🔧 Frontier - Front Brake Pad & Rotor Replacement

This repair replaces the front brake pads and rotors on your Frontier. Worn pads or warped rotors can cause squeaking, grinding, vibration while braking, or longer stopping distance.

Difficulty Level: Beginner to Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support your Frontier with jack stands. Never rely on a jack alone.
• ⚠️ Wear safety glasses and gloves. Brake dust and rust particles can irritate your eyes and skin.
• ⚠️ Do not press the brake pedal while the caliper is removed.
• ⚠️ Brake parts get very hot after driving. Let everything cool before starting.
• ⚠️ Open the brake fluid reservoir cap before compressing the caliper piston, but do not let dirt enter the reservoir.
• ⚠️ Battery disconnect is not required for this front brake service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 21mm lug nut socket
• 19mm socket
• 14mm socket
• 3/8-inch ratchet
• 1/2-inch breaker bar
• 1/2-inch torque wrench
• 3/8-inch torque wrench
• Brake caliper piston compressor tool (specialty)
• Flat-blade screwdriver
• Wire brush
• Brake parts cleaner spray
• Shop rags
• Bungee cord
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Qty: 2
• Front brake hardware kit - Qty: 1
• Disc brake caliper slide pin grease - Qty: 1
• Brake fluid DOT 3 - Qty: 1 pint

---

📋 Before You Begin

• 🅿️ Park your Frontier on level ground and shift into Park.
• 🧱 Place wheel chocks behind the rear wheels. Wheel chocks are wedge blocks that stop the truck from rolling.
• 🛞 Slightly loosen the front lug nuts with a 21mm lug nut socket before lifting the truck.
• 🧴 Open the hood and locate the brake fluid reservoir. Clean around the cap with a shop rag, then loosen the cap.
• 📏 If the brake fluid level is already at the MAX line, remove a small amount with a clean suction tool before compressing the caliper piston to prevent overflow.
• 🔌 No infotainment menu, scan tool, EPB retraction, ADAS calibration, or battery registration is needed for this front brake job.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 21mm lug nut socket and 1/2-inch breaker bar to loosen each front lug nut about 1/2 turn.
• Do not remove the lug nuts yet. The tire should stay on the ground while breaking them loose.
• Loosen first, lift second.

Step 2: Lift and Support the Front of the Truck

• Use a floor jack rated 3-ton minimum under the front center crossmember to raise the front of your Frontier.
• Place jack stands rated 3-ton minimum under the left and right front frame support points.
• Slowly lower the truck onto the jack stands and gently shake the truck to confirm it is stable.
• Keep the floor jack lightly touching the lift point as a backup.

Step 3: Remove the Front Wheels

• Use the 21mm lug nut socket and 3/8-inch ratchet to remove the loosened lug nuts.
• Remove both front wheels and set them flat on the ground.
• Slide one wheel under the frame as an extra safety backup.

Step 4: Inspect the Brake Assembly

• Put on safety glasses and nitrile gloves.
• Look at the brake caliper, brake hose, rotor, and pad thickness before removal.
• The caliper is the clamp-shaped part that squeezes the pads against the rotor.
• If the brake hose is cracked, leaking, or twisted, do not continue until that is repaired.

Step 5: Remove the Caliper Slide Pin Bolts

• Use a 14mm socket and 3/8-inch ratchet to remove the two caliper slide pin bolts from the back of the caliper.
• Slide pins let the caliper move evenly as the pads wear.
• Pull the caliper away from the rotor carefully.
• Do not let the caliper hang by the brake hose.

Step 6: Support the Caliper

• Use a bungee cord to hang the caliper from the front coil spring or upper suspension area.
• Make sure the rubber brake hose is not stretched, kinked, or twisted.
• Protect the hose from stress.

Step 7: Remove the Old Brake Pads

• Use a flat-blade screwdriver to gently pry the old brake pads out of the caliper bracket.
• Note the position of any wear indicator clips before removing the pads.
• The wear indicator is a small metal tab that squeals when pads are worn.

Step 8: Remove the Caliper Bracket

• Use a 19mm socket and 1/2-inch breaker bar to remove the two caliper bracket bolts.
• Hold the bracket firmly while removing the last bolt.
• Set the bracket on a clean surface.

Step 9: Remove the Old Rotor

• Pull the rotor straight off the wheel hub by hand.
• If it is stuck from rust, lightly tap around the rotor hat with the handle of a 1/2-inch breaker bar.
• Do not hit the wheel studs.
• The rotor hat is the raised center section of the brake rotor.

