🔧 TITAN - Front Brake Pad & Rotor Replacement

This repair replaces the front brake pads and front brake rotors on your TITAN. The pads create stopping friction, and the rotors are the metal discs the pads clamp onto; replacing both together helps prevent vibration, noise, and uneven braking.

Difficulty Level: Beginner-Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack by itself.
• ⚠️ Use jack stands rated for the weight of your TITAN before putting hands near the brakes.
• ⚠️ Brake dust can be harmful. Do not blow it with compressed air; use brake cleaner.
• ⚠️ Front brake calipers are heavy. Support them so the rubber brake hose is not stretched.
• ⚠️ Brake fluid can damage paint. Wipe spills immediately with water.
• ⚠️ Battery disconnect is not required for this front brake job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• 21mm lug nut socket
• 1/2-inch drive breaker bar
• 1/2-inch drive ratchet
• 14mm socket
• 22mm socket
• Torque wrench 10-150 ft-lb
• Torque wrench 50-250 ft-lb
• Brake caliper piston compressor tool
• Flathead screwdriver
• Wire brush
• Rubber mallet
• Bungee cord
• Brake cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Front brake hardware kit - Qty: 1
• Brake lubricant - Qty: 1
• Brake cleaner spray - Qty: 2 cans

---

📋 Before You Begin

• 🅿️ Park your TITAN on level ground and shift into Park.
• 🧱 Place wheel chocks behind the rear wheels.
• 🛞 Loosen the front lug nuts slightly before lifting the truck.
• 🧰 A caliper is the part that squeezes the brake pads against the rotor to stop the truck.
• 🧰 A slide pin lets the caliper move smoothly as the brakes apply and release.
• 🧰 A torque wrench tightens bolts to the correct tightness so they are not loose or over-tightened.
• 🧴 Open the brake fluid reservoir cap under the hood before compressing the caliper pistons. Lay a towel around it in case fluid rises.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen Front Lug Nuts

• Use a 21mm lug nut socket and 1/2-inch drive breaker bar to loosen each front lug nut about 1/2 turn.
• Do not remove the lug nuts yet.
• Loosen while tires touch ground.

Step 2: Lift and Support the Front

• Use a floor jack rated 3-ton minimum to lift the front of your TITAN at the front crossmember or proper front lifting point.
• Place jack stands rated 3-ton minimum under the front frame support points.
• Lower the truck gently onto the jack stands.
• Keep the floor jack lightly touching as a backup support.

Step 3: Remove the Front Wheels

• Use the 21mm lug nut socket and 1/2-inch drive ratchet to remove the lug nuts.
• Remove both front wheels and set them flat under the truck as an extra safety backup.

Step 4: Inspect the Brake Assembly

• Put on safety glasses and nitrile gloves.
• Use brake cleaner spray to lightly clean dust from the caliper, pads, and rotor area.
• Look at the brake hose and ABS wire. Make sure you know where they are before moving the caliper.

Step 5: Remove the Caliper Slide Pin Bolts

• Use a 14mm socket and 1/2-inch drive ratchet to remove the two caliper slide pin bolts on the back of the caliper.
• Pull the caliper straight off the pads.
• Use a bungee cord to hang the caliper from the suspension spring or upper control arm.
• Do not let the caliper hang by the brake hose.

Step 6: Remove the Old Brake Pads

• Use a flathead screwdriver to gently pry the old brake pads out of the caliper bracket.
• Note the position of any wear indicator tab before removal.
• Remove the old stainless pad clips from the bracket by hand or with the flathead screwdriver.

Step 7: Remove the Caliper Bracket

• The caliper bracket is the heavy metal holder bolted around the rotor.
• Use a 22mm socket and 1/2-inch drive breaker bar to remove the two caliper bracket bolts.
• Set the bracket aside.
• These bolts are very tight from the factory, so use steady pressure.

Step 8: Remove the Old Rotor

• Pull the old rotor straight off the wheel hub by hand.
• If it is stuck from rust, tap the rotor hat area with a rubber mallet.
• Do not hit the wheel studs directly.
• Rotate rotor while tapping evenly.

