🔧 HR-V - Front Brake Pad & Rotor Replacement

This repair replaces the front brake pads and front brake rotors on your HR-V. The pads are the friction material that stops the vehicle, and the rotors are the metal discs the pads clamp onto.

Difficulty Level: Beginner-Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack by itself.
• ⚠️ Use jack stands before putting any part of your body near the wheel well.
• ⚠️ Brake dust can be harmful. Do not blow it with compressed air.
• ⚠️ Front brakes do not require electronic parking brake service mode on your HR-V.
• ⚠️ Brake fluid can damage paint. Wipe spills immediately with water.
• ⚠️ After the repair, pump the brake pedal before driving. The pedal will feel low at first.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 19mm lug nut socket
• 12mm socket
• 17mm socket
• 3/8-inch ratchet
• 1/2-inch breaker bar
• Torque wrench rated to 120 ft-lbs
• Phillips #3 screwdriver
• Impact screwdriver (specialty)
• C-clamp or disc brake piston compressor (specialty)
• Flathead screwdriver
• Brake caliper hanger or bungee cord
• Wire brush
• Brake cleaner spray
• Shop towels
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Front brake hardware kit - Qty: 1
• Brake lubricant - Qty: 1
• Brake cleaner - Qty: 1
• DOT 3 brake fluid - Qty: 1 small bottle if topping off is needed

---

📋 Before You Begin

• Park your HR-V on level ground and place the transmission in Park.
• Apply the parking brake and place wheel chocks behind the rear wheels.
• Open the hood and locate the brake fluid reservoir. This is the small plastic tank near the driver-side rear of the engine bay.
• Do not disconnect the battery for this front brake repair.
• Brake caliper means the metal clamp that holds the brake pads and squeezes them against the rotor.
• Brake rotor means the round metal disc behind the wheel.
• Caliper bracket means the larger metal support that bolts to the steering knuckle and holds the pads in place.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 19mm lug nut socket and 1/2-inch breaker bar to loosen the front wheel lug nuts about half a turn.
• Do this while the tires are still touching the ground.
• Tip: Do not remove them yet.

Step 2: Raise and Support the Front of the HR-V

• Use a floor jack rated 2-ton minimum to lift the front of your HR-V at the front center jacking point.
• Place jack stands rated 2-ton minimum under the proper front side support points.
• Gently lower the vehicle onto the jack stands.
• Give the vehicle a light shake by hand to confirm it is stable.

Step 3: Remove the Front Wheels

• Use the 19mm lug nut socket and 3/8-inch ratchet to remove the loosened lug nuts.
• Remove both front wheels and place them flat under the side of the vehicle as an extra safety backup.

Step 4: Inspect the Brake Fluid Level

• Put on safety glasses and nitrile gloves.
• Look at the brake fluid reservoir under the hood.
• If the fluid is already at the MAX line, use shop towels around the reservoir in case fluid rises when the pistons are pushed back.
• Do not leave the reservoir open where dirt can enter.

Step 5: Remove the Front Brake Caliper

• Turn the steering wheel to give yourself more room on the side you are working on.
• Use a 12mm socket and 3/8-inch ratchet to remove the two caliper slide pin bolts.
• Lift the caliper off the bracket.
• Use a brake caliper hanger or bungee cord to hang the caliper from the suspension spring or strut.
• Do not let the caliper hang by the rubber brake hose.

Step 6: Remove the Old Brake Pads and Hardware

• Use your hands or a flathead screwdriver to slide the old brake pads out of the caliper bracket.
• Use the flathead screwdriver to remove the old stainless pad clips from the bracket.
• Remember how the clips are positioned before removing them.
• Tip: Take a photo before disassembly.

Step 7: Remove the Caliper Bracket

• Use a 17mm socket and 1/2-inch breaker bar to remove the two caliper bracket bolts.
• Remove the caliper bracket and set it on a clean surface.
• These bolts are tight from the factory, so use steady pressure instead of quick jerks.

