friction surfaces.

Step 11: Reinstall the Caliper Bracket

• Place the caliper bracket over the rotor.
• Start both bracket bolts by hand to avoid cross-threading.
• Use a 21mm socket and ratchet wrench to snug the bolts.
• Use a 1/2-inch drive torque wrench and 21mm socket to tighten the caliper bracket bolts to Torque to 275 Nm (203 ft-lbs).

Step 12: Compress the Caliper Pistons

• Place one old brake pad against the caliper pistons.
• Use a brake caliper piston compressor to slowly push the pistons fully back into the caliper.
• Watch the brake fluid reservoir under the hood while compressing the pistons.
• If fluid rises near the top, stop and remove a small amount before continuing.
• Compress slowly to protect the brake hydraulic system.

Step 13: Install the New Brake Pads

• Slide the new brake pads into the caliper bracket by hand.
• Make sure the friction material faces the rotor.
• Apply a thin film of high-temperature brake lubricant only to the pad ears where they contact the clips.
• Do not lubricate the front or back friction face of the pads.

Step 14: Reinstall the Caliper

• Remove the bungee cord and carefully lower the caliper over the new pads.
• Start both caliper slide pin bolts by hand.
• Use a 13mm socket and ratchet wrench to snug the bolts.
• Use a 1/2-inch drive torque wrench and 13mm socket to tighten the caliper slide pin bolts to Torque to 35 Nm (26 ft-lbs).

Step 15: Repeat on the Other Side

• Repeat Steps 4 through 14 on the opposite front brake.
• Use the same tools and torque values.
• Always replace front brake pads and rotors in pairs.

Step 16: Reinstall the Wheels

• Remove the temporary lug nut holding each rotor using the 22mm socket.
• Install each wheel onto the hub.
• Thread all lug nuts by hand first.
• Use the 22mm socket and ratchet wrench to snug the lug nuts in a star pattern.

Step 17: Lower and Torque the Wheels

• Use the floor jack to raise the truck slightly off the jack stands.
• Remove the jack stands.
• Lower the truck until the tires touch the ground enough to stop spinning.
• Use a 1/2-inch drive torque wrench and 22mm socket to tighten the lug nuts in a star pattern to Torque to 176 Nm (130 ft-lbs).
• Fully lower the truck and remove the floor jack.

Step 18: Pump the Brake Pedal

• Before moving the truck, press the brake pedal several times until it feels firm.
• This seats the caliper pistons against the new pads.
• The pedal may go low on the first push. That is normal after pad replacement.

---

✅ After Repair

• ✅ Check the brake fluid level and adjust it to the proper level on the reservoir.
• ✅ Start the engine and press the brake pedal again. It should feel firm.
• ✅ Check around both front calipers for brake fluid leaks.
• ✅ Test drive slowly in a safe area before driving in traffic.
• ✅ Bed in the new pads if the pad manufacturer requires it. A common method is 8-10 moderate stops from about 35 mph down to 5 mph, with cooling time between stops.
• ✅ Avoid hard braking for the first 200 miles unless needed for safety.
• ✅ Recheck lug nut torque after the first short drive using a 1/2-inch drive torque wrench and 22mm socket: Torque to 176 Nm (130 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $180-$420 (parts only)

You Save: $270-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
