🔧 Civic - Front Brake Pad & Rotor Replacement

This repair replaces the front brake pads and rotors on your Civic. The pads create friction to stop the car, and the rotors are the metal discs the pads clamp onto.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

Assumption: This guide is for the front brakes only and uses the active vehicle details provided.

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool brake system. Brake parts can burn you after driving.
• ⚠️ Support your Civic with jack stands. Never rely on a floor jack alone.
• ⚠️ Wear safety glasses and gloves. Brake dust and cleaner can irritate skin and eyes.
• ⚠️ Do not press the brake pedal while the caliper is removed.
• ⚠️ Open the brake fluid reservoir cap before compressing the caliper piston, and watch the fluid level so it does not overflow.
• ⚠️ No battery disconnect is required for this front brake job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• 19mm socket
• 14mm socket
• 17mm wrench
• Breaker bar 1/2-inch drive
• Ratchet 3/8-inch drive
• Torque wrench 1/2-inch drive
• Torque wrench 3/8-inch drive
• Phillips #3 screwdriver
• Impact driver with Phillips #3 bit
• C-clamp 6-inch
• Disc brake caliper spreader tool (specialty)
• Bungee cord
• Wire brush
• Brake cleaner spray nozzle
• Shop towels
• Drain pan
• Turkey baster or fluid syringe
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Qty: 2
• Front brake hardware kit - Qty: 1
• Brake lubricant - Qty: 1
• Brake cleaner - Qty: 2 cans
• DOT 3 brake fluid - Qty: 1 pint

---

📋 Before You Begin

• 🅿️ Park your Civic on level ground and set the parking brake.
• 🧱 Place wheel chocks behind the rear wheels.
• 🔧 Slightly loosen the front lug nuts before lifting the car.
• 🧴 Open the hood and remove the brake fluid reservoir cap. If the fluid is near the top, use a turkey baster or fluid syringe to remove a small amount.
• 📘 A caliper is the clamp-shaped brake part that holds the pads and squeezes the rotor.
• 📘 A rotor is the round metal disc behind the wheel.
• 📘 A torque wrench tightens bolts to the correct force so they are not too loose or too tight.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Wheel Lug Nuts

• Use the 19mm socket and breaker bar 1/2-inch drive to loosen each front wheel lug nut about one turn.
• Do not remove the lug nuts yet.
• Loosen before lifting the car.

Step 2: Lift and Support the Front of the Car

• Use the floor jack rated 3-ton minimum to lift the front of your Civic at the front center jacking point.
• Place jack stands rated 3-ton minimum under the front side pinch weld jack points.
• Slowly lower the car onto the jack stands.
• Gently shake the vehicle by hand to confirm it is stable before working underneath or around it.

Step 3: Remove the Front Wheels

• Use the 19mm socket and ratchet 3/8-inch drive to remove the loosened lug nuts.
• Remove both front wheels and set them flat on the ground.

Step 4: Inspect the Brake Fluid Level

• Use the turkey baster or fluid syringe if the brake fluid reservoir is full.
• Remove a small amount of fluid into a safe container so it will not overflow when the caliper piston is pushed back.
• Do not reuse removed brake fluid.

Step 5: Remove the Caliper Slide Pin Bolts

• Turn the steering wheel to give yourself better access to the caliper you are working on.
• Use the 14mm socket and ratchet 3/8-inch drive to remove the upper and lower caliper slide pin bolts.
• If the slide pin spins, hold the pin with the 17mm wrench while loosening the bolt with the 14mm socket.
• Slide pins are small smooth pins that let the caliper move evenly as the brakes apply.

Step 6: Lift the Caliper Off the Bracket

• Carefully lift the caliper away from the rotor by hand.
• Use the bungee cord to hang the caliper from the suspension spring or strut.
• Do not let the caliper hang by the rubber brake hose.
• Protect the brake hose always.

Step 7: Remove the Old Brake Pads

• Pull the old inner and outer brake pads out of the caliper bracket by hand.
• Use the shop towels to keep brake dust off your hands and work area.
• Notice the pad wear pattern. Uneven wear can point to stuck slide pins or hardware.

Step 8: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use the C-clamp 6-inch or disc brake caliper spreader tool to slowly push the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing the piston. Use the turkey baster or fluid syringe if the level gets too high.
• The piston is the round metal part inside the caliper that pushes the pad against the rotor.

