🔧 Forester - Front Brake Pad & Rotor Replacement

This repair replaces the front brake pads and front brake rotors on your Forester. Worn pads or warped rotors can cause squealing, grinding, vibration while braking, or longer stopping distance.

Difficulty Level: Beginner | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack alone.
• ⚠️ Use jack stands before putting any part of your body near the brakes.
• ⚠️ Brake dust can be harmful. Do not blow it with compressed air.
• ⚠️ Brake fluid can damage paint. Wipe spills immediately with water.
• ⚠️ Front brake calipers are heavy. Do not let them hang by the brake hose.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• 19mm lug nut socket
• 1/2-inch drive breaker bar
• 1/2-inch drive ratchet
• 14mm socket
• 17mm socket
• Torque wrench rated 20-150 ft-lbs
• C-clamp 6-inch
• Brake caliper piston compression tool (specialty)
• Flat-blade screwdriver medium
• Wire brush
• Bungee cord 18-inch
• Brake cleaner aerosol
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Qty: 2
• Front brake hardware kit - Qty: 1
• Brake caliper slide pin grease - Qty: 1
• Brake pad anti-squeal lubricant - Qty: 1

---

📋 Before You Begin

• Park your Forester on level ground and shift the manual transmission into 1st gear.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Loosen the front lug nuts slightly before lifting the vehicle.
• Open the hood and check the brake fluid reservoir. If it is full, remove a small amount with a clean fluid-safe syringe before compressing the caliper pistons.
• A caliper piston is the round part inside the brake caliper that pushes the pads against the rotor.
• A rotor is the round metal disc that the brake pads clamp onto to stop the vehicle.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 19mm lug nut socket and 1/2-inch drive breaker bar to loosen each front lug nut about 1/2 turn.
• Do not remove the lug nuts yet.
• Loosen wheels before lifting.

Step 2: Lift and Support the Front

• Use a floor jack rated 2-ton minimum to lift the front of your Forester at the front center jacking point.
• Place jack stands rated 2-ton minimum under the proper front support points.
• Lower the vehicle gently onto the jack stands.
• Use wheel chocks at the rear wheels to prevent rolling.
• Give the vehicle a gentle shake to confirm it is stable.

Step 3: Remove the Front Wheels

• Use the 19mm lug nut socket and 1/2-inch drive ratchet to remove the front lug nuts.
• Remove both front wheels and set them flat under the vehicle as an extra safety backup.

Step 4: Remove the Caliper Slide Bolts

• Work on one side at a time so the other side can be used as a reference.
• Use a 14mm socket and 1/2-inch drive ratchet to remove the upper and lower front caliper slide bolts.
• A slide bolt holds the moving part of the caliper to the bracket and lets it move smoothly as the pads wear.
• If the slide pin spins, hold the pin steady with a suitable wrench while removing the bolt with the 14mm socket.

Step 5: Lift Off the Brake Caliper

• Use a flat-blade screwdriver medium to gently pry the caliper outward if it is tight.
• Lift the caliper off the rotor.
• Use a bungee cord 18-inch to hang the caliper from the strut spring.
• Do not stretch, twist, or hang the caliper by the rubber brake hose.

Step 6: Remove the Old Brake Pads

• Pull the old brake pads out of the caliper bracket by hand.
• Use a flat-blade screwdriver medium if a pad is stuck.
• Note the position of any wear indicator clips before removing them.
• A wear indicator is a small metal tab that makes noise when the pad is nearly worn out.

Step 7: Remove the Caliper Bracket

• Use a 17mm socket and 1/2-inch drive breaker bar to loosen the two caliper bracket bolts.
• Remove both bracket bolts with the 17mm socket and 1/2-inch drive ratchet.
• Remove the caliper bracket from the knuckle.

Step 8: Remove the Old Rotor

• Pull the rotor straight off the wheel hub by hand.
• If the rotor is stuck, tap around the rotor hat with a hammer if available, or carefully work it loose by hand.
• If your rotor has threaded removal holes, install matching bolts evenly and slowly to push the rotor free.
• Do not hit the wheel studs.