Step 8: Remove the Front Rotor

• Use a Phillips #3 screwdriver or impact screwdriver to remove the rotor retaining screws.
• An impact screwdriver is a hand tool you strike with a hammer so the screw turns without stripping.
• Pull the rotor straight off the hub.
• If the rotor is stuck, tap around the rotor hat area with a suitable hammer while wearing safety glasses.
• Do not hit the wheel studs.

Step 9: Clean the Hub Surface

• Use a wire brush to clean rust and debris from the wheel hub face.
• Use brake cleaner spray and shop towels to wipe the hub clean.
• The new rotor must sit flat against the hub to prevent brake vibration.

Step 10: Install the New Rotor

• Clean both sides of the new rotor with brake cleaner spray and shop towels.
• Slide the new rotor onto the hub.
• Install the rotor retaining screws using a Phillips #3 screwdriver.
• Tighten the screws snug only. Do not overtighten them.

Step 11: Service the Caliper Bracket

• Use a wire brush to clean the pad contact areas on the caliper bracket.
• Install the new brake hardware clips by hand.
• Apply a thin layer of brake lubricant only where the pad ears touch the hardware clips.
• Do not get lubricant on the rotor or pad friction material.

Step 12: Reinstall the Caliper Bracket

• Position the caliper bracket over the new rotor.
• Start both bracket bolts by hand to avoid cross-threading.
• Use a 17mm socket and torque wrench rated to 120 ft-lbs to tighten the bracket bolts.
• Torque to 108 Nm (80 ft-lbs).

Step 13: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use a C-clamp or disc brake piston compressor to slowly push the piston fully back into the caliper.
• A piston is the round part inside the caliper that pushes the brake pad.
• Go slowly and check the brake fluid reservoir so it does not overflow.

Step 14: Install the New Brake Pads

• Slide the new inner and outer brake pads into the caliper bracket by hand.
• Make sure the pads move smoothly in the hardware clips.
• If they bind, remove them and clean the bracket contact points again with the wire brush.

Step 15: Reinstall the Caliper

• Lower the caliper over the new brake pads.
• Start the caliper slide pin bolts by hand.
• Use a 12mm socket and torque wrench rated to 120 ft-lbs to tighten the slide pin bolts.
• Torque to 34 Nm (25 ft-lbs).

Step 16: Repeat on the Other Front Side

• Repeat Steps 5 through 15 on the opposite front wheel.
• Always replace front pads and rotors in pairs.

Step 17: Reinstall the Wheels

• Put both front wheels back on the hubs.
• Install the lug nuts by hand first.
• Use a 19mm lug nut socket and 3/8-inch ratchet to snug the lug nuts in a star pattern.

Step 18: Lower the HR-V and Torque the Lug Nuts

• Use the floor jack rated 2-ton minimum to lift slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower your HR-V until the tires touch the ground.
• Use a 19mm lug nut socket and torque wrench rated to 120 ft-lbs to tighten lug nuts in a star pattern.
• Torque to 108 Nm (80 ft-lbs).

Step 19: Pump the Brake Pedal

• Sit in the driver seat and press the brake pedal slowly several times.
• The pedal will travel low at first, then become firm.
• Do not drive until the pedal feels firm.

Step 20: Check Brake Fluid

• Check the brake fluid reservoir level.
• If needed, add DOT 3 brake fluid until the level is between MIN and MAX.
• Use shop towels to clean any spills.

---

✅ After Repair

• ✅ Start your HR-V and press the brake pedal again. It should feel firm.
• ✅ Check behind both front wheels for brake fluid leaks.
• ✅ Test drive slowly in a safe area before normal driving.
• ✅ Perform brake bedding: make 8-10 moderate stops from about 35 mph down to 10 mph, allowing cooling time between stops.
• ✅ Avoid hard braking for the first 200 miles unless it is an emergency.
• ✅ Recheck front lug nut torque after the first short drive.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $120-$250 (parts only)

You Save: $230-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
