🔧 Focus - Manual Transmission Fluid Change

This service drains and refills the manual transmission fluid in your Focus. Fresh fluid helps protect the gears, bearings, and synchronizers, which are the parts that help the transmission shift smoothly.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Support your Focus securely on jack stands before going underneath it. Never rely on a jack alone.
• ⚠️ Transmission fluid may be hot after driving. Let the vehicle cool before removing plugs.
• ⚠️ Keep the vehicle level during filling. Fluid level is checked at the fill opening.
• ⚠️ Always remove the fill plug before the drain plug. This prevents draining the transmission and then discovering it cannot be refilled.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (8-quart minimum)
• 8mm hex bit socket
• 3/8-inch drive ratchet
• 3/8-inch drive torque wrench
• Fluid transfer pump
• Brake cleaner spray
• Clean shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Manual transmission fluid meeting Ford specification WSD-M2C200-C - Qty: approximately 1.7 quarts
• Transmission fill plug seal - Qty: 1
• Transmission drain plug seal - Qty: 1

---

📋 Before You Begin

• 🚗 Park your Focus on a level surface.
• 🧱 Place wheel chocks behind the rear wheels to stop the car from rolling.
• 🅿️ Set the parking brake and shift the transmission into neutral.
• 📌 A fluid transfer pump is a hand pump that pushes new fluid into the transmission because the fill hole is on the side.
• 📌 A torque wrench tightens bolts to the correct tightness so the case threads are not damaged.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the vehicle

• Use the floor jack (rated 2-ton minimum) at the approved front jacking point to raise the front of your Focus.
• Place jack stands (rated 2-ton minimum) under the approved front support points.
• Lower the vehicle gently onto the jack stands.
• Use the floor jack (rated 2-ton minimum) to raise the rear enough so the vehicle sits level.
• Support the rear with jack stands (rated 2-ton minimum).
• Gently push the vehicle by hand to confirm it is stable before going underneath.

Step 2: Locate the transmission fill and drain plugs

• Put on safety glasses and nitrile gloves.
• Slide under the front-left area of the vehicle.
• Find the manual transmission case on the driver-side of the engine bay area.
• The fill plug is on the side of the transmission case.
• The drain plug is lower on the transmission case.
• Use clean shop towels to wipe dirt away from both plugs.

Step 3: Remove the fill plug first

• Place the drain pan (8-quart minimum) under the transmission.
• Use the 8mm hex bit socket and 3/8-inch drive ratchet to loosen the fill plug.
• Remove the fill plug by hand once it is loose.
• Inspect the plug and seal. Replace the seal if it is crushed, cracked, or leaking.
• Fill plug first, always.

Step 4: Drain the old fluid

• Move the drain pan (8-quart minimum) directly under the drain plug.
• Use the 8mm hex bit socket and 3/8-inch drive ratchet to loosen the drain plug.
• Remove the drain plug by hand and let the fluid drain completely.
• Wait until the fluid slows to a drip.
• Clean the drain plug with brake cleaner spray and wipe it with clean shop towels.

Step 5: Reinstall the drain plug

• Install a new transmission drain plug seal on the drain plug.
• Thread the drain plug in by hand first to avoid cross-threading.
• Use the 8mm hex bit socket and 3/8-inch drive torque wrench to tighten the drain plug.
• Torque to 35 Nm (26 ft-lbs).

Step 6: Fill the transmission

• Attach the fluid transfer pump to the new manual transmission fluid container.
• Insert the pump hose into the fill opening.
• Pump fluid into the transmission slowly.
• Fill until fluid just begins to trickle out of the fill opening while the vehicle is level.
• Approximate refill amount is 1.7 quarts.
• Do not overfill it.

Step 7: Reinstall the fill plug

• Install a new transmission fill plug seal on the fill plug.
• Thread the fill plug in by hand first.
• Use the 8mm hex bit socket and 3/8-inch drive torque wrench to tighten the fill plug.
• Torque to 35 Nm (26 ft-lbs).

Step 8: Clean and inspect

• Use brake cleaner spray to clean fluid residue from the transmission case.
• Wipe the area dry with clean shop towels.
• Look closely around the fill and drain plugs for leaks.

Step 9: Lower the vehicle

• Use the floor jack (rated 2-ton minimum) to raise the rear slightly and remove the rear jack stands (rated 2-ton minimum).
• Lower the rear slowly.
• Use the floor jack (rated 2-ton minimum) to raise the front slightly and remove the front jack stands (rated 2-ton minimum).
• Lower the front slowly.
• Remove the wheel chocks.

---

✅ After Repair

• ✅ Start your Focus and let it idle for one minute.
• ✅ With the clutch pressed, shift through all gears while parked.
• ✅ Take a short test drive and confirm the transmission shifts smoothly.
• ✅ Park on a clean surface and check underneath for drips after 10-15 minutes.
• ✅ Dispose of used transmission fluid at a recycling center or auto parts store.

---

💰 DIY vs Shop Cost

Shop Cost: $140-$260 (parts + labor)

DIY Cost: $35-$75 (parts only)

You Save: $105-$185 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
