🔧 Edge - Automatic Transmission Fluid Change

Changing the automatic transmission fluid on your Edge helps protect the transmission from wear, heat, and shift quality problems. This service drains the old fluid from the transmission pan area and refills it with the correct Ford-spec fluid.

Assumption: This covers the factory automatic transmission drain-and-fill service.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Transmission fluid can be very hot. Let the drivetrain cool before removing the drain plug.
• 🧤 Wear gloves and safety glasses to avoid skin and eye contact with used fluid.
• 🚗 Keep your Edge level during draining and filling. Fluid level is sensitive to vehicle angle.
• 🔥 Keep fluid away from exhaust parts. Spilled fluid can smoke or burn.
• 🔋 Battery disconnect is not required for this service.
• ⚠️ Do not flush the transmission with universal chemicals. Use only the correct Ford-approved fluid.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 8mm socket
• 10mm socket
• 11mm socket
• 3/8-inch ratchet
• 3/8-inch extension set
• Torque wrench 5-50 Nm
• Fluid transfer pump (specialty)
• Long-neck transmission funnel
• Drain pan 10-quart minimum
• Measuring jug 5-quart minimum
• Infrared thermometer
• Trim clip removal tool
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid Mercon LV - Qty: 5 quarts
• Transmission drain plug seal - Qty: 1

---

📋 Before You Begin

• 🅿️ Park your Edge on level ground.
• 🛞 Place wheel chocks at the wheels that stay on the ground.
• 🌡️ For the most accurate fill, fluid should be checked warm, not cold. An infrared thermometer reads surface temperature without touching it.
• 📏 Measure the amount drained so you can refill the same amount first.
• ⚠️ Do not open the transmission if dirt, sand, or water can enter the fill area.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Warm the Fluid Slightly

• Start your Edge and let it idle for a few minutes.
• Drive gently for 5-10 minutes if the vehicle is safe to drive.
• Park on level ground and move the shifter slowly through each gear, then back to Park.
• Turn the engine off before draining.
• Warm fluid drains faster.

Step 2: Raise and Level the Vehicle

• Use a floor jack rated 3-ton minimum to lift your Edge at the approved lift points.
• Place jack stands rated 3-ton minimum under the approved support points.
• Make sure the vehicle sits level front-to-back and side-to-side.
• Use wheel chocks for extra safety.
• Never work under a jack alone.

Step 3: Remove the Lower Shield

• Use an 8mm socket or 10mm socket to remove the lower splash shield fasteners.
• Use a trim clip removal tool to remove any plastic push clips.
• Set the shield aside where it will not get stepped on.

Step 4: Locate the Transmission Drain Plug

• Look at the lower transmission case area on the driver side of the powertrain.
• Place a drain pan 10-quart minimum under the drain plug.
• Use shop towels to clean around the plug before removal.

Step 5: Drain the Old Transmission Fluid

• Use an 11mm socket and 3/8-inch ratchet to loosen the transmission drain plug.
• Remove the plug by hand once loose and let the fluid drain fully.
• Expect around 4-5 quarts during a normal drain-and-fill, not the full transmission capacity.
• Inspect the fluid. Dark fluid is common; burnt smell or metal flakes may indicate internal wear.
• Keep the drain pan centered.

Step 6: Measure the Drained Fluid

• Pour the used fluid from the drain pan 10-quart minimum into a measuring jug 5-quart minimum.
• Write down the exact amount removed.
• This gives you the starting refill amount.

Step 7: Reinstall the Drain Plug

• Install a new transmission drain plug seal on the plug.
• Thread the plug in by hand first to avoid cross-threading.
• Use an 11mm socket and torque wrench 5-50 Nm to tighten the drain plug.
• Torque to 12 Nm (106 in-lbs).

Step 8: Access the Transmission Fill Point

• Open the hood and locate the transmission fluid fill cap/dipstick area near the transmission side of the engine bay.
• Wipe the area clean with shop towels before opening it.
• If access is tight, use a 3/8-inch extension set to move nearby retainers only if needed.

Step 9: Refill the Transmission

• Place a long-neck transmission funnel into the fill tube.
• Add automatic transmission fluid Mercon LV equal to the amount drained.
• If access requires pumping fluid instead of pouring, use a fluid transfer pump.
• Add fluid slowly to prevent overflow.
• Use only Mercon LV fluid.

Step 10: Warm and Circulate the Fluid

• Start the engine and keep your foot on the brake.
• Move the shifter slowly through Reverse, Neutral, Drive, and Sport/Low if equipped, pausing 3 seconds in each position.
• Return the shifter to Park and leave the engine idling.
• Use an infrared thermometer to monitor the transmission pan/case temperature.

Step 11: Check and Adjust Fluid Level

• With the engine idling and your Edge level, check the transmission fluid level at the transmission dipstick/fill indicator if equipped.
• Use shop towels to wipe the indicator, reinsert it fully, then check again.
• Add automatic transmission fluid Mercon LV in small amounts using the long-neck transmission funnel if low.
• Do not overfill. Too much fluid can cause foaming and shifting problems.
• If your Edge uses a level plug style check, use the fluid transfer pump and check with fluid warm until fluid just dribbles from the level port.

Step 12: Reinstall the Lower Shield

• Turn the engine off after the level is correct.
• Use shop towels to clean any spilled fluid.
• Position the lower splash shield back in place.
• Use a trim clip removal tool to reinstall plastic push clips.
• Use an 8mm socket or 10mm socket to reinstall the shield fasteners snugly.

Step 13: Lower the Vehicle

• Use the floor jack rated 3-ton minimum to lift your Edge slightly off the jack stands.
• Remove the jack stands rated 3-ton minimum.
• Lower the vehicle slowly to the ground.

---

✅ After Repair

• ✅ Start your Edge and confirm the transmission engages Reverse and Drive smoothly.
• 🔍 Check underneath for leaks around the drain plug.
• 🚗 Take a gentle 10-minute test drive.
• 🌡️ Recheck the fluid level warm and level after the test drive.
• ♻️ Take the used transmission fluid to a recycling center or auto parts store that accepts waste oil.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $45-$95 (parts only)

You Save: $135-$255 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-1.5 hours.

---