Step 9: Clean the Hub Face

• Use a wire brush to clean rust and scale from the wheel hub face.
• Use brake cleaner spray and shop towels to wipe the hub clean.
• This step helps prevent brake pedal pulsation from rotor wobble.

Step 10: Install the New Rotor

• Spray both sides of the new rotor with brake cleaner spray and wipe it dry with shop towels.
• Slide the new rotor onto the wheel studs.
• Thread one lug nut on by hand to hold the rotor flat against the hub.

Step 11: Service the Caliper Bracket

• Use a wire brush to clean the pad contact areas on the caliper bracket.
• Install the new clips from the front brake hardware kit by hand.
• Apply a thin layer of brake lubricant to the pad contact points on the clips.
• Do not get lubricant on the rotor or pad friction surfaces.

Step 12: Reinstall the Caliper Bracket

• Place the caliper bracket over the rotor.
• Start both bracket bolts by hand to avoid cross-threading.
• Use a 22mm socket and 1/2-inch drive ratchet to snug the bolts.
• Use a torque wrench 50-250 ft-lb and 22mm socket to tighten the caliper bracket bolts to Torque to 210 Nm (155 ft-lbs).

Step 13: Compress the Caliper Pistons

• Check the brake fluid reservoir under the hood. If the fluid is near the top, remove a small amount with a clean towel or suction tool before compressing the pistons.
• Place an old brake pad against the pistons.
• Use the brake caliper piston compressor tool to slowly push the pistons fully back into the caliper.
• Go slowly so brake fluid does not overflow.

Step 14: Install the New Brake Pads

• Slide the new front brake pads into the caliper bracket by hand.
• Make sure the friction material faces the rotor.
• Apply a very thin layer of brake lubricant to the pad ears only.
• Do not lubricate the pad friction surface.

Step 15: Reinstall the Caliper

• Remove the bungee cord and slide the caliper over the new pads.
• Start both slide pin bolts by hand.
• Use a 14mm socket and 1/2-inch drive ratchet to snug the bolts.
• Use a torque wrench 10-150 ft-lb and 14mm socket to tighten the slide pin bolts to Torque to 43 Nm (32 ft-lbs).

Step 16: Repeat on the Other Side

• Repeat Steps 4 through 15 on the opposite front wheel.
• Always replace front brake pads and rotors in pairs.

Step 17: Reinstall the Wheels

• Remove the temporary lug nut holding each rotor.
• Install each wheel onto the wheel studs.
• Thread all lug nuts by hand first.
• Use the 21mm lug nut socket and 1/2-inch drive ratchet to snug the lug nuts in a star pattern.

Step 18: Lower and Torque the Wheels

• Use the floor jack rated 3-ton minimum to lift the truck slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower the truck until the tires touch the ground.
• Use the torque wrench 50-250 ft-lb and 21mm lug nut socket to tighten the lug nuts in a star pattern to Torque to 133 Nm (98 ft-lbs).

Step 19: Pump the Brake Pedal

• Before moving the truck, press the brake pedal slowly 5-10 times until it feels firm.
• This moves the caliper pistons back against the new pads.
• Check the brake fluid reservoir and install the cap securely.

---

✅ After Repair

• ✅ Start your TITAN and press the brake pedal. It should feel firm, not sink to the floor.
• ✅ Check around both front calipers for brake fluid leaks.
• ✅ Test drive slowly in a safe area before normal driving.
• ✅ Bed in the new brakes: make 8-10 moderate stops from about 35-40 mph down to 10 mph, allowing short cooling time between stops.
• ✅ Avoid hard braking for the first 200 miles unless needed for safety.
• ✅ Recheck lug nut torque after the first short drive: Torque to 133 Nm (98 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $450-$750 USD equivalent (parts + labor)

DIY Cost: $180-$350 USD equivalent (parts only)

You Save: $270-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
