🔧 Engine Oil & Oil Filter - Oil Change

On your Tacoma, the engine oil and filter service is straightforward, but the filter is a cartridge-style element, not a spin-on can. You’ll drain the oil, replace the filter element and O-ring, then refill with the correct amount of oil and verify the level.

Difficulty Level: Beginner | Estimated Time: 1-1.5 hours

---

⚠️ Safety & Precautions

• Work on a level surface and let the engine cool enough to avoid burns.
• The engine oil and filter housing can be hot after driving.
• Use jack stands if you raise the truck. Never rely on a floor jack alone.
• Keep the drain pan centered under the oil pan to avoid spills.
• Do not overtighten the drain plug or filter cap. Aluminum parts can strip.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 14mm socket
• 3/8-inch ratchet
• Oil filter cap wrench 64mm 14-flute
• Torque wrench
• Drain pan
• Funnel
• Shop towels
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Engine oil (SAE 5W-30 full synthetic) - Qty: 5.5 quarts
• Oil filter element kit - Qty: 1
• Drain plug crush washer - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Let the engine cool for 15-30 minutes if it was recently running.
• If you raise the front of the truck, chock the rear wheels first.
• Have the new filter element and crush washer ready before draining the oil.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the truck

• Use a floor jack (rated 3-ton minimum) to lift the front of the truck if needed.
• Place jack stands under the frame and lower the truck onto them.
• Make sure the truck is stable before getting underneath it.

Step 2: Remove the drain plug and drain the oil

• Put the drain pan under the oil pan.
• Use a 14mm socket and 3/8-inch ratchet to remove the drain plug.
• Let the oil drain completely.
• Replace the crush washer on the drain plug.
• Install the drain plug and Torque to 39 Nm (29 ft-lbs).

Step 3: Remove the oil filter housing

• Move the drain pan under the oil filter housing.
• Use the Oil filter cap wrench 64mm 14-flute to loosen and remove the filter cap.
• Pull the filter element out of the housing.
• Let the remaining oil drip into the pan.
• Keep the old filter upright to reduce mess.

Step 4: Replace the filter element and seals

• Remove the old O-ring from the filter cap.
• Install the new O-ring from the filter kit.
• Lightly coat the new O-ring with fresh engine oil.
• Install the new filter element into the housing.
• Reinstall the filter cap and Torque to 25 Nm (18 ft-lbs).

Step 5: Refill with engine oil

• Remove the oil fill cap on top of the engine.
• Use a funnel to add 5.5 quarts of SAE 5W-30 full synthetic.
• Install the oil fill cap.

Step 6: Start and check for leaks

• Start the engine and let it idle for 30-60 seconds.
• Check the drain plug and filter housing for leaks.
• Shut the engine off and wait 5 minutes.

Step 7: Verify the oil level

• Use the dipstick to check the oil level.
• Add oil in small amounts if needed until the level is at the full mark.
• Do not overfill.

---

✅ After Repair

• Confirm there are no oil leaks after a short test drive.
• Recheck the oil level after the engine sits for a few minutes.
• Reset your maintenance reminder if your Tacoma has one set manually.
• Dispose of used oil and filter at a recycling center or auto parts store.

---

💰 DIY vs Shop Cost

Shop Cost: $90-$150 (parts + labor)

DIY Cost: $35-$65 (parts only)

You Save: $55-$85 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.0 hours.

---