Step 10: Clean the Hub Face

• Use a wire brush to clean rust and scale from the wheel hub face.
• Spray the area with brake parts cleaner spray and wipe it with shop rags.
• A clean hub helps the new rotor sit flat and prevents brake vibration.
• Clean metal makes smooth brakes.

Step 11: Prepare and Install the New Rotor

• Spray both sides of the new rotor with brake parts cleaner spray.
• Wipe the rotor dry with shop rags.
• Slide the new rotor onto the hub.
• Thread one lug nut on by hand using the 21mm lug nut socket to hold the rotor in place temporarily.

Step 12: Service the Caliper Bracket

• Use a flat-blade screwdriver to remove the old stainless brake hardware clips from the caliper bracket.
• Use a wire brush to clean the areas where the clips sit.
• Install the new clips from the front brake hardware kit by hand.
• Apply a thin layer of disc brake caliper slide pin grease to the pad contact points on the clips.
• Do not get grease on the rotor or pad friction surfaces.

Step 13: Reinstall the Caliper Bracket

• Position the caliper bracket over the rotor.
• Start both bracket bolts by hand to avoid cross-threading.
• Use a 19mm socket and 1/2-inch torque wrench to tighten the caliper bracket bolts.
• Torque to 152 Nm (112 ft-lbs)

Step 14: Compress the Caliper Piston

• Place one old brake pad against the caliper piston.
• Use a brake caliper piston compressor tool to slowly push the piston fully back into the caliper.
• The piston is the round metal part that pushes the inner brake pad.
• Watch the brake fluid reservoir while compressing. Use shop rags to catch any overflow.
• If brake fluid spills, clean it immediately because it can damage paint.

Step 15: Install the New Brake Pads

• Install the new front brake pads into the caliper bracket by hand.
• Make sure the pad friction material faces the rotor.
• If the pad set has a wear indicator, install it in the same position as the original pad.
• The pads should slide smoothly in the new hardware clips.

Step 16: Reinstall the Caliper

• Remove the bungee cord and carefully place the caliper over the new pads.
• Start both caliper slide pin bolts by hand.
• Use a 14mm socket and 3/8-inch torque wrench to tighten the slide pin bolts.
• Torque to 32 Nm (24 ft-lbs)

Step 17: Repeat on the Other Side

• Repeat Steps 5 through 16 on the other front brake assembly.
• Always replace front brake pads and rotors in pairs.
• This keeps braking even from side to side.

Step 18: Reinstall the Wheels

• Remove the temporary lug nut holding each rotor using the 21mm lug nut socket.
• Install both front wheels.
• Thread all lug nuts by hand first.
• Snug the lug nuts in a star pattern using the 21mm lug nut socket and 3/8-inch ratchet.

Step 19: Lower the Truck and Torque the Lug Nuts

• Use the floor jack rated 3-ton minimum to raise the truck slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower the truck until the tires touch the ground fully.
• Use a 21mm lug nut socket and 1/2-inch torque wrench to tighten the lug nuts in a star pattern.
• Torque to 133 Nm (98 ft-lbs)

Step 20: Pump the Brake Pedal

• Before driving, press the brake pedal slowly 5-10 times until it feels firm.
• This moves the caliper pistons back into normal position against the new pads.
• If the pedal stays soft or sinks, do not drive the truck.

Step 21: Check Brake Fluid Level

• Use safety glasses and check the brake fluid reservoir level.
• Add DOT 3 brake fluid if needed to bring the level between MIN and MAX.
• Reinstall the brake fluid reservoir cap tightly by hand.
• Wipe any spilled fluid with shop rags.

---

✅ After Repair

• ✅ Start your Frontier and press the brake pedal again. It should feel firm.
• ✅ Check around both front calipers for leaks before driving.
• ✅ Perform a slow test in a safe area. Confirm the truck stops straight without grinding or pulling.
• ✅ Bed in the new pads and rotors: make 8-10 moderate stops from about 30 mph to 5 mph, allowing a short cool-down between stops.
• ✅ Avoid hard emergency-style braking for the first 200 miles unless necessary.
• ✅ Recheck lug nut torque after 25-50 miles using a 21mm lug nut socket and 1/2-inch torque wrench.

---

💰 DIY vs Shop Cost

Shop Cost: $420-$750 (parts + labor)

DIY Cost: $160-$320 (parts only)

You Save: $260-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
