🔧 Insight - Transmission Fluid Drain and Refill

This one is manageable for a careful beginner. Your Insight needs a simple drain and refill, not a pressurized flush. Despite the “e-CVT” name, it requires Honda ATF DW-1, not Honda HCF-2 CVT fluid or universal CVT fluid. Honda specifies approximately 2.3 US quarts (2.2 liters) per fluid change. carmanualsonline.info

Difficulty Level: Intermediate | Estimated Time: 1-1.5 hours

Assumption: These instructions cover a routine drain and refill with no transmission leaks or warning messages.

---

⚠️ Safety & Precautions

• ⚠️ Keep the Insight completely level while draining and refilling. An uneven vehicle can produce an incorrect fluid level.
• ⚠️ Support the car with four properly rated jack stands. Never work underneath a vehicle supported only by a jack.
• ⚠️ Turn the power system completely off and keep the key away from the car.
• ⚠️ Do not touch orange hybrid-voltage cables or connectors. Hybrid-system disconnection isn’t required for this service.
• ⚠️ Wear gloves and safety glasses. Warm transmission fluid can burn skin.
• ⚠️ Remove the fill plug before draining. That proves you can refill the transmission before it’s empty.
• ⚠️ Do not add transmission additives or mix ATF DW-1 with HCF-2 or universal CVT fluid.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 2 tons minimum
• Four jack stands rated 2 tons minimum
• Wheel chocks
• 3/8-inch drive ratchet
• 10mm socket
• Phillips screwdriver No. 2
• Flat-blade screwdriver
• Torque wrench rated 10-80 ft-lbs
• Drain pan rated 8 quarts minimum
• Long-neck funnel with flexible hose
• 1-quart graduated measuring container
• Plastic trim-clip removal tool
• Nitrile gloves
• Safety glasses
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Honda ATF DW-1 automatic transmission fluid - Qty: 3 US quarts
• Transmission drain-plug crush washer - Qty: 1
• Underbody splash-shield clips - Qty: As needed

Important: The universal and conventional CVT fluids currently displayed aren’t the right specification for your Insight. Use fluid clearly labeled Honda ATF DW-1. Wrong fluid is expensive shop-floor confetti.

---

📋 Before You Begin

• 📋 Drive the Insight for approximately 10 minutes so the fluid becomes warm, not scorching hot.
• 📋 Park on firm, level ground, select Park, engage the parking brake and turn the power system off.
• 📋 Place wheel chocks securely around the wheels remaining on the ground.
• 📋 Raise and support all four corners at equal height if additional working room is required.
• 📋 Confirm the car is stable by giving it a careful push before getting underneath.
• 📋 No infotainment service mode, scan tool command, battery registration or hybrid-system isolation is required.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and level the vehicle

• Use the floor jack rated 2 tons minimum at the approved center lifting points.
• Position the four jack stands rated 2 tons minimum beneath the reinforced side support points.
• Verify the car is level from front to rear and side to side.
• Never trust a hydraulic jack alone.

Step 2: Remove the lower splash shield

• Put on the safety glasses and nitrile gloves.
• Use the Phillips screwdriver No. 2, flat-blade screwdriver, 10mm socket and plastic trim-clip removal tool to remove the applicable screws, bolts and push clips.
• Support the panel while removing its final fasteners, then lower it carefully.
• Arrange the fasteners by location so they return to the correct holes.

Step 3: Locate and loosen the transmission fill plug

• Locate the transmission fill opening above the transmission case. Depending on access, it may be reached from above after moving the intake duct or through the service area underneath.
• Use the 10mm socket to loosen the intake duct fasteners if additional access is required.
• Remove the fill plug by hand or with the appropriate installed tool arrangement.
• Clean around the opening with shop towels before removing it completely.
• Do not drain the old fluid until the fill opening has been successfully opened.

Step 4: Drain the old transmission fluid

• Place the drain pan rated 8 quarts minimum directly beneath the transmission drain plug.
• Insert the square drive of the 3/8-inch drive ratchet directly into the drain plug.
• Turn counterclockwise while pressing the ratchet firmly into the plug.
• Remove the plug by hand and allow the fluid to drain completely.
• Expect approximately 2.3 US quarts (2.2 liters). carmanualsonline.info

Step 5: Inspect and measure the old fluid

• Use the 1-quart graduated measuring container to measure the amount removed.
• Clean the magnetic drain plug with shop towels.
• A thin coating of gray metallic paste can be normal. Large chips, flakes or a strong burnt odor call for professional inspection before driving.
• Compare the drained amount with the specified refill quantity. A major shortage may indicate a leak.

Step 6: Install the drain plug

• Remove the old crush washer and install a new transmission drain-plug crush washer.
• Thread the drain plug in by hand until fully seated. This prevents damaging the aluminum transmission case.
• Use the torque wrench rated 10-80 ft-lbs with the 3/8-inch drive connection.
• Torque the drain plug to 49 Nm (36 ft-lbs).
• Do not add extra force after the torque wrench clicks.

Step 7: Add new ATF DW-1

• Insert the long-neck funnel with flexible hose securely into the fill opening.
• Slowly add 2.3 US quarts (2.2 liters) of Honda ATF DW-1. carmanualsonline.info)
• Pause periodically so the fluid can flow into the case without backing up through the funnel.
• If the measured amount drained was significantly below 2.3 quarts, inspect for leakage rather than blindly overfilling.
• Slow pouring prevents an impressive red waterfall.

Step 8: Reinstall the fill plug and intake parts

• Remove the long-neck funnel with flexible hose and wipe away spilled fluid with shop towels.
• Inspect the fill plug seal and replace it if cut, hardened or swollen.
• Press the fill plug fully into place by hand.
• If the intake duct was moved, reinstall it using the 10mm socket.
• Confirm every intake hose, clamp and electrical connector is properly secured.

Step 9: Check for leaks

• Leave the lower splash shield removed temporarily.
• Make sure all tools are clear, then start the Insight and place it in Ready mode.
• Hold the brake pedal and select Reverse, Neutral and Drive for several seconds each, then return to Park.
• Turn the power system off and inspect the drain plug and fill area with the safety glasses and a flashlight if available.
• If fluid appears, shut the car down and correct the leak before reinstalling the shield.

Step 10: Reinstall the splash shield and lower the vehicle

• Use the Phillips screwdriver No. 2, flat-blade screwdriver, 10mm socket and plastic trim-clip removal tool to reinstall every shield fastener.
• Replace any broken underbody splash-shield clips.
• Use the floor jack rated 2 tons minimum to remove the stands one axle at a time.
• Lower the Insight carefully and remove the wheel chocks.

---

✅ After Repair

• ✅ Test-drive the Insight gently for 10-15 minutes.
• ✅ Check for warning lights, unusual noise or vibration.
• ✅ Park on clean, level ground and inspect underneath for fresh fluid.
• ✅ Recheck the drain-plug area after the next two drives.
• ✅ Do not use a power-flush machine. Routine service is a drain and refill.
• ✅ Transmission service appears as Maintenance Minder sub-code 3. Honda calls for more frequent service under sustained low-speed mountainous operation, specifically every 47,500 miles or three years under those conditions. owners.honda.com

---

💰 DIY vs Shop Cost

Shop Cost: $150-$275 equivalent (parts + labor)

DIY Cost: $45-$90 equivalent (parts only)

You Save: $75-$200 by doing it yourself!

Local Sonīpat labor and genuine-fluid prices vary. This repair takes a shop approximately 0.5-1 hour.

---
