🔧 Corolla - Engine Oil & Oil Filter Change

This service replaces the used engine oil and oil filter so your Corolla’s 1.8L engine stays properly lubricated and protected. You’ll drain the old oil, replace the filter, install new oil, then check the level carefully.

Difficulty Level: Beginner | Estimated Time: 45-75 minutes

---

⚠️ Safety & Precautions

• ⚠️ Work on a cool or mildly warm engine only. Hot oil can burn skin.
• ⚠️ Park on level ground so the oil drains correctly and the final level is accurate.
• ⚠️ Never get under your Corolla supported only by a jack. Always use jack stands.
• ⚠️ Wear safety glasses and nitrile gloves to protect your eyes and skin from oil.
• ⚠️ Do not overtighten the drain plug or oil filter. The aluminum oil pan can be damaged.
• ⚠️ Battery disconnect is not required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 14mm socket
• 3/8-inch ratchet
• 3/8-inch torque wrench
• 64mm 14-flute oil filter wrench
• Oil drain pan 8-quart minimum
• Floor jack 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Funnel
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil 0W-20 full synthetic - Qty: 4.4 quarts
• Spin-on engine oil filter - Qty: 1
• Engine oil drain plug crush washer - Qty: 1

---

📋 Before You Begin

• ✅ Park your Corolla on level ground and set the parking brake.
• ✅ Place wheel chocks behind the rear wheels.
• ✅ Let the engine cool for at least 15-30 minutes if it was recently driven.
• ✅ A torque wrench is a tool that tightens bolts to the correct tightness, helping prevent stripped threads or leaks.
• ✅ A crush washer is a soft sealing washer on the drain plug that should be replaced each oil change.
• ✅ Keep used oil off the ground. Put it in a sealed container and recycle it properly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Secure the Front

• Use the floor jack 2-ton minimum at the front center jacking point to lift the front of your Corolla.
• Place jack stands rated 2-ton minimum under the front side pinch weld support points.
• Gently lower the car onto the jack stands using the floor jack.
• Give the car a light shake by hand to confirm it is stable before going underneath.
• Never trust the jack alone.

Step 2: Position the Drain Pan

• Put on safety glasses and nitrile gloves.
• Slide the oil drain pan 8-quart minimum under the engine oil drain plug.
• The drain plug is at the bottom of the oil pan, facing downward/rearward under the engine.

Step 3: Remove the Oil Fill Cap

• Open the hood and remove the engine oil fill cap by hand.
• This lets air enter the engine while the old oil drains out.
• Use shop towels to wipe dirt away from the cap area before removing it.

Step 4: Drain the Old Engine Oil

• Use a 14mm socket and 3/8-inch ratchet to loosen the oil drain plug.
• Finish removing the plug by hand while keeping pressure inward until the last thread releases.
• Let the oil drain into the drain pan until it slows to an occasional drip.
• Remove the old crush washer from the drain plug.
• Use shop towels to clean the drain plug and the oil pan sealing surface.

Step 5: Reinstall the Drain Plug

• Install a new engine oil drain plug crush washer onto the drain plug.
• Thread the drain plug in by hand first to avoid cross-threading.
• Use the 14mm socket and 3/8-inch torque wrench to tighten the drain plug.
• Torque to 40 Nm (30 ft-lbs).
• Hand-start every bolt first.

Step 6: Remove the Old Oil Filter

• Move the oil drain pan 8-quart minimum under the oil filter area.
• Use the 64mm 14-flute oil filter wrench with the 3/8-inch ratchet to loosen the spin-on oil filter.
• A spin-on filter is the metal can-style filter that unscrews as one complete piece.
• Once loose, remove the filter by hand.
• Keep the open end facing upward as much as possible to reduce spills.
• Check that the old rubber gasket came off with the old filter.

Step 7: Install the New Oil Filter

• Use a clean finger with fresh 0W-20 full synthetic engine oil to lightly coat the rubber gasket on the new oil filter.
• Thread the new spin-on engine oil filter onto the engine by hand.
• Tighten the oil filter by hand until the gasket contacts the mounting surface.
• Then tighten it an additional 3/4 turn by hand.
• If using the 64mm 14-flute oil filter wrench, use it only lightly to finish the 3/4 turn.
• Do not overtighten the oil filter.

Step 8: Add New Engine Oil

• Place the funnel into the oil fill opening on top of the engine.
• Add about 4.0 quarts of 0W-20 full synthetic engine oil first.
• Reinstall the oil fill cap by hand.
• Use shop towels to wipe any spilled oil from the engine cover or valve cover area.

Step 9: Start the Engine and Check for Leaks

• Start the engine and let it idle for 30-60 seconds.
• Turn the engine off.
• Use safety glasses and look underneath for leaks at the drain plug and oil filter.
• If you see a leak, shut the engine off and correct it before driving.

Step 10: Lower the Vehicle

• Use the floor jack 2-ton minimum to lift the front slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower your Corolla slowly back onto level ground with the floor jack.

Step 11: Set the Final Oil Level

• Wait 5 minutes so the oil can drain back into the oil pan.
• Pull the dipstick, wipe it clean with shop towels, reinstall it fully, then pull it out again.
• Add oil through the funnel in small amounts until the level is near the full mark.
• Total oil capacity with filter is approximately 4.4 quarts.
• Do not overfill. Too much oil can cause engine damage.

Step 12: Reset the Maintenance Reminder

• Turn the ignition to ON without starting the engine.
• Use the steering wheel controls to select the odometer/trip display.
• Set the display to Trip A.
• Turn the ignition OFF.
• Press and hold the trip reset button.
• While holding the button, turn the ignition ON without starting the engine.
• Keep holding until the maintenance reset progress completes and the reminder clears.
• If your Corolla shows settings through the instrument display, use Settings > Vehicle Settings > Scheduled Maintenance > Reset.

---

✅ After Repair

• ✅ Start the engine again and confirm the oil pressure warning light turns off within a few seconds.
• ✅ Recheck for leaks around the drain plug and oil filter.
• ✅ After a short drive, park on level ground, wait 5 minutes, and recheck the dipstick level.
• ✅ Dispose of used oil and the old filter at a proper recycling center or auto parts store.
• ✅ Write down the mileage and date of the oil change.

---