Step 9: Clean the Hub Face

• Use a wire brush to clean rust from the wheel hub face.
• Use brake cleaner aerosol and shop towels to wipe the hub clean.
• The hub face must be flat and clean so the new rotor does not wobble.
• Rust here can cause brake vibration.

Step 10: Install the New Rotor

• Use brake cleaner aerosol and shop towels to clean both friction surfaces of the new rotor.
• Slide the new rotor onto the wheel studs.
• Thread one lug nut on by hand to hold the rotor flat while you work.

Step 11: Service the Caliper Bracket

• Use a flat-blade screwdriver medium to remove the old pad hardware clips from the caliper bracket.
• Use a wire brush to clean the bracket where the clips sit.
• Install the new clips from the front brake hardware kit by hand.
• Apply a thin film of brake pad anti-squeal lubricant only where the pad ears contact the clips.
• Do not get lubricant on the rotor or pad friction material.

Step 12: Reinstall the Caliper Bracket

• Place the caliper bracket back over the rotor.
• Start both bracket bolts by hand to avoid cross-threading.
• Use the 17mm socket and torque wrench rated 20-150 ft-lbs to tighten the caliper bracket bolts.
• Torque to 80 Nm (59 ft-lbs)

Step 13: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use a C-clamp 6-inch or brake caliper piston compression tool to slowly push the piston fully back into the caliper.
• Go slowly and check the brake fluid reservoir often so it does not overflow.
• If fluid gets too high, remove a small amount using a clean fluid-safe syringe.

Step 14: Lubricate the Slide Pins

• Pull each slide pin out of the caliper bracket by hand.
• Wipe the pins clean with shop towels.
• Apply a light coat of brake caliper slide pin grease to each pin.
• Reinstall the pins by hand and make sure they move smoothly.
• Do not use regular grease. Brake grease is made to handle heat and rubber parts.

Step 15: Install the New Brake Pads

• Install the new inner and outer brake pads into the caliper bracket by hand.
• Make sure the pads slide freely in the new hardware clips.
• If the pad has a wear indicator, match its position to the old pad layout.
• Keep the pad friction surfaces clean.

Step 16: Reinstall the Caliper

• Remove the bungee cord 18-inch and lower the caliper over the new pads.
• Start the upper and lower slide bolts by hand.
• Use the 14mm socket and torque wrench rated 20-150 ft-lbs to tighten the slide bolts.
• Torque to 27 Nm (20 ft-lbs)

Step 17: Repeat on the Other Front Side

• Repeat Steps 4 through 16 on the opposite front brake.
• Use the same tools and keep each side clean.
• Always replace front pads and rotors in pairs.

Step 18: Reinstall the Wheels

• Remove the temporary lug nut holding each rotor.
• Install the wheels onto the hubs.
• Thread all lug nuts by hand first.
• Use the 19mm lug nut socket and 1/2-inch drive ratchet to snug the lug nuts in a star pattern.

Step 19: Lower the Vehicle and Torque Lug Nuts

• Use the floor jack rated 2-ton minimum to lift slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower your Forester fully to the ground.
• Use the 19mm lug nut socket and torque wrench rated 20-150 ft-lbs to tighten lug nuts in a star pattern.
• Torque to 120 Nm (89 ft-lbs)

Step 20: Pump the Brake Pedal

• Before driving, press the brake pedal slowly several times until it feels firm.
• This moves the caliper pistons back into position against the new pads.
• Check the brake fluid level and top off only if needed with the correct brake fluid listed on the reservoir cap.
• Do not drive until the pedal feels firm.

---

✅ After Repair

• ✅ Start your Forester and press the brake pedal again. It should feel firm, not soft or sinking.
• ✅ Check around both front calipers for leaks.
• ✅ Test drive slowly in a safe area before normal driving.
• ✅ Bed in the new brakes: make 8-10 gentle stops from about 30 mph to 5 mph, allowing short cooling time between stops.
• ✅ Avoid hard braking for the first 200 miles unless needed for safety.
• ✅ Recheck lug nut torque after 25-50 miles using the 19mm lug nut socket and torque wrench rated 20-150 ft-lbs.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $120-$280 (parts only)

You Save: $230-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