Step 9: Remove the Caliper Bracket

• Use the 17mm wrench or appropriate socket setup to remove the two caliper bracket mounting bolts.
• Support the bracket by hand as the last bolt comes out.
• Set the bracket on a clean surface.

Step 10: Remove the Rotor Retaining Screws

• Use the impact driver with Phillips #3 bit to loosen the rotor retaining screws.
• If the screws are not stuck, use the Phillips #3 screwdriver to remove them.
• An impact driver is a hand tool you strike or twist to break stuck screws loose without stripping them.
• Press firmly to avoid stripping.

Step 11: Remove the Old Rotor

• Pull the rotor straight off the wheel hub by hand.
• If it is stuck from rust, tap the rotor hat area lightly with a suitable shop tool, avoiding wheel studs and brake hose.
• Use the wire brush to clean rust from the wheel hub face.
• Use brake cleaner and shop towels to wipe the hub clean.

Step 12: Clean and Install the New Rotor

• Use brake cleaner and shop towels to clean both sides of the new rotor.
• Slide the new rotor onto the hub.
• Install the rotor retaining screws using the Phillips #3 screwdriver.
• Tighten the rotor retaining screws snugly. Do not over-tighten them.

Step 13: Service the Caliper Bracket Hardware

• Use the wire brush to clean the caliper bracket where the pad hardware sits.
• Install the new front brake hardware kit by hand.
• Apply a thin layer of brake lubricant to the pad contact points on the hardware.
• Do not get lubricant on the rotor face or pad friction material.

Step 14: Reinstall the Caliper Bracket

• Position the caliper bracket over the new rotor.
• Start both bracket bolts by hand to prevent cross-threading.
• Use the 17mm wrench or appropriate socket setup to tighten the caliper bracket bolts.
• Torque to 108 Nm (80 ft-lbs).

Step 15: Install the New Brake Pads

• Slide the new inner and outer brake pads into the caliper bracket by hand.
• Make sure each pad moves smoothly in the hardware.
• Use only a thin film of brake lubricant on the pad ears where they touch the hardware.
• Do not lubricate the pad face.

Step 16: Reinstall the Caliper

• Lower the caliper over the new pads by hand.
• Start the upper and lower slide pin bolts by hand.
• Use the 14mm socket and torque wrench 3/8-inch drive to tighten the slide pin bolts.
• If the slide pin spins, hold it with the 17mm wrench.
• Torque to 34 Nm (25 ft-lbs).

Step 17: Repeat on the Other Front Side

• Repeat Steps 5 through 16 on the other front wheel.
• Replace front pads and rotors in pairs so braking stays even.

Step 18: Reinstall the Front Wheels

• Place each wheel back on the hub by hand.
• Start all lug nuts by hand.
• Use the 19mm socket and ratchet 3/8-inch drive to snug the lug nuts in a star pattern.

Step 19: Lower the Vehicle and Torque the Lug Nuts

• Use the floor jack rated 3-ton minimum to lift the car slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower the car until the tires touch the ground.
• Use the 19mm socket and torque wrench 1/2-inch drive to tighten the lug nuts in a star pattern.
• Torque to 108 Nm (80 ft-lbs).

Step 20: Pump the Brake Pedal

• Before starting or driving, press the brake pedal slowly several times until it feels firm.
• This seats the caliper pistons against the new pads.
• Use shop towels to check around each caliper for leaks.

Step 21: Set the Brake Fluid Level

• Check the brake fluid reservoir level.
• Add DOT 3 brake fluid if needed to bring the level between MIN and MAX.
• Reinstall the reservoir cap securely by hand.

---

✅ After Repair

• ✅ Start your Civic and press the brake pedal again. It should feel firm, not sink to the floor.
• ✅ Test the brakes at low speed in a safe area before normal driving.
• ✅ Listen for grinding, scraping, or clunking. Stop and recheck if anything sounds wrong.
• ✅ Recheck the lug nut torque after the first short drive: Torque to 108 Nm (80 ft-lbs).
• ✅ Bed in the new pads: make several moderate stops from about 30-40 mph, allowing the brakes to cool between stops.
• ✅ Avoid hard panic stops for the first 200 miles unless needed for safety.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 (parts + labor)

DIY Cost: $180-$350 (parts only)

You Save: $270-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
